2007 NISSAN LATIO compression ratio

QUICK REFERENCE CHART: VERSA2007

QUICK REFERENCE CHART: VERSAPFP:00000
Engine Tune-Up DataELS00252
GENERAL SPECIFICATIONS
DRIVE BELT
SPARK PLUG
Unit: mm (in)
Front Wheel Alignment (Unladen*1)ELS00253
Engine typeMR18DE
Cylinder arrangementIn-line 4
Displacement
cm
3 (cu in)1,797 (109.65)
Bore and stroke mm (in) 84.0 x 81.1 (3.307 x 3.192)
Valve arrangementDOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Compression ratio9.9
Compression pressure
kPa (bar, kg/cm
2 , psi) / 250 rpmStandard 1,500 (15.0, 15.3, 217.6)
Minimum 1,200 (12.0, 12.2, 174)
Differential limit between cylinders 100 (1.0, 1.0, 15)
Tension of drive belt Auto adjustment by auto-tensioner
Plug typeIridium-tipped TYPE
MakeDENSO
Standard typeFXE20HR11
Spark plug gapNominal: 1.1 (0.043)
Camber
Degree minute (Decimal degree)RHMinimum - 1° 05′ (- 1.08°)
Nominal - 0° 20′ (- 0.33°)
Maximum 0° 25′ (0.42°)
LHMinimum - 0° 55′ (- 0.92°)
Nominal - 0° 10′ (- 0.17°)
Maximum 0° 35′ (0.58°)
Left and right difference
(RH - LH)Minimum -0° 45′ (-0.75°) or less
Nominal -0° 12′ (-0.20°) or less
Maximum 0° 21′ (0.35°) or less
Caster
Degree minute (Decimal degree)RHMinimum 4° 05′ (4.08°)
Nominal 4° 50′ (4.83°)
Maximum 5° 35′ (5.58°)
LHMinimum 3° 55′ (3.92°)
Nominal 4° 40′ (4.67°)
Maximum 5° 25′ (5.42°)
Left and right difference
(RH - LH)Minimum -0° 21′ (-0.35°) or less
Nominal 0° 12′ (0.20°) or less
Maximum 0° 45′ (0.75°) or less

TROUBLE DIAGNOSIS
EC-121
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
DATA MONITOR (SPEC) MODE
Monitored Item
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
ACTIVE TEST MODE
Test Item
Monitored item [Unit]ECM
input
signalsMain
signalsDescription Remarks
ENG SPEED [rpm]××

Indicates the engine speed computed
from the signal of the crankshaft position
sensor (POS) and camshaft position
sensor (PHASE).
MAS A/F SE-B1 [V]××

The signal voltage of the mass air flow
sensor specification is displayed.
When engine is running specification
range is indicated.
B/FUEL SCHDL
[msec]×

“Base fuel schedule” indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.

When engine is running specification
range is indicated.
A/F ALPHA-B1 [%]×

The mean value of the air-fuel ratio feed-
back correction factor per cycle is indi-
cated.
When engine is running specification
range is indicated.

This data also includes the data for the
air-fuel ratio learning control.
TEST ITEM CONDITION JUDGEMENT CHECK ITEM (REMEDY)
FUEL INJEC-
TION

Engine: Return to the original
trouble condition

Change the amount of fuel injec-
tion using CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.

Harness and connectors

Fuel injector

Air fuel ratio (A/F) sensor 1
IGNITION TIM-
ING

Engine: Return to the original
trouble condition

Timing light: Set

Retard the ignition timing using
CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.

Perform Idle Air Volume Learning.
POWER BAL-
ANCE

Engine: After warming up, idle
the engine.

A/C switch OFF

Shift lever: P or N (A/T, CVT),
Neutral (M/T)

Cut off each fuel injector signal
one at a time using CONSULT-II.Engine runs rough or dies.

