2007 NISSAN 350Z engine

AT-78
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
54
OthersJudder occurs during
lock-up.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT- 1 0 6
4. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 9
5. Accelerator pedal position sensorAT- 1 3 1
6. CAN communication lineAT- 9 4
7. Torque converter clutch solenoid valveAT- 1 2 5
8. Control valve with TCMAT- 2 1 5
OFF vehicle 9. Torque converterAT- 2 5 5
55Strange noise in “R”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 5
6. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
8. High and low reverse clutchAT- 2 8 6
9. Reverse brakeAT- 2 5 5
56Strange noise in “N”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 56. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
57Strange noise in “D”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 5
6. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
8. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-79
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z58
OthersVehicle does not
decelerate by engine
brake.
Refer to AT-202,
"Vehicle Does Not
Decelerate by Engine
Brake" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Input clutchAT-2768. High and low reverse clutchAT-286
9. Direct clutchAT-288
59Engine brake does
not work M5 → M4 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Front brake (brake band)AT-255
60Engine brake does
not work M4 → M3 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
61Engine brake does
not work M3 → M2 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
9. High and low reverse clutchAT-286
No. Items Symptom Condition Diagnostic ItemReference
page

AT-80
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
62
OthersEngine brake does
not work M2 → M1 .ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Manual mode switchAT- 1 5 7
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Input clutchAT- 2 7 68. High and low reverse clutchAT- 2 8 6
9. Direct clutchAT- 2 8 8
63 Maximum speed low.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. CAN communication lineAT- 9 4
5. Direct clutch solenoid valveAT- 1 4 9
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Torque converterAT- 2 5 5
8. Oil pump assemblyAT- 2 7 1
9. Input clutchAT- 2 7 6
10. Gear systemAT- 2 4 6
11. High and low reverse clutchAT- 2 8 6
12. Direct clutchAT- 2 8 8
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-sectional View" .)AT- 2 5 5
14 Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
64Extremely large
creep.ON vehicle1. Engine idle speed EC-76

2. CAN communication lineAT- 9 4
OFF vehicle 3. Torque converterAT- 2 5 5
65With selector lever in
“P” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.ON vehicle1. PNP switchAT- 1 0 2
2. A/T positionAT- 2 0 6
3. Parking pawl componentsAT- 2 4 6
66Vehicle runs with A/T
in “P” position.ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Control valve with TCMAT- 2 1 5
5. Parking pawl componentsAT- 2 4 6
OFF vehicle 6. Gear systemAT- 2 4 6
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-81
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
67
OthersVehicle runs with A/T
in “N” position.
Refer to AT-174, "In
“N” Position, Vehicle
Moves" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Control valve with TCMAT-215
OFF vehicle5. Input clutchAT-276
6. Gear systemAT-246
7. Direct clutchAT-288
8. Reverse brakeAT-255
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
10. Low coast brake (Parts behind drum support is impossi-
ble to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
68Engine does not start
in “N” or “P” position.
Refer to AT-173, "Engine Cannot Be
Started in “P” or “N”
Position" .ON vehicle1. Ignition switch and starterPG-4
,
SC-8
2. A/T positionAT-206
3. PNP switchAT-102
69Engine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Ignition switch and starterPG-4
,
SC-8
2. A/T positionAT-206
3. PNP switchAT-102
70 Engine stall.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT-106
4. Torque converter clutch solenoid valveAT-125
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Torque converterAT-255
71Engine stalls when
selector lever shifted
“N” → “D”, “R”.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT-106
4. Torque converter clutch solenoid valveAT-125
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Torque converterAT-255
No. Items Symptom Condition Diagnostic ItemReference
page

AT-82
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
72 OthersEngine speed does
not return to idle.
Refer to AT-195,
"Engine Speed Does
Not Return to Idle" .ON vehicle1. A/T fluid level and stateAT- 4 9
2. Direct clutch solenoid valveAT- 1 4 9
3. Front brake solenoid valveAT- 1 4 7
4. Accelerator pedal position sensorAT- 1 3 1
5. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 9
6. CAN communication lineAT- 9 4
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Front brake (brake band)AT- 2 5 59. Direct clutchAT- 2 8 8
No. Items Symptom Condition Diagnostic ItemReference
page

