RF-40
SOFT TOP
Revision: 2006 November2007 350Z
Check Soft Top Control Unit Power Supply (OP, CL)NIS0006K
1. CHECK FUSE

Check 10A fuse [No.12, located in the fuse block (J/B)]

Check 40A fusible link (letter G located in the fuse and fusible link box.)
NOTE:
Refer to RF-11, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Start engine.
2. Check voltage between soft top control unit connector B66, 67
terminal 1, 8, 17 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check soft top control unit power supply circuit for open
or short.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect soft top control unit connector.
3. Check continuity between soft top control unit connector B66
terminal 7, 16 and ground.
OK or NG
OK >> Power supply and ground circuit are OK.
NG >> Check soft top control unit ground circuit for open or
short.
Check Soft Top Switch (OPEN)NIS0006L
1. CHECK SOFT TOP OPEN SWITCH SIGNAL
1. Start engine.
2. Check soft top control unit connector and ground.
OK or NG
OK >> Soft top switch (OPEN) is OK.
NG >> GO TO 2.1 (W/R) - Ground : Battery voltage
8 (W/R) - Ground : Battery voltage
17 (R) - Ground : Battery voltage
PIIA7886E
7 (B) - Ground : Continuity should exist.
16 (B) - Ground : Continuity should exist.
PIIA7887E
ConnectorTerminal (Wire color)
Soft top switch
ConditionVoltage (V)
(Approx.)
(+) (-)
B67 18 (SB) GroundOPEN 0
Other than above 5
PIIA7888E