Harness and connectors

Compression

Fuel injector

Power transistor

Spark plug

Ignition coil
COOLING FAN*

Ignition switch: ON

Turn the cooling fan “LOW”, “HI”
and “OFF” with CONSULT-II.Cooling fan moves and stops.

Harness and connectors

Cooling fan relay

Cooling fan motor
ENG COOLANT
TEMP

Engine: Return to the original
trouble condition

Change the engine coolant tem-
perature using CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.

Harness and connectors

Engine coolant temperature sen-
sor

Fuel injector
FUEL PUMP
RELAY

Ignition switch: ON
(Engine stopped)

Turn the fuel pump relay ON and
OFF using CONSULT-II and lis-
ten to operating sound.Fuel pump relay makes the operat-
ing sound.
Harness and connectors

Fuel pump relay

EC-308Revision: June 2006
DTC P0300 - P0304 MULTIPLE CYLINDER MISFIRE, NO. 1 - 4 CYLINDER MIS-
FIRE
2007 Versa
DTC P0300 - P0304 MULTIPLE CYLINDER MISFIRE, NO. 1 - 4 CYLINDER MIS-
FIRE
PFP:00000
On Board Diagnosis LogicUBS00QGZ
When a misfire occurs, engine speed will fluctuate. If the engine speed fluctuates enough to cause the crank-
shaft position (CKP) sensor (POS) signal to vary, ECM can determine that a misfire is occurring.
The misfire detection logic consists of the following two conditions.
1. One Trip Detection Logic (Three Way Catalyst Damage)
On the 1st trip that a misfire condition occurs that can damage the three way catalyst (TWC) due to over-
heating, the MIL will blink.
When a misfire condition occurs, the ECM monitors the CKP sensor (POS) signal every 200 engine revo-
lutions for a change.
When the misfire condition decreases to a level that will not damage the TWC, the MIL will turn off.
If another misfire condition occurs that can damage the TWC on a second trip, the MIL will blink.
When the misfire condition decreases to a level that will not damage the TWC, the MIL will remain on.
If another misfire condition occurs that can damage the TWC, the MIL will begin to blink again.
2. Two Trip Detection Logic (Exhaust quality deterioration)
For misfire conditions that will not damage the TWC (but will affect vehicle emissions), the MIL will only
light when the misfire is detected on a second trip. During this condition, the ECM monitors the CKP sen-
sor signal every 1,000 engine revolutions.
A misfire malfunction can be detected on any one cylinder or on multiple cylinders.
Sensor Input Signal to ECM ECM function
Crankshaft position sensor (POS) Engine speed On board diagnosis of misfire
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0300
0300Multiple cylinder misfire
detectedMultiple cylinder misfire.

Improper spark plug

Insufficient compression

Incorrect fuel pressure

Fuel injector circuit is open or shorted

Fuel injector

Intake air leak

The ignition signal circuit is open or
shorted

Lack of fuel

Drive plate or flywheel

Air fuel ratio (A/F) sensor 1

Incorrect PCV hose connection P0301
0301No.1 cylinder misfire
detectedNo. 1 cylinder misfires.
P0302
0302No. 2 cylinder misfire
detectedNo. 2 cylinder misfires.
P0303
0303No. 3 cylinder misfire
detectedNo. 3 cylinder misfires.
P0304
0304No. 4 cylinder misfire
detectedNo. 4 cylinder misfires.

