2007 NISSAN 350Z Owners Manual

FrontTo open the cup holder, slide the lid
1.
Install the partition plate into the slit
2.
Soft bottle holder
CAUTION

Do not use bottle holder for any other
objects that could be thrown about in
the vehicle and possibly injure
people during sudden braking or an
accident.

Do not use bottle holder for open
liquid containers.
CONSOLE BOXPushing the button
1
will open the lid slightly,
then pull up the lid manually
2. The center
console box is equipped with a card holder
A.
SIC3007
SIC3008
SIC3009
2-34
Instruments and controls


06.10.24/Z33-D/V5.0


If objects (coins, etc.) fall into the rear section of
the center console box, remove the rear wall
B
of the box as shown, and pick up the objects.
CAUTION
Be careful not to pinch your fingers
when removing the rear wall
B.
REAR FLOOR BOXThe rear floor box is located behind the passen-
ger’s seat.
Fold the passenger’s seatback forward to ac-
cess the rear floor box.
Coupe model: Pull on the lever
A.
Roadster model: Push the upper portion of the
power seatback tilt switch
B.Return the passenger’s seatback to a locked
position after using the rear floor box.
Coupe model: Pull up on the lever
Aand return
the seatback.
Roadster model: Push the lower portion of the
power seatback tilt switch
B.
SIC3010
SSS0203
Coupe model
SIC3348
Roadster model
Instruments and controls
2-35


06.10.24/Z33-D/V5.0


The rear floor box may be opened by pulling the
handle. The rear floor box light illuminates when
the box lid is opened with the headlight switch
ON.
When locking
1
or unlocking
2
the rear floor
box, use the master key.The rear floor box has additional space under the
bottom plate.
WARNING
Keep rear floor box lid closed while
driving to help prevent injury in an acci-
dent or a sudden stop.
REAR PARCEL BOXPush the upper part of the lid to open the rear
parcel box. For models without the Navigation
system, two boxes are available.
WARNING
Keep rear parcel box lid closed while
driving to help prevent injury in an acci-
dent or a sudden stop.
SIC1975A
SIC2377
SIC1977
2-36
Instruments and controls


06.10.24/Z33-D/V5.0


STOWING GOLF BAGSFollow the instructions here to stow golf bags in
the rear cargo space of your vehicle. Normally
two bags can be stowed in the luggage area
(Coupe models) or one bag in the trunk (Road-
ster models).
However, in some cases you may not be able to
stow the above number of golf bags in your
vehicle, depending on their sizes or types.
Coupe modelsNormally, two standard golf bags can be stowed
across the strut tower bar in the luggage area as
illustrated (A and B). When stowing a golf bag A
in the rear space, insert the top of the golf baginto left side of the luggage area
1then put the
bag down
2.
SIC2196
Instruments and controls
2-37


06.10.24/Z33-D/V5.0


Roadster modelsNormally, one standard golf bag C can be
stowed in the trunk. Insert the top of the golf bag
into left side of the trunk
1
then put the bag
down
2.
COAT HOOK (Coupe models)The hooks are locked above the side windows
as shown in the illustration.
CAUTION
Do not apply a total load of more than 2
lb (1 kg) to a single hook.
POWER WINDOWS
WARNING

Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.

Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
The power windows operate when the ignition
key is in the ON position and for about 45
seconds, after the ignition key is turned to the
OFF position. If the driver’s door or the front
passenger’s door is opened during this period of
about 45 seconds, power to the windows is
canceled.
The power window switches will be deactivated
during the soft top operation. (Roadster models)
SIC2237
SIC2378
WINDOWS
2-38
Instruments and controls


06.10.24/Z33-D/V5.0


Driver’s side power window switch1. Driver side window
2. Passenger side window
3. Window lock button
To open or close the window, push down
A
or
pull up
B
the switch and hold it. The main
switch (driver side switches) will open or close
all the windows.
Passenger side power window switchThe passenger side switch will open or close
only the corresponding window. To open or
close the window, hold the switch down or up.Locking passenger’s windowWhen the lock button
C
is pushed in, only the
driver side window can be opened or closed.
Push it in again to cancel.
Automatic operationTo fully open or close the window, completely
press or lift the switch and release it; it need not
be held. The window will automatically open or
close all the way. To stop the window, just press
or lift the switch on the opposite side.Auto reverse functionIf the control unit detects something caught in a
window as it moves up, the window will be
immediately lowered.
The auto reverse function can be activated when
a window is closed by automatic operation when
the ignition key is in the ON position or for about
SIC3286
SIC3287
SIC3288
Instruments and controls
2-39


06.10.24/Z33-D/V5.0


45 seconds after the ignition key is turned to the
OFF position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-
side the vehicle before closing the win-
dow.Automatic window lowering (Roadster
models)When the soft top operating switch is pressed,
the power windows will automatically be low-
ered completely. The windows do not rise auto-
matically after the soft top open/close operation
is completed. Use the power window switches
to raise them.
AUTOMATIC ADJUSTING
FUNCTION
CAUTION
When the battery cable is removed from
the battery terminal, do not close either
of the front doors. The automatic win-
dow adjusting function will not work,
and the side roof panel/top side rail
may be damaged.
The power window has an automatic adjusting
function. When the door is being opened, the
window is automatically lowered slightly to avoid
contact between the window and the side roof
panel/top side rail. When the door is closed, the
window is automatically raised slightly.
ROOM LIGHTThe interior light has a two-position switch. (
A:
DOOR,
B: OFF)
When the switch is in the DOOR position, the
light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:

The doors are unlocked by the keyfob, a key
or the power door lock switch while all doors
are closed.

The driver’s door is opened and then closed
while the key is removed from the ignition
switch.
SIC1980A
Coupe models
INTERIOR LIGHTS
2-40
Instruments and controls


06.10.24/Z33-D/V5.0


The key is removed from the ignition switch
while all doors are closed.
The interior light will turn off while the 30 second
timer is activated, when:

The driver’s door is locked either with the
keyfob, a key or the power door lock switch.

The ignition switch is turned ON.MAP LIGHTSTo turn on the light, push the plastic surface
C
of the light. Push it again to turn off the light.
When the map light stays on, it will auto-
matically turn off 30 minutes after theignition switch has been turned to the OFF
position. To turn on the light again, turn the
ignition switch to the ONposition.
The map and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operation
of the following with the ignition switch in the
ACC or OFF position:

Opening or closing any door

Locking or unlocking with the keyfob, a key or
the power door lock switch

Inserting or removing a key from the ignition
switch
These lights will turn on again when any of the
above operations is performed after the lights
have turned off automatically. (The lights will turn
off 30 minutes after the latest operation of the
above as well.)
CAUTION

Turn off the lights when you leave the
vehicle.

Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.The light on the vanity mirror will turn on when
the cover on the vanity mirror is opened.
When the vanity mirror light stays on, it will
automatically turn off 30 minutes after the
ignition switch has been turned to the OFF
position. To turn on the light again, turn the
ignition switch to the ONposition.
SIC2238
Roadster models
SIC1859
VANITY MIRROR LIGHT
Instruments and controls
2-41


06.10.24/Z33-D/V5.0
