GLASSES, WINDOW SYSTEM & MIRRORS
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Battery Service ................................ 3
Precautions for Procedures without Cowl Top Cover ..... 3
Handling for Adhesive and Primer ........................... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINING ..................................... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
WINDSHIELD GLASS ...............................................11
Removal and Installation ......................................... 11
REMOVAL (COUPE) ............................................ 11
REMOVAL (ROADSTER) ................................... 12
INSTALLATION ................................................... 12
BACK DOOR WINDOW GLASS .............................. 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15SIDE WINDOW GLASS ............................................ 16
Removal and Installation ........................................ 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 17
POWER WINDOW SYSTEM .................................... 18
Component Parts and Harness Connector Location ... 18
System Description ................................................. 19
MANUAL OPERATION ........................................ 19
POWER WINDOW SERIAL LINK ....................... 20
AUTO OPERATION ............................................. 20
POWER WINDOW LOCK ................................... 20
RETAINED POWER OPERATION ...................... 20
ANTI-PINCH SYSTEM ........................................ 21
POWER WINDOW CONTROL BY THE KEY
CYLINDER SWITCH ........................................... 21
AUTOMATIC WINDOW ADJUSTING FUNC-
TION .................................................................... 21
Schematic ............................................................... 22
Wiring Diagram — WINDOW — ............................. 23
Terminal and Reference Value for BCM ................. 26
Terminal and Reference Value for Power Window
Main Switch ............................................................ 27
Terminal and Reference Value for Power Window
Sub-Switch ............................................................. 28
CONSULT-III Function (BCM) ................................ 29
WORK SUPPORT ............................................... 29
DATE MONITOR ................................................. 29
ACTIVE TEST ..................................................... 29
Work Flow ............................................................... 30
Trouble Diagnoses Symptom Chart ....................... 30
Check BCM Power Supply and Ground Circuit ...... 32
Check Drive Side Power Window Motor Circuit ..... 33
Check Passenger Side Power Window Motor Cir-
cuit .......................................................................... 33
Check Limit Switch Circuit (Driver Side) ................. 34
Check Limit Switch Circuit (Passenger Side) ......... 36
Check Encoder Circuit (Driver Side) ....................... 37
Check Encoder Circuit (Passenger Side) ............... 39
Check Door Switch ................................................. 42
Check Power Window Serial Link ........................... 44

PRECAUTIONS
GW-3
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NIS00049
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Battery ServiceNIS0004A
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Precautions for Procedures without Cowl Top CoverNIS001L6
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Handling for Adhesive and PrimerNIS0004B

Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.

Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

Open the seal of the primer and adhesive just before application. Discard the remainder.

Before application, be sure to shake the primer container to stir the contents. If any floating material is
found, do not use it.

If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
soap.

When using primer and adhesive, always observe the precautions in the instruction manual.
PIIB3706J

GW-4
PREPARATION
Revision: 2006 November2007 350Z
PREPARATIONPFP:00002
Special Service ToolsNIS0004D
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsNIS0004E
Tool number
(Kent-Moore No.)
Tool nameDescription
(J39570)
Chassis earLocating the noise
(J43980)
NISSAN Squeak and
Rattle KitRepairing the cause of noise
SIIA0993E
SIIA0994E
Tool name Description
Engine ear Locating the noise
Suction lifterRemove the windshield,
back door window glass
SIIA0995E
PIIB1805J

SQUEAK AND RATTLE TROUBLE DIAGNOSES
GW-5
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 November2007 350Z
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowNIS0004F
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to GW-9, "
Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.

The customer may not be able to provide a detailed description or the location of the noise. Attempt to
obtain all the facts and conditions that exist when the noise occurs (or does not occur).

If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
is concerned about. This can be accomplished by test driving the vehicle with the customer.

After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.

Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping

Creak—(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
dependent on materials/often brought on by activity.

Rattle—(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.

Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.

Tick—(Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.

Thump—(Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.

Buzz—(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.

Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
judge as acceptable may be very irritating to the customer.

Weather conditions, especially humidity and temperature, may have a great effect on noise level.
SBT842

GW-6
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2006 November2007 350Z
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle “twist”.
5) At idle, apply engine load (electrical load, half-clutch on M/T models, drive position on A/T models).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.

Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.

If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1. Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
(Chassis Ear: J-39570, Engine Ear and mechanics stethoscope).
2. Narrow down the noise to a more specific area and identify the cause of the noise by:

removing the components in the area that you suspect the noise is coming from.
Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
or lost during the repair, resulting in the creation of new noise.

tapping or pushing/pulling the component that you suspect is causing the noise.
Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
temporarily.

feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
noise.

placing a piece of paper between components that you suspect are causing the noise.

looking for loose components and contact marks.
Refer to GW-7, "
Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE

If the cause is a loose component, tighten the component securely.

