2007 PONTIAC VIBE service indicator

Seats and Restraint Systems
....................... 7
Front Seats
.............................................. 8
Rear Seats
............................................. 16
Safety Belts
............................................ 18
Child Restraints
...................................... 37
Airbag System
........................................ 63
Restraint System Check
......................... 82
Features and Controls
................................ 85
Keys
....................................................... 87
Doors and Locks
.................................... 92
Windows
................................................ 98
Theft-Deterrent Systems
....................... 100
Starting and Operating Your Vehicle
..... 102
Mirrors
.................................................. 121
OnStar
®System
................................... 123
Storage Areas
...................................... 127
Sunroof
................................................ 131Instrument Panel
....................................... 133
Instrument Panel Overview
................... 136
Climate Controls
................................... 152
Warning Lights, Gages, and
Indicators
.......................................... 158
Audio System(s)
................................... 177
Driving Your Vehicle
................................. 221
Your Driving, the Road, and
Your Vehicle
..................................... 222
Towing
................................................. 259
Service and Appearance Care
.................. 269
Service
................................................. 272
Fuel
...................................................... 274
Checking Things Under the Hood
......... 280
Bulb Replacement
................................ 315
Windshield Wiper Blade Replacement
... 321
2007 Pontiac Vibe Owner ManualM
1

Your vehicle has a crash sensing and
diagnostic module which records information
after a crash. SeeVehicle Data Collection and
Event Data Recorders on page 411.
Let only qualied technicians work on the
airbag system. Improper service can mean that
the airbag system will not work properly. See
your dealer for service.
Passenger Sensing System
Your vehicle has a passenger sensing system. A
passenger airbag status indicator on the
instrument panel will be visible when you turn your
ignition key to ON.
The words ON and OFF
will be visible in the
passenger airbag status
indicator during the
system check.When the system check is complete, either the
word ON or the word OFF will be visible depending
on whether the seat is occupied and/or the
weight of the occupant. SeePassenger Airbag
Status Indicator on page 163. The passenger
sensing system will turn off the right front
passenger’s frontal airbag, seat-mounted side
impact airbag (if equipped), and the safety
belt pretensioner under certain conditions. The
driver’s airbags are not part of the passenger
sensing system.
The passenger sensing system works with sensors
that are part of the right front passenger’s seat
assembly and safety belt assembly. The sensors
are designed to detect the presence of a
properly-seated occupant and determine if the right
front passenger’s frontal airbag, seat-mounted side
impact airbag (if equipped), and the safety belt
pretensioner should be enabled (may inate) or not.
74

If the airbag readiness light stays on after you
start the vehicle or comes on when you are driving,
your airbag system may not work properly.
Have your vehicle serviced right away.
{CAUTION:
If the airbag readiness light stays on or
keeps ashing after you start your
vehicle, it means the airbag system and
safety belt pretension system may not be
working properly. The airbags in your
vehicle may not inate in a crash, or they
could even inate without a crash. To help
avoid injury to yourself or others, have
your vehicle serviced right away if the
airbag readiness light stays on after you
start your vehicle.
Passenger Airbag Status Indicator
Your vehicle has a passenger airbag status
indicator in the instrument panel.
The indicator next to the
passenger airbag status
indicator lights is the
passenger safety
belt reminder light.
SeeSafety Belt Reminder Light on page 161for
more information on that indicator.
When the ignition key is turned to ON, the
passenger airbag status indicator will light ON and
OFF as a system check.
Then, after several more seconds, the status
indicator will light either ON or OFF if there is weight
on the seat or if the safety belt is buckled, to let you
know the status of the right front passenger’s frontal
and seat-mounted side impact airbag (if equipped).
163

If the word OFF is lit on the passenger airbag status
indicator, it means that the passenger sensing
system has turned off the right front passenger’s
frontal airbag and seat-mounted side impact airbag
(if equipped). SeePassenger Sensing System on
page 74for information about the conditions that
may affect the airbag system and also important
safety information.
If, after several seconds, all status indicator lights
remain on, or if there are no lights at all, there
may be a problem with the lights or the passenger
sensing system. See your dealer for service.
{CAUTION:
If the off indicator and the airbag readiness
light ever come on together, it means that
something may be wrong with the airbag
system. If this ever happens, have the
vehicle serviced promptly, because an
adult-size person sitting in the right front
passenger seat may not have the
protection of an airbag. SeeAirbag
Readiness Light on page 162.
Charging System Light
This light comes on
briey when you turn on
the ignition, with the
engine not running, as a
check to show you it
is working.
It should go out when the engine starts. If it stays
on, or comes on while you are driving, you
may have a problem with the electrical charging
system. It could indicate that you have a loose
generator drive belt or another electrical problem.
Have it checked right away. Driving while this
light is on could drain your battery.
If you must drive a short distance with the
charging system light on, be certain to turn
off all your accessories, such as the radio and
air conditioner.
165

