2007 PONTIAC G6 engine

California Fuel
If your vehicle is certied to meet California
Emissions Standards, it is designed to operate on
fuels that meet California specications. See
the underhood emission control label. If this fuel is
not available in states adopting California
emissions standards, your vehicle will operate
satisfactorily on fuels meeting federal
specications, but emission control system
performance may be affected. The malfunction
indicator lamp may turn on and your vehicle may
fail a smog-check test. SeeMalfunction Indicator
Lamp on page 204. If this occurs, return to
your authorized GM dealer for diagnosis. If it is
determined that the condition is caused by the type
of fuel used, repairs may not be covered by
your warranty.
Additives
To provide cleaner air, all gasolines in the United
States are now required to contain additives
that will help prevent engine and fuel system
deposits from forming, allowing your emission
control system to work properly. In most cases,
you should not have to add anything to your fuel.
However, some gasolines contain only the
minimum amount of additive required to meet U.S.
Environmental Protection Agency regulations.
To help keep fuel injectors and intake valves clean,
or if your vehicle experiences problems due to
dirty injectors or valves, look for gasoline that is
advertised as TOP TIER Detergent Gasoline. Also,
your GM dealer has additives that will help
correct and prevent most deposit-related problems.
Gasolines containing oxygenates, such as
ethers and ethanol, and reformulated gasolines
may be available in your area. General Motors
recommends that you use these gasolines if they
comply with the specications described earlier.
311

Filling the Tank
{CAUTION:
Fuel vapor burns violently and a fuel re
can cause bad injuries. To help avoid
injuries to you and others, read and follow
all the instructions on the pump island.
Turn off your engine when you are
refueling. Do not smoke if you are near
fuel or refueling your vehicle. Keep
sparks, ames, and smoking materials
away from fuel. Do not leave the fuel
pump unattended when refueling your
vehicle. This is against the law in some
places. Keep children away from the fuel
pump; never let children pump fuel.The tethered fuel cap is located behind a hinged
fuel door on the passenger’s side of the vehicle.
To remove the fuel cap, turn it slowly
counterclockwise. The fuel cap has a spring in it;
if the cap is released too soon, it will spring
back to the right.
313

Checking Things Under
the Hood
{CAUTION:
An electric fan under the hood can start up
and injure you even when the engine is not
running. Keep hands, clothing, and tools
away from any underhood electric fan.
{CAUTION:
Things that burn can get on hot engine
parts and start a re. These include
liquids like fuel, oil, coolant, brake uid,
windshield washer and other uids, and
plastic or rubber. You or others could be
burned. Be careful not to drop or spill
things that will burn onto a hot engine.
316

Engine Compartment Overview
When you open the hood on the 2.4L L4 engine, here is what you will see:
318

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 330.
B. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 325.
C. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 325.
D. Engine Coolant Surge Tank. SeeEngine
Coolant on page 339.
E. Pressure Cap. SeePressure Cap on page 342.F. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 352.
G. Battery. SeeBattery on page 355.
H. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 350.
I. Engine Compartment Fuse Block. SeeEngine
Compartment Fuse Block on page 418.
319

When you open the hood on the 3.5L V6 engine, here is what you will see:
320

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 330.
B. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 349.
C. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 325.
D. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 325.
E. Engine Coolant Surge Tank. SeeEngine
Coolant on page 339.F. Pressure Cap. SeePressure Cap on page 342.
G. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 352.
H. Battery. SeeBattery on page 355.
I. Engine Compartment Fuse Block. SeeEngine
Compartment Fuse Block on page 418.
J. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 350.
321

When you open the hood on the 3.6L V6 engine, here is what you will see:
322