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-105
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: June 20062007 Versa
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00U80
GENERAL SPECIFICATIONS
DRIVE BELT
WATER CONTROL VALVE
EXHAUST MANIFOLD
Unit: mm (in)
THERMOSTAT
SPARK PLUG
Unit: mm (in)
CYLINDER HEAD
Unit: mm (in) Engine typeMR18DE
Cylinder arrangementIn-line 4
Displacement
cm
3 (cu in)1,797 (109.65)
Bore and stroke mm (in) 84.0 x 81.1 (3.307 x 3.192)
Valve arrangementDOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Compression ratio9.9
Compression pressure
kPa (bar, kg/cm
2 , psi) / 250 rpmStandard 1,500 (15.0, 15.3, 217.6)
Minimum 1,200 (12.0, 12.2, 174)
Differential limit between cylinders 100 (1.0, 1.0, 15)
Tension of drive belt Auto adjustment by auto-tensioner
Valve opening temperature 93.5 - 96.5°C (200 - 206°F)
Maximum valve lift 8 mm/ 108°C (0.315 in/ 226°F)
Valve closing temperature More than 90°C (194°F)
Items Limit
Surface distortionEach exhaust port 0.3 (0.012)
Entire part 0.7 (0.028)
Valve opening temperature 80.5 - 83.5°C (177 - 182°F)
Maximum valve lift 8 mm/ 95°C (0.315 in/ 203°F)
Valve closing temperature More than 77°C (171°F)
Plug typeIridium-tipped TYPE
MakeDENSO
Standard typeFXE20HR11
Spark plug gapNominal: 1.1 (0.043)
Items Standard Limit
Head surface distortion — 0.1 (0.004)

FAX-20
FRONT DRIVE SHAFT
Revision: June 20062007 Versa
3. Press support bearing assembly off slide joint assembly using a
suitable tool.
4. Remove dust shield.
Damper

Remove damper bands, then remove damper from shaft.
INSPECTION AFTER DISASSEMBLY
Shaft
Replace shaft if there is bending, cracking, or other damage.
Joint Sub-Assembly

Make sure there is no rough rotation or unusual axial looseness.

Make sure there is no foreign material inside joint sub-assembly.

Check joint sub-assembly for compression scars, cracks or fractures.
CAUTION:
If there are any irregular conditions of joint sub-assembly components, replace the entire joint sub-
assembly.
Slide Joint Housing and Spider Assembly
Make sure there are no compression scars, cracks, fractures or unusual wear of housing or spider roller con-
tact surface.
CAUTION:
If there are any irregular conditions of the slide joint housing and spider assembly components,
replace them as a set.
Support Bearing
Make sure wheel bearing rolls freely and is free from noise, cracks, pitting or wear.
Support Bearing Bracket
Check for bending, cracks, or damage.
Damper
Check damper for cracks or wear. Replace as necessary.
ASSEMBLY
Transaxle Side
1. Install new boot and new small boot band on shaft.
CAUTION:

Do not reuse boot or boot band.

Cover drive shaft serration with tape to prevent damage
to boot during installation.
2. Remove protective tape wound around serrated part of shaft.
YAX004
SFA80 0