Malfunction Indicator Lamp
Check Engine Light
Your vehicle has a computer which monitors
operation of the fuel, ignition, and emission control
systems.
This system is called OBD II (On-Board
Diagnostics-Second Generation) and is intended to
assure that emissions are at acceptable levels for
the life of the vehicle, helping to produce a cleaner
environment. The CHECK ENGINE light comes on
to indicate that there is a problem and service is
required. Malfunctions often will be indicated by the
system before any problem is apparent. This may
prevent more serious damage to your vehicle. This
system is also designed to assist your service
technician in correctly diagnosing any malfunction.Notice:If you keep driving your vehicle with
this light on, after awhile, the emission controls
might not work as well, your vehicle’s fuel
economy might not be as good, and the engine
might not run as smoothly. This could lead
to costly repairs that might not be covered by
your warranty.
Notice:Modications made to the engine,
transaxle, exhaust, intake, or fuel system
of your vehicle or replacement tires that do not
match your vehicle’s original tires can affect
your vehicle’s emission controls and may
cause this light to come on. Modications to
these systems could lead to costly repairs not
covered by your warranty. This may also
result in a failure to pass a required Emission
Inspection/Maintenance test. SeeAccessories
and Modifications on page 272.
This light should come on, as a check to show
you it is working, when the ignition is on and the
engine is not running. If the light does not
come on, have it repaired.
United StatesCanada
170

However, E85 (85% ethanol) and other fuels
containing more than 10% ethanol must not be
used in vehicles that were not designed for
those fuels.
Notice:Your vehicle was not designed for
fuel that contains methanol. Do not use
fuel containing methanol. It can corrode metal
parts in the fuel system and also damage
plastic and rubber parts. That damage would
not be covered under your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane-enhancing
additive called methylcyclopentadienyl manganese
tricarbonyl (MMT); ask the attendant where you
buy gasoline whether the fuel contains MMT.
General Motors recommends against the use of
such gasolines. Fuels containing MMT can reduce
the life of spark plugs and the performance of
the emission control system may be affected. The
malfunction indicator lamp may turn on. If this
occurs, return to your dealer for service.Fuels in Foreign Countries
If you plan on driving in another country outside
the United States or Canada, the proper fuel might
be hard to nd. Never use leaded gasoline or
any other fuel not recommended in the previous
text on fuel. Costly repairs caused by use of
improper fuel would not be covered by your
warranty.
To check the fuel availability, ask an auto club, or
contact a major oil company that does business
in the country where you will be driving.
276

Brake Wear
Your vehicle has front disc brakes and rear drum
brakes.
Disc brake pads have built-in wear indicators that
make a high-pitched warning sound when the
brake pads are worn and new pads are needed.
The sound can come and go or be heard all
the time your vehicle is moving, except when you
are pushing on the brake pedal rmly.
{CAUTION:
The brake wear warning sound means that
soon the brakes will not work well. That
could lead to an accident. When you hear
the brake wear warning sound, have your
vehicle serviced.
Notice:Continuing to drive with worn-out
brake pads could result in costly brake repair.Some driving conditions or climates can cause a
brake squeal when the brakes are rst applied
or lightly applied. This does not mean something
is wrong with the brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated,
inspect brake pads for wear and evenly tighten
wheel nuts in the proper sequence to GM torque
specications.
Rear drum brakes do not have wear indicators,
but if you ever hear a rear brake rubbing
noise, have the rear brake linings inspected
immediately. Also, the rear brake drums should be
removed and inspected each time the tires are
removed for rotation or changing. When you have
the front brake pads replaced, have the rear
brakes inspected, too.
Brake linings should always be replaced as
complete axle sets.
SeeBrake System Inspection on page 393.
308

Light (cont.)
Low Tire Pressure Warning Light............. 167
Low Washer Fluid Warning...................... 175
Malfunction Indicator................................ 170
Oil Pressure............................................. 173
Overdrive Off........................................... 174
Passenger Airbag Status Indicator............ 163
Safety Belt Reminder............................... 161
StabiliTrak
®Indicator................................ 168
Taillamp Indicator..................................... 174
TCS Warning Light.................................. 168
Traction Control System (TCS) Warning ... 168
Lighting
Entry........................................................ 149
Loading Your Vehicle................................... 253
Locks
Door.......................................................... 92
Power Door............................................... 94
Rear Door Security Locks.......................... 95
Loss of Control........................................... 237
Low Fuel Warning Light............................... 177
Low Washer Fluid Warning Light................. 175
M
Maintenance, Normal Replacement Parts.... 370
Maintenance Schedule
At Each Fuel Fill...................................... 386
At Least Once a Month............................ 386
At Least Once a Year.............................. 388
At Least Twice a Year.............................. 387
Brake System Inspection.......................... 393
Engine Cooling System Inspection........... 393
Exhaust System Inspection...................... 392
Fuel System Inspection............................ 392
How This Section is Organized................ 374
Introduction.............................................. 374
Maintenance Requirements...................... 374
Part A - Scheduled Maintenance
Services............................................... 376
Part B - Owner Checks and Services...... 386
Part C - Periodic Maintenance
Inspections........................................... 392
Part D - Recommended Fluids and
Lubricants............................................. 394
Part E - Maintenance Record................... 396
Scheduled Maintenance........................... 377
426
