2007 NISSAN MURANO WASHER SWITCH

The rear window wiper and washer operate
when the ignition switch is in the ON position.
Turn the switch clockwise from the OFF position
to operate the wiper.1Intermittent (INT) — intermittent operation
(not adjustable)
2Low (ON) — continuous low speed operation
Push the switch forward
3
to operate the
washer. Then the wiper will also operate several
times.
WARNING
In freezing temperatures the washer so-
lution may freeze on the rear window
glass and obscure your vision. Warm the
rear window with the defroster before
you wash the rear window.
CAUTION

If the rear window wiper operation is
interrupted by snow etc., the wiper
may stop moving to protect its motor.
If this occurs, turn the wiper switch to
OFF and remove the snow etc. on
and around the wiper arms. After
about 1 minute, turn the switch ON
again to operate the wiper.

Do not operate the washer continu-
ously for more than 30 seconds.

Do not operate the washer if the
reservoir tank is empty.

Do not fill the window washer reser-
voir tank with washer fluid concen-trates at full strength. Some methyl
alcohol based washer fluid concen-
trates may permanently stain the
grille if spilled while filling the win-
dow washer reservoir tank.

Pre-mix washer fluid concentrates
with water to the manufacturer’s rec-
ommended levels before pouring the
fluid into the window washer reser-
voir tank. Do not use the window
washer reservoir tank to mix the
washer fluid concentrate and water.
SIC3297
REAR WINDOW WIPER AND
WASHER SWITCH
Instruments and controls
2-21


06.7.5/Z50-D/V5.0


CAUTION

After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when
the engine hood is opened.

Make sure the wiper blade contact
the glass, otherwise the arms may be
damaged from wind pressure.

Worn windshield wiper blades can
damage the windshield and impair
driver vision.CLEANINGIf your windshield is not clear after using the
windshield washer or if a wiper blade chatters
when running, wax or other material may be on
the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your wind-
shield is clean if beads do not form when rinsing
with clear water.
Clean the blade by wiping it with a cloth soaked
in a washer solution or a mild detergent. Thenrinse the blade with clear water. If your wind-
shield is still not clear after cleaning the blades
and using the wiper, replace the blades.
REPLACINGReplace the wiper blades if they are worn.
1. Turn the ignition switch to the ON position
and the windshield wiper switch ON. Turn the
ignition switch OFF when the wiper is in the
fully up position. The wiper will stop as
illustrated.
The wiper should be in the fully up position
to avoid scratching the engine hood or
wiper arm.
2. Pull the wiper arm up.
Hold the wiper arm to avoid hitting the
SDI1503
WINDSHIELD WIPER BLADES8-18
Maintenance and do-it-yourself


06.7.5/Z50-D/V5.0


F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-10
Filter
Air cleaner housing filter ................................... 8-17
Changing engine oil filter ................................. 8-11
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-22
Floor mat cleaning ....................................................... 7-4
Fluid
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
CVT fluid ............................................................... 8-12
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM-SAT radio with casette player
and CD changer ........................................................ 4-38
FM-AM-SAT radio with CD player ....................... 4-34
Fog light switch ......................................................... 2-27
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-49
Front power seat adjustment .................................... 1-3
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Fuel economy ...................................................... 5-24
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Fuel-filler cap ....................................................... 3-26
Fuel-filler door...................................................... 3-26Gauge ...................................................................... 2-5
Fuses ............................................................................ 8-21
Fusible links ................................................................ 8-22
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-44
Gas cap ....................................................................... 3-26
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Fuel gauge .............................................................. 2-5
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-4
General maintenance .................................................. 8-2
Glove box .................................................................... 2-33
H
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-7
Headlights
Aiming control ..................................................... 2-25
Bulbreplacement ............................................... 8-27
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-28
Heater
Engine block heater ........................................... 5-35
Heater and air conditioner (automatic) ......... 4-23
HomeLink
Universal Transceiver ......................... 2-44
Hood release .............................................................. 3-24Horn .............................................................................. 2-28
I
Ignition knob(Intelligent Key system) .................. 3-13
Ignition switch
Key positions ....................................................... 5-10
Ignition switch (Except for Intelligent Key
equipped model) .......................................................... 5-9
Ignition switch (Intelligent Key System
equipped model) ....................................................... 5-10
Immobilizer system .................................................... 2-18
In-cabin microfilter .................................................... 4-26
Indicator lights............................................................ 2-14
Continuously variable transmission (CVT)
indicator light ....................................................... 2-14
Cruise set indicator light .................................. 2-14
Malfunction indicator light (MIL) .................... 2-14
Inside
Automatic anti-glare mirror............................... 3-31
Mirror...................................................................... 3-30
Inspection/maintenance (I/M) test ........................ 9-25
Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Intelligent Key system ................................................. 3-9
Engine starting .................................................... 3-13
Key operating range........................................... 3-15
Key operation....................................................... 3-12
Mechanical key and valet key .......................... 3-23
Operating the engine......................................... 3-13
Remote keyless operation ................................ 3-20
Trouble-shooting guide ..................................... 3-19
Warning light ....................................................... 2-11
Warning signals .................................................. 3-17


