StartingandStoppingEngine
StartingProcedures
Pleaseobservethechapter”IMMOBILIZER”onpage22.
Pleaseobservethechapter”EMISSIONCONTROLSYSTEM”onpage247.
Danger!
Seriouspersonalinjuryordeathmayresultifyouareinvolvedinacollisionwithouthavingfastenedthesafetybelts.
Fastensafetybeltsbeforedrivingaway.
Beforestartingtheengine
Applythefootbrake.
Manualtransmission:Movethegearshiftleverintoneutral.Theclutchpedalmustbedepressedfullybeforethestarterwillengage.
Tiptronic:MovetheselectorlevertoPorN.
Temperaturesensorsontheengineautomaticallyprovidethecorrectfuel/airmixturerequiredforstarting.Therefore,itisnotnecessarytodepresstheacceleratorpedalwhilestartingacoldorawarmengine.
Startingtheengine
Turnignitionkeytoignitionlockposition2.
Assoonastheenginestarts,releasetheignitionkey.
Thefirstoperationofthestarterisendedautomat-icallywhentheenginestarts.Iftheenginedoesnotstart,subsequentstarteroperationswillnotbeendedautomatically.
Iftheenginefailstostartafter10secondsor15secondsofcranking:
Waitabout10secondsbeforeengagingthestarteragain.
Whenstartingtheengine,bereadytodriveimmediately.Drivevehicleatmoderatespeedsandavoidenginespeedsabove4,200rpmduringthefirst5minutes.
Donotlettheengineidletowarmup.
Danger!
Engineexhaustfumeshavemanycompo-nentswhichyoucansmell.Theyalsocontaincarbonmonoxide(CO),whichisacolorlessandodorlessgas.Carbonmonoxidecancauseunconsciousnessandevendeathifinhaled.
Neverstartorlettheengineruninanenclosed,unventilatedarea.Itisnotrec-ommendedtositinyourcarforprolongedperiodswiththeengineonandthecarnotmoving.
Danger!
Anunattendedvehiclewitharunningengineispotentiallyhazardous.Ifwarninglightsshouldcomeontoindicateimproperopera-tion,theywouldgounnoticed.
Neverleavetheengineidlingunattended.
Danger!
Dangerofre.
Donotparkoroperatethevehicleinareaswherethehotexhaustsystemmaycomeincontactwithdrygrass,brush,fuelspillorotherflammablematerial.
Controls,Instruments89

InstrumentPanelUSAModels
Overview
AlsorefertothecorrespondingchaptersintheOwner’sManual.
1.Engineoiltemperaturegauge
2.Speedometerwithanaloguedisplay
3.Tirepressurewarninglight
4.Turnsignalindicatorlight,left
5.Tachometer
6.Highbeamindicatorlight
7.Turnsignalindicatorlight,right
8.ABSwarninglight
9.Coolingsystem:Temperaturegauge,warninglight
10.Fuel:Levelgauge,warninglight
11.Engineoilpressuregauge
12.Adjustmentbuttonforinstrumentilluminationandtripcounter
13.Odometeranddailytripmileagedisplay
14.Automaticspeedcontrolindicatorlight
15.Lightsensorforinstrumentillumination
16.Airbagwarninglight
17.Emissioncontrolwarninglight(CheckEngine)
18.Centralwarninglight
19.On-boardcomputerdisplay
20.PorscheStabilityManagement:MultifunctionalPSMlight
21.Brakewarninglight
22.Safetybeltwarninglight
23.Tiptronicindicator
24.Clockandoutsidetemperaturedisplay
25.Adjustmentbuttonforclock
Whentheignitionisswitchedon,thewarninglightslightupforalampcheck.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Controls,Instruments91

