BCM (BODY CONTROL MODULE)
BCS-15
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: 2006 November2007 350Z
CONSULT-III Function (BCM)NKS0009R
CONSULT-III can display each diagnostic item using the diagnostic test mode shown following.
ITEMS OF EACH PART
NOTE:
CONSULT-III displays systems equipped in the vehicle.
×: Applicable
NOTE:
This item is displayed, but should not be used.BCM diagnostic test item Check item, diagnostic test mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
SELF-DIAG RESULTS BCM performs self-diagnosis of CAN communication.
DATA MONITOR Displays the input data of BCM in real time.
ACTIVE TEST Gives a drive signal to a load to check the operation.
CAN DIAG SUPPORT MNTRThe result of transmit/receive diagnosis of CAN com-
munication can be read.
ECU PART NUMBER BCM part number can be read.
System and item CONSULT-III displayDiagnostic test mode (Inspection by part)
WORK
SUPPORTSELF−
DIAG
RESULTSDATA
MONI-
TORCAN
DIAG
SUP-
PORT
MNTRACTIVE
TESTECU
PA RT
NUM-
BERCON-
FIGU-
RATION
BCM BCM×× × ×
×
NOTE
Power door lock system DOOR LOCK×××
Rear window defogger REAR DEFOGGER××
Warning chime BUZZER××
Room lamp timer INT LAMP×××
Remotecontrol entry system MULTI REMOTE ENT×××
Headlamp HEAD LAMP×××
Wiper WIPER×××
Turn signal lamp
Hazard lampFLASHER××
Blower fan switch signal
A/C switch signalAIR CONDITONER×
Combination switch COMB SW×
NVIS IMMU××
Interior lamp battery saver BATTERY SAVER×× ×
Trunk lid TRUNK××
Vehicle security system THEFT ALM×××
Retained power control RETAINED PWR×××
Oil pressure switch SIGNAL BUFFER
×
NOTE×
Low tire pressure warning
system AIR PRESSURE
MONITOR××× ×
Panic alarm system PANIC ALARM×
BCS-16
BCM (BODY CONTROL MODULE)
Revision: 2006 November2007 350Z
WORK SUPPORT
Display Item List
CAN Communication Inspection Using CONSULT-III (Self-Diagnosis)NKS0009S
1. SELF-DIAGNOSIS RESULT CHECK
Contents displayed
No malfunction>>INSPECTION END
Malfunction in CAN communication system>>After printing the monitor items, go to “CAN System”. Refer to
LAN-48, "
CAN System Specification Chart" .
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
CONSULT-III display code Diagnosis item
U1000INITIAL DIAG
TRANSMIT DIAG
ECM
IPDM E/R
METER / M&A