If the cause is insufficient clearance between components:
–separate components by repositioning or loosening and retightening the component, if possible.
–insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape or ure-
thane tape. A Nissan Squeak and Rattle Kit (J-43980) is available through your authorized Nissan Parts
Department.
CAUTION:
Do not use excessive force as many components are constructed of plastic and may be damaged.
NOTE:
Always check with the Parts Department for the latest parts information.
The following materials are contained in the Nissan Squeak and Rattle Kit (J-43980). Each item can be
ordered separately as needed.
URETHANE PADS [1.5 mm (0.059 in) thick]
Insulates connectors, harness, etc.
76268-9E005: 100×135 mm (3.94×5.31 in)/76884-71L01: 60×85 mm (2.36×3.35 in)/76884-
71L02: 15×25 mm (0.59×0.98 in)
INSULATOR (Foam blocks)
Insulates components from contact. Can be used to fill space behind a panel.
73982-9E000: 45 mm (1.77 in) thick, 50×50 mm (1.97×1.97 in)/73982-50Y00:
10 mm (0.39 in) thick, 50×50 mm (1.97×1.97 in)

GW-30
POWER WINDOW SYSTEM
Revision: 2006 November2007 350Z
Work FlowNIS0004T
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to GW-19, "
System Description" .
3. According to the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to GW-30,
"Trouble Diagnoses Symptom Chart" .
4. Does power window system operate normally? If Yes, GO TO 5, If No, GO TO 3.
5. INSPECTION END
Trouble Diagnoses Symptom ChartNIS0004U

Make sure that other systems using the signal of the following check systems operate normally.
Symptom Diagnoses / service procedureReference
page
None of the power windows can be operated using any
switch.1. Check BCM power supply and ground circuitGW-32
2. Check power window main switch power supply and
ground circuitGW-46
3. Check power window serial linkGW-44
4. Replace BCM.BCS-17
Driver side power window cannot be operated1.Check driver side power window motor circuitGW-332. Replace the power window main switch.GW-46
Passenger side power window cannot be operated.1. Check power window sub-switch power supply and
ground circuitGW-472. Check power window serial linkGW-44
3. Check passenger side power window motor circuitGW-33
4. Replace BCM.BCS-17
Anti-pinch system does not operate normally (driver
side).1. Door window sliding part malfunction

A foreign material adheres to window glass or grass
run rubber.

Glass run rubber wear or deformation.

Sash is tilted too much, or not enough.—
2. Limit switch adjustingGW-52
3. Check limit switch circuit (driver side)GW-34
4. Check encoder circuit (driver side)GW-37
Anti-pinch system does not operate normally (passenger
side).1. Door window sliding part malfunction

A foreign material adheres to window glass or grass
run rubber.

Glass run rubber wear or deformation.

Sash is tilted too much, or not enough.—
2. Limit switch adjustingGW-52
3. Check limit switch circuit (passenger side)GW-36
4. Check encoder circuit (passenger side)GW-39
Power window retained power operation does not oper-
ate properly.1. Check the retained power operation mode setting.GW-292. Check door switchGW-42
3. Replace BCM.BCS-17

POWER WINDOW SYSTEM
GW-31
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 November2007 350Z
Automatic window adjusting function does not operate.1. Check door switchGW-42
2. Limit switch adjustingGW-52
3. Check limit switch circuit (driver side)GW-34
4. Check limit switch circuit (passenger side)GW-36
5. Check power window serial linkGW-44
6. Replace BCM.BCS-17
Does not operate by the key cylinder switch.1. Check door key cylinder switchGW-482. Replace the power window main switch.EI-33
Power window lock switch does not function.1. Check power window serial linkGW-442. Replace the power window main switch.EI-33
Auto operation does not operate but manual operate
normally (driver side)1. Check encoder circuit (driver side)GW-37
2. Replace power window main switchEI-33
Auto operation does not operate but manual operate
normally (passenger side)1. Check encoder circuit (passenger side)GW-39
2. Replace power window sub-switchEI-33
Symptom Diagnoses / service procedureReference
page

REAR WINDOW DEFOGGER
GW-69
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 November2007 350Z
Work FlowNIS0005P
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to GW-56, "
System Description" .
3. According to the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to GW-69,
"Trouble Diagnoses Symptom Chart" .
4. Does rear window defogger operate normally? YES: GO TO 5, NO: GO TO 4.
5. INSPECTION END
Trouble Diagnoses Symptom ChartNIS0005Q
Make sure that other systems using the signal of the following systems operate normally.
*1 : For Coupe
*2 : For RoadsterSymptom Diagnoses / service procedure Refer to page
Rear window defogger does not operate.1. CAN communication inspection using CONSLUT-III
(self-diagnosis)BCS-16
2. Check IPDM E/R operationGW-70
3. Check rear window defogger switch circuitGW-70
4. Check rear window defogger power supply circuitGW-71
5. Replace IPDM E/R.PG-26
Rear window defogger does not response but door mir-
ror defoggers operate.1. Check rear window defogger circuitGW-73*1
GW-74*2
2. Check filamentGW-78
Both of door mirror defoggers do not response but rear
window defogger operates.Check door mirror defogger power supply circuitGW-75
Driver side door mirror defogger does not operate. Check driver side door mirror defogger circuitGW-76
Passenger side door mirror defogger does not operate. Check passenger side door mirror defogger circuitGW-76
