sunrooF controls (if so equipped)
The ignition switch must be in the ON position to operate the sunroof.
TILTING THE SUNROOF
To tilt the sunroof up, push the switch toward UP/
CLOSE. 01 To tilt the sunroof down, push the switch toward DOWN/OPEN. 02
SLIDING THE SUNROOF
To close the sunroof, push the switch toward UP/CLOSE. 01
To open the sunroof, push the switch toward DOWN/OPEN. 02
Fuel -Filler door release
The fuel-filler door release is located on the floor to the left of the driver’s seat.
To open the fuel-filler door, push down on the switch. 01
To lock, close the fuel-filler door securely.
trunk lid release s W itch
The trunk lid release switch is located on the floor to the left of the driver’s seat.
To open the trunk lid, pull the trunk lid release switch up. 02
To close the trunk lid, lower and push the trunk lid down securely.
LOAD BUTTON
LOAD A SINGLE DISC - Press the LOAD button for less than 1.5 seconds. Select
the loading slot by pressing the CD insert select button (1-6), then insert the CD.
LOAD UP TO 6 DISCS - Press and hold the LOAD button for more than 1.5
seconds. The slot numbers (1-6) will illuminate on the display when CDs are loaded
into the changer.
FM/
aM/ sat * radio With cd changer (
if so equipped)
01
02
01
01
02
03
04
05
0607
08
09
10
01
02