06.7.5/Z50-D/V5.0

10-3

Checking engine oil level .................................... 8-9
Engine oil................................................................. 8-9
Engine oil viscosity ............................................... 9-5
Operating the engine (Intelligent Key
system) ......................................................................... 3-13
Outside mirrors .......................................................... 3-32
Overheat, If your vehicle overheats ...................... 6-11
Owner’s Manual/Service Manual order
information................................................................... 9-26
P
Parking
Brake break-in ..................................................... 5-30
Parking brake operation .................................... 5-21
Parking on hills .................................................... 5-29
Pedal position adjustment....................................... 3-29
Phone, Car phone or CB radio ............................. 4-45
Power
Front seat adjustment .......................................... 1-3
Power door lock .................................................... 3-3
Power outlet ......................................................... 2-30
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Power windows................................................... 2-38
P position selecting warning light ......................... 2-13
Pre-tensioner seat belt system .............................. 1-54
Precautions
Audio operation ................................................... 4-28
Braking precautions ........................................... 5-30
Child restraints .................................................... 1-21
Cruise control ...................................................... 5-22
Driving safety .......................................................... 5-6
Maintenance ........................................................... 8-5On-pavement and offroad driving ..................... 5-6
Seat belt usage ..................................................... 1-9
Supplemental restraint system ........................ 1-41
When starting and driving .................................. 5-2
Push starting .............................................................. 6-11
R
Radio, Car phone or CB radio .............................. 4-45
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-25
Rear center seat belt................................................ 1-17
Rear door lock, Child safety rear door lock.......... 3-5
Rear personal light .................................................... 2-43
Rear power point....................................................... 2-30
Rear seat adjustment .................................................. 1-5
Rear window and outside mirror defroster
switch ........................................................................... 2-22
Rear window wiper and washer switch .............. 2-21
Rearview monitor ....................................................... 4-19
Recorders, Event data ............................................. 9-26
Registering your vehicle in another country.......... 9-9
Remote keyless entry
System, Except Intelligent Key system ............ 3-5
System, For Intelligent Key system ................ 3-20
Reporting safety defects (US only) ...................... 9-24
Rollover........................................................................... 5-5
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-24Towing safety....................................................... 9-19
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment ............................. 1-3
Rear seat adjustment ........................................... 1-5
Seat belt(s)
Child safety .......................................................... 1-12
Infants .................................................................... 1-12
Injured persons.................................................... 1-13
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-54
Precautions on seat belt usage......................... 1-9
Pregnant women ................................................. 1-13
Rear center seat belt ......................................... 1-17
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-20
Seat belt hook ..................................................... 1-17
Seat belt maintenance ...................................... 1-20
Seat belt warning light and chime ................. 2-13
Seat belts ................................................................ 1-9
Shoulder belt height adjustment..................... 1-16
Small children ...................................................... 1-12
Three-point type with retractor ....................... 1-13
Seat(s)
Driver-side memory ............................................ 3-33
Heated seats........................................................ 2-28
Seats ........................................................................ 1-2
Security system (NISSAN Vehicle Immobilizer
System), Engine start ............................................... 2-18
Security system, Vehicle security system ........... 2-17
Selector lever, Shift lock release ............... 5-16, 5-20
Servicing air conditioner .............................. 4-23, 4-26
Shift lock release, Transmission ................ 5-16, 5-20


06.7.5/Z50-D/V5.0

10-5

U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-23
V
Valet key (for Intelligent Key system) ................... 3-23
Vanity mirror light ...................................................... 2-44
Vehicle
Dimensions and weights ..................................... 9-8
Identification number (VIN) ................................. 9-9
Loading information............................................ 9-13
Recovery (freeing a stuck vehicle) ................. 6-15
Security system ................................................... 2-17
Vehicle Dynamic Control (VDC) off
switch..................................................................... 2-29
Vehicle Dynamic Control (VDC) system ...... 5-32
Vehicle electronic systems...................... 4-7, 4-16
Ventilators.................................................................... 4-21
W
Warning labels, Air bag warning labels .............. 1-55
Warning light
Air bag warning light .............................. 1-56, 2-13
All-wheel drive (AWD) warning light................ 2-9
Anti-lock Braking System (ABS) warning
light......................................................................... 2-10
AWD warning light ............................................. 5-27
Brake warning light ............................................ 2-10
Door open warning light ................................... 2-11
Intelligent Key warning light ............................. 2-11Low fuel warning light ....................................... 2-12
Low tire pressure warning light ...................... 2-12
P position selecting warning light .................. 2-13
Seat belt warning light and chime ................. 2-13
Warning lights .............................................................. 2-9
Warning, Hazard warning flasher switch ............ 2-27
Warning, Tire pressure monitoring system
(TPMS) ........................................................................... 5-3
Warning, Warning/indicator lights and audible
reminders ....................................................................... 2-9
Warranty, Emission control system warranty ..... 9-24
Washer switch
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Washing ......................................................................... 7-2
Waxing............................................................................ 7-2
Weights (See dimensions and weights) ............... 9-8
Wheel/tire size.............................................................. 9-8
Wheels and tires ....................................................... 8-29
Cleaning aluminum alloy wheels ....................... 7-3
Window washer fluid ............................................... 8-14
Window(s)
Cleaning................................................................... 7-3
Power windows................................................... 2-38
Windshield wiper and washer switch .................. 2-20
Wiper
Rear window wiper and washer switch........ 2-21
Rear window wiper blade................................. 8-20
Windshield wiper and washer switch ........... 2-20
Wiper blades ....................................................... 8-18X
Xenon headlights....................................................... 2-22


06.7.5/Z50-D/V5.0

10-7