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Collision diagnosis .......................................... SRS-54
Combination lamp, rear, removal and installation LT-87
Combination meter ................................................ DI-5
Combination meter removal and installation - See Instru-
ment panel .......................................................... IP-11
COMBSW - Wiring diagram ............................... LT-67
Component Location (manual A/C) ................ MTC-25
Compression pressure ...................................... EM-62
Compressor mounting .................................... MTC-84
Compressor special service tool .................... MTC-12
Condenser ...................................................... MTC-88
Connecting rod .................................................. EM-97
Connecting rod bearing clearance .................. EM-101
Connecting rod bushing clearance .................... EM-97
CONSULT for ABS .......................................... BRC-20
CONSULT general information .......................... GI-37
CONSULT-II for engine ................................... EC-113
CONSULT-II function (EPS) ............................ STC-13
CONSULT-II Reference value (CVT) .............. CVT-57
Control lever (M/T) ............................................ MT-12
Control units (terminal arrangement) ................ PG-72
Control valve (CVT) ......................................... CVT-29
Converter housing installation ............ AT-254, AT-369
COOL/F - Wiring diagram ............................... EC-448
Coolant mixture ratio ......................................... MA-12
Cooling circuit (engine) ....................................... CO-7
Cooling fan ........................................................ CO-15
Cooling fan motor ............................................ EC-443
Corrosion protection ......................................... BL-237
Coupling sleeve (M/T) ....................................... MT-18
Crankcase ventilation system - See Positive crankcase
ventilation .......................................................... EC-44
Crankshaft ......................................................... EM-77
Crankshaft position sensor (POS) ................... EC-319
Crash zone sensor .......................................... SRS-49
CVT air breather hose ................................... CVT-205
CVT control system ......................................... CVT-22
CVT cross-sectional view ................................ CVT-21
CVT Electrical parts location ........................... CVT-40
CVT fluid checking ............... CVT-16, CVT-43, MA-20
CVT fluid cooler cleaning ................................ CVT-18
CVT fluid replacement ........................ CVT-17, MA-21
CVT fluid temparature sensor ......................... CVT-85
CVT hydraulic control system ......................... CVT-23
CVT indicator ...................................................... DI-42
CVT self-diagnoses ........................... CVT-60, CVT-67
CVT shift lock system .................................... CVT-197
CVT trouble diagnoses .................................... CVT-34
CVTIND - Wiring diagram ................................... DI-43
Cylinder block .................................................... EM-77
Cylinder head .................................................... EM-62
Cylinder head bolt tightening ............................. EM-65
D
D/LOCK - Wiring diagram ...................... BL-26
, BL-31
Data link connector ............. EC-115, EC-127, EC-592
DEF - Wiring diagram ....................................... GW-52
Diagnosis sensor unit ...................................... SRS-52
Diagnostic trouble code (DTC) for OBD system . EC-8,
EC-48
Diagnostic trouble code (DTC) inspection priority chart
EC-89
, CVT-34
Differential gear (FF M/T) .................................. MT-22
Differentil side oil seal .................................... CVT-206
DLC - Wiring diagram ...................................... EC-592
Door glass .......................................... GW-43, GW-47
Door glass Fitting Adjustment(Front) ................ GW-46
Door glass Fitting Adjustment(Rear) ................ GW-49
Door mirror ....................................................... GW-65
Door trim .............................................................. EI-27
Door, front ......................................................... GW-43
Door, rear ......................................................... GW-47
Drive shaft ......................................................... MA-27
Driver air bag ................................................... SRS-41
Dropping resistor (A/T) .................................... AT-150
DTC work support ............................................ EC-122
DTRL - Wiring diagram ....................................... LT-31
Duct and grilles ............................................... MTC-75
E
ECM input/output signal .................................. EC-105
ECM power supply .......................................... EC-144
ECTS - Wiring diagram .................................... EC-202
Electric sunroof .................................................. RF-10
Electric throttle control actuator .. EM-18, EC-499, EC-
506, EC-511
Electrical load signal circuit ............................. EC-562
Electrical unit ..................................................... PG-72
Electrical units location ...................................... PG-64
Electronic ignition (EI) system ........................... EC-25
Electronic key ..................................................... BL-80
ENG SS - Wiring diagram ................................ AT-114
Engine control circuit diagram ......................... EC-103
Engine control component parts location .......... EC-96
Engine control module (ECM) ......................... EC-427
Engine control system diagram ......................... EC-22
Engine coolant ..................................................... CO-8
Engine coolant temperature sensor (ECTS) ... EC-200,
EC-212
Engine fail-safe system ..................................... EC-91
Engine oil ............................................................. LU-5
Engine oil precautions .......................................... GI-7
Engine removal .................................................. EM-73
EPS - Wiring diagram ........................................ STC-9
EPS control unit input/output signal reference values ..
STC-11
EPS system description ..................................... STC-5
EPS system diagram ......................................... STC-6
ETC1 - Wiring diagram .................................... EC-500
ETC2 - Wiring diagram .................................... EC-495
ETC3 - Wiring diagram .................................... EC-507
EVAP canister ................................................... EC-34
EVAP canister purge volume control solenoid valve ....
EC-354
, EC-362
EVAP canister vent control valve ...... EC-369, EC-376
EVAP control system (small leak) diagnosis .. EC-346,
