2007 NISSAN 350Z check engine

LAN-48
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
CAN System Specification ChartNKS004PU
Determine CAN system type from the following specification chart. Then choose the correct diagnosis sheet.
NOTE:
Refer to LAN-19, "
CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION
CHART)" for how to use CAN system specification chart.
VEHICLE EQUIPMENT IDENTIFICATION INFORMATION
NOTE:
Check CAN system type from the vehicle shape and equipment.
Body type Coupe/Roadster
Axle2WD
EngineVQ35HR
Transmission M/T A/T M/T A/T
Brake control ABS TCS VDC
CAN system type 12345
Diagnosis sheetLAN-59
LAN-60LAN-61LAN-62LAN-63
CAN communication signal chartLAN-49, "TYPE
1"LAN-50, "TYPE 2/TYPE 3"LAN-51, "TYPE 4/TYPE 5"
PKID1090E

LAN-50
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
NOTE:
CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.
TYPE 2/TYPE 3
NOTE:
Refer to LAN-41, "
Abbreviation List" for the abbreviations of the connecting units.
T: Transmit R: Receive Low beam status signal R T
Rear window defogger control signal R TSignal name/Connecting unit
ECM
BCM
M&A
ABS
IPDM-E
Signal name/Connecting unitECM
TCM
BCM
M&A
ABS
IPDM-E
A/C compressor feedback signal T R
A/C compressor request signal TR
Accelerator pedal position signal T R R
ASCD CRUISE lamp signal T R
ASCD OD cancel request signal T R
ASCD operation signal T R
ASCD SET lamp signal T R
Battery voltage signal T R
Closed throttle position signal T R
Cooling fan speed request signal TR
Engine coolant temperature signal T R
Engine speed signal T R R R
Fuel consumption monitor signal T R
Malfunction indicator lamp signal T R
Wide open throttle position signal T R
A/T CHECK indicator lamp signal T R
A/T position indicator signal T R R
A/T self-diagnosis signal R T
Manual mode gear position signal T R
Manual mode indicator signal T R
Output shaft revolution signal R T
Turbine revolution signal R T
A/C switch signal R T
Blower fan motor switch signal R T
Buzzer output signal T R
Day time running light request signal T R
Door switch signal T R R
Front wiper request signal T R
High beam request signal T R R
Horn chirp signal T R
Ignition switch signal T R
Low beam request signal T R
Position lights request signal T R R

LAN-52
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Closed throttle position signal T R
Cooling fan speed request signal TR
Engine coolant temperature signal T R
Engine speed signal T R R R
Fuel consumption monitor signal T R
Malfunction indicator lamp signal T R
Wide open throttle position signal T R
A/T shift schedule change demand signal T R
ABS operation signal T R
ABS warning lamp signal T R
Brake warning lamp signal T R
SLIP indicator lamp signal T R
VDC OFF indicator lamp signal T R
Vehicle speed signalTR
RRRT
A/T CHECK indicator lamp signal T R
A/T position indicator signal R T R
A/T self-diagnosis signal R T
Manual mode gear position signal T R
Manual mode indicator signal T R
Output shaft revolution signal R T
Turbine revolution signal R T
A/C switch signal R T
Blower fan motor switch signal R T
Buzzer output signal T R
Day time running light request signal T R
Door switch signal T R R
Front wiper request signal T R
High beam request signal T R R
Horn chirp signal T R
Ignition switch signal T R
Low beam request signal T R
Position lights request signal T R R
Rear window defogger switch signal T R
Sleep request 1 signal T R
Sleep request 2 signal T R
Theft warning horn request signal T R
Tire pressure signal T R
Turn indicator signal T R
Wake up request 1 signal T R
Fuel level sensor signal R T
Manual mode shift down signal R T
Manual mode shift up signal R TSignal name/Connecting unit
ECM
ABS
TCM
BCM
M&A
STRG
IPDM-E