InstrumentPanelCanadaModels
Overview
AlsorefertothecorrespondingchaptersintheOwner’sManual.
1.Engineoiltemperaturegauge
2.Speedometerwithanaloguedisplay
3.Tirepressurewarninglight
4.Turnsignalindicatorlight,left
5.Tachometer
6.Highbeamindicatorlight
7.Turnsignalindicatorlight,right
8.ABSwarninglight
9.Coolingsystem:Temperaturegauge,warninglight
10.Fuel:Levelgauge,warninglight
11.Engineoilpressuregauge
12.Adjustmentbuttonforinstrumentilluminationandtripcounter
13.Odometeranddailytripmileagedisplay
14.Automaticspeedcontrolindicatorlight
15.Lightsensorforinstrumentillumination
16.Airbagwarninglight
17.Emissioncontrolwarninglight(CheckEngine)
18.Centralwarninglight
19.On-boardcomputerdisplay
20.PorscheStabilityManagement:MultifunctionalPSMlight
21.Brakewarninglight
22.Safetybeltwarninglight
23.Tiptronicindicator
24.Clockandoutsidetemperaturedisplay
25.Adjustmentbuttonforclock
Whentheignitionisswitchedon,thewarninglightslightupforalampcheck.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Controls,Instruments93

InstrumentIllumination
Function
Theilluminationisautomaticallyadjustedtotheambientbrightnessbythelightsensorinthetachometer.
Inaddition,whenthecarlightsareswitchedon,theinstrumentandswitchsymbolbrightnesscanbemanuallyadjusted.
Warning!
Riskoflossofcontroloranaccident,resultinginseriouspersonalinjuryordeath.
Donotreachthroughthesteering-wheelspokeswhiledriving.
Note
Whenthecarlightsareswitchedon,theinstrumentlightingforlightdialsswitchesonandoffautomati-callydependingontheambientbrightness.
Dimminginstrumentillumination
TurnadjustmentbuttonAintheappropriatedirectionandholdituntilthedesiredbright-nesshasbeenreached.
Thechosenlevelofbrightnessisindicatedbyabardisplayinthedisplayfieldoftheon-boardcomputer.
Controls,Instruments97

thisprocess,theTirePressureMonitoringrecog-nizesthetiresandtheirlocations.Theon-boardcomputerdisplayesthemessage“TPCinactive-systemlearning”.
TheTirePressureMonitoringrequiresacertainamountoftimetolearnthewheels.Duringthistime,thecurrenttirepressuresarenotavailableontheon-board-computer:
–ThedisplayoftheTirepressurefunctionoftheon-boardcomputershowslines.
–Therequiredpressuresforcoldtiresat68°F(20°C)areindicatedintheInfopressuredisplayintheTirepressuremenu.
–Tirepressurewarningsareissuedwithouttirepressureandpositioninformation(gure)assoonasthevehicle’sownwheelshavebeendetectedandthetirepressurewarninglighthasgoneout.
PositionandpressureinformationisdisplayedassoonastheTirePressureMonitoringhasassignedthewheelsidentifiedasbelongingtothevehicletothecorrectwheelpositions.
Thewheellearningprocesstakesplaceexclusivelywhenthevehicleisbeingdriven.
Manuallycheckthetirepressureatallwheelsandcorrectthetirepressuretotherequiredvalue.
Changingawheelandreplacingtires
Newwheelsmustbefittedwithradiotransmit-tersfortheTirePressureMonitoring.Beforetiresarechanged,thebatterychargestateofthewheeltransmittersshouldbecheckedatanauthorizedPorschedealer.
Switchtheignitionoffwhenchangingawheel.
Thetiresettingsontheon-boardcomputermustbeupdatedafterchangingawheel.
Amessageappearsifthecharacteristicsofthenewtiresdonotagreewiththeon-boardcomputersettings.
Updatetheon-boardcomputersettingswhenthevehicleisstationarythenexttime.
Warninglight
Thewarninglightinthespeedometerlightsup:
–Whenalossinpressurehasbeendetected
–IftheTirePressureMonitoringisfaulty
–Whenlearningnewlymountedwheels/wheelsensors,aslongasthevehicle’sownwheelshavenotyetbeenrecognized.
Thetirepressurewarninglightintheinstrumentpanelgoesoutonlywhenthecauseofthefaulthasbeenrectified.
Nomonitoring
IntheeventoffaultstheTirePressureMonitoringcannotmonitorthetirepressure.Thewarninglightontheinstrumentpanellightsupandacorrespondingmessageappearsontheon-boardcomputer.
Monitoringisnotactivewhen:
–theTirePressureMonitoringisfaulty,
–wheeltransmittersfortheTirePressureMonitoringaremissing,
–temporarilyafterchangingawheel(learningphase),
–morethanfourwheeltransmittersaredetect-ed,
–thereisexternalinterferencebyotherradiosources,e.g.wirelessheadphones,
–tiretemperaturesaretoohigh.
Pleaseobservethechapter”WARNINGSONTHEINSTRUMENTPANELANDTHEON-BOARDCOMPUTER”onpage143.
134Controls,Instruments

