BCM (BODY CONTROL MODULE)
BCS-17
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: 2006 November2007 350Z
Removal and Installation of BCMNKS0009T
REMOVAL
1. Remove the dash side finisher (LH). Refer to EI-35, "BODY
SIDE TRIM" .
2. Disconnect BCM connector.
3. Remove bracket mounting screws to remove BCM and fuse
block with bracket.
4. Raise the pawl of fuse block and remove bracket from fuse block
to remove BCM.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
When replacing BCM perform initialization of NATS system and registration of all NATS ignition key IDs.
SKIA1918E
SKIA1919E