InstrumentpanelOn-boardcomputerTextdisplayonon-boardcomputerMeaning/measure
ParkinglightonLeft/rightparkinglighton
Checkleft/rightdippedbeam(lowbeam)alsoappliesto:frontsidelights,directionindicator,highbeam,foglights,sideindicatorlight,brakelight,taillight,rearfoglight,reversinglight,raisedbrakelight,sidemarker
Thereportedlightisfaulty.Checkbulb.HavethefaultremediedatanauthorizedPorschedealer.
DaytimedrivinglightsoffDaytimedrivinglightsswitchoffwhentheengineisshutoff.Switchonlightsifnecessary.
HeadlightbeamadjustmentfaultyHavethefaultremediedatanauthorizedPorschedealer.
FrontlidnotclosedCloseluggagecompartmentlidproperly.
RearlidnotclosedCloseenginecompartmentlidproperly.
TargapanelnotclosedCloseglassrearhatch.
RainsensorfaultyHavethefaultremediedatanauthorizedPorschedealer.
Refillwasherfluid
144Controls,Instruments

WindshieldWiper/WasherLever
Generalinformation
Warning!
Dangerofinjurywhenthewindshieldwipersoperateunintentionally,e.g.inrainsensoroperation.Riskofdamagetothewindshieldandwipersystem.
Avoidrunningthewiperbladesoveradrywindshieldtopreventscratchingtheglass.Spraywasherfluidonthewindshieldfirst.Ascratchedwindshieldwillreducevisibility.
Alwaysloosenwiperbladesfromfrozenglassbeforeoperatingwiperstopreventdamagetothewipermotororblades.
Alwaysswitchoffwindshieldwipersincarwashtopreventthemwipingunintentionally(intermittentorsensoroperation).
Alwaysswitchoffwindshieldwipersbeforecleaningthewindshieldtoavoidunintentionaloperation(intermittentorsensoroperation).
Donotoperatetheheadlightwasherincarwashes.
Donotoperateheadlightwasherwhenitisfrozen.
Frontwiperandheadlightwashersystem
0–Windshieldwipersoff
1–Rainsensoroperationforfrontwindshieldwipers
Movewiperleverupwardstothefirstclick.
2–Windshieldwipersslow
Movewiperleverupwardstothesecondclick.
3–Windshieldwipersfast
Movewiperleverupwardstothethirdclick.
4–Frontwindshieldwiper-one-touchopera-tion:
Movewiperleverdownwards.Thefrontwindshieldwiperswipeonce.
5–Windshieldwipersandwashersystem:
Pullwiperlevertowardsthesteeringwheel.Thewashersystemspraysandwipeswhiletheleverispulledtowardsthesteeringwheel.Whenthewiperleverisreleased,afewdryingwipesareexecuted.
A-Headlightwasher
VehicleswithBi-Xenonheadlights
Thewasherspraysonlywhilelowbeamorhighbeamisswitchedon.
BrieflypushbuttonAtooperateheadlightwashersystem.
Ifheavilysoiled,repeatwash.
Theheadlightwashersystemautomaticallyspraysonceforeverytentimesthefrontwindshieldwashersystemisoperated.
Note
Thewindshieldwashernozzlesareheatedwhentheignitionison,asaprecautionagainstfreezing.
Controls,Instruments157

RearWiper
6–Rearwindowwiper-intermittentoperation
Movewiperleverforwardstothefirstclick.Therearwindowwiperwipesatpresetintervals.
Therearwiperisautomaticallyswitchedoffwhenaspeedof130mph(210km/h)isexceeded.Itisswitchedonagainwhenthespeedfallsbelow124mph(200km/h).
OnvehicleswiththeSportChronoPackagePlus,furtherrearwiperfunctionscanbeselectedviathePCM.
Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Rainsensor
Wiperspeed
Therainsensoronthewindshieldmeasurestheamountofrainfall(snowfalltoo).Wiperspeedisautomaticallyadjustedaccordingly.
Switchingon
Movewiperleverupwardstothefirstclick.
Switchingoff
Movewiperlevertoposition0.