AT-84
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
CONSULT-III Function (TRANSMISSION)NCS0002E
CONSULT-III can display each diagnostic item using the diagnostic test mode shown following.
FUNCTION
CONSULT-III REFERENCE VALUE
NOTICE:
1. The CONSULT-III electrically displays shift timing and lock-up timing (that is, operation timing of each
solenoid).
Check for time difference between actual shift timing and the CONSULT-III display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-III and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-III indicates the point where shifts are completed.
3. Display of solenoid valves on CONSULT-III changes at the start of shifting, while gear position is dis-
played upon completion of shifting (which is computed by TCM).
Diagnostic test mode Function
Work supportThis mode enables a technician to adjust some devices faster and more accurately by following the
indications on CONSULT-III.
Self-diagnostic results Self-diagnostic results can be read and erased quickly.
Data monitor Input/Output data in the ECU can be read.
CAN diagnostic support monitor The results of transmit/receive diagnosis of CAN communication can be read.
Function testPerformed by CONSULT-III instead of a technician to determine whether each system is “OK” or
“NG”.
DTC work support Select the operating condition to confirm Diagnosis Trouble Codes.
ECU part number TCM part number can be read.
Item name Condition Display value (Approx.)
ATF TEMP SE 1
0°C (32° F) – 20°C (68°F) – 80°C (176°F)3.3 – 2.7 – 0.9 V
ATF TEMP SE 23.3 – 2.5 – 0.7 V
ATF TEMP 1 Ignition switch ONMeasured ATF temperature is dis-
played.
TCC SOLENOID Lock-up is active 0.4 – 0.6 A
SLCT LVR POSISelector lever in “N” and “P” positions. N/P
Selector lever in “R” position. R
Selector lever in “D” position. D
VHCL/S SE-A/T During drivingApproximately matches the speed-
ometer reading.
VEHICLE SPEED During drivingApproximately matches the speed-
ometer reading.
ENGINE SPEED Engine runningClosely matches the tachometer
reading.
LINE PRES SOL During driving 0.2 – 0.6 A
TURBINE REV During driving (lock-up ON)Approximately matches the engine
speed.
VHCL/S SE-MTR During drivingApproximately matches the speed-
ometer reading.
ATF PRES SW 2Low coast brake engaged. Refer to AT- 1 9
.ON
Low coast brake disengaged. Refer to AT- 1 9
.OFF

AT-86
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
SELF-DIAGNOSTIC RESULT MODE
After performing self-diagnosis, place check marks for results on the AT- 4 4 , "DIAGNOSTIC WORKSHEET" .
Reference pages are provided following the items.
Display Items List
X: Applicable, —: Not applicable
Items (CONSULT-III
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIIMIL
*1 ,
“ENGINE” with
CONSULT-III
or GST
CAN COMM CIRCUITWhen TCM is not transmitting or receiving CAN communica-
tion signal for 2 seconds or more.U1000 U1000AT- 9 4
STARTER RELAY/
CIRCIf this signal is ON other than in “P” or “N” position, this is
judged to be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be
a malfunction.)P0615 —AT- 9 7
TCM TCM is malfunctioning P0700 P0700AT- 1 0 1
PNP SW/CIRC

PNP switch 1–4 signals input with impossible pattern.

“P” position is detected from “N” position without any other
position being detected in between.P0705 P0705AT- 1 0 2
TURBINE REV S/CIRC

TCM does not receive the proper voltage signal from the
sensor.

TCM detects an irregularity only at position of 4th gear for
turbine revolution sensor 2.P0717 P0717AT- 1 0 6
VEH SPD SEN/CIR AT

Signal from vehicle speed sensor A/T (Revolution sensor)
not input due to cut line or the like.

Unexpected signal input during running.

After ignition switch is turned ON, unexpected signal input
from vehicle speed sensor MTR before the vehicle starts
moving.P0720 P0720AT- 1 0 8
ENGINE SPEED SIGTCM does not receive the CAN communication signal from
the ECM.P0725 P0725AT- 11 3
A/T 1ST GR FNCTN A/T cannot shift to 1st gear P0731 P0731AT- 11 5
A/T 2ND GR FNCTN A/T cannot shift to 2nd gear P0732 P0732AT- 11 7
A/T 3RD GR FNCTN A/T cannot shift to 3rd gear P0733 P0733AT- 11 9
A/T 4TH GR FNCTN A/T cannot shift to 4th gear P0734 P0734AT- 1 2 1
A/T 5TH GR FNCTN A/T cannot shift to 5th gear P0735 P0735AT- 1 2 3
TCC SOLENOID/CIRCNormal voltage not applied to solenoid due to cut line, short,
or the like.P0740 P0740AT- 1 2 5
A/T TCC S/V FNCTN

A/T cannot perform lock-up even if electrical circuit is
good.

TCM detects as irregular by comparing difference value
with slip rotation.P0744
P0744*2AT- 1 2 7
L/PRESS SOL/CIRC

Normal voltage not applied to solenoid due to cut line,
short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P0745 P0745AT- 1 2 9
TP SEN/CIRC A/TTCM does not receive the proper accelerator pedal position
signals (input by CAN communication) from ECM.P1705 P1705AT- 1 3 1
ATF TEMP SEN/CIRC During running, the A/T fluid temperature sensor signal volt-
age is excessively high or low.P1710 P0710AT- 1 3 4

TROUBLE DIAGNOSIS
AT-87
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z

*1: Refer to AT- 3 9 , "Malfunction Indicator Lamp (MIL)" .

*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL. VEH SPD SE/CIR-MTR

Signal (CAN communication) from vehicle speed sensor
MTR not input due to cut line or the like.

Unexpected signal input during running.P1721 —AT-139
A/T INTERLOCKExcept during shift change, the gear position and ATF pres-
sure switch states are monitored and comparative judgment
made.P1730 P1730AT-141
A/T 1ST E/BRAKINGEach ATF pressure switch and solenoid current is monitored
and if a pattern is detected having engine braking 1st gear
other than in the M
1 position, a malfunction is detected.P1731 —AT-143
I/C SOLENOID/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1752 P1752AT-145
FR/B SOLENOID/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1757 P1757AT-147
D/C SOLENOID/CIRC

Normal voltage not applied to solenoid due to cut line,
short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1762 P1762AT-149
HLR/C SOL/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1767 P1767AT-151
LC/B SOLENOID/CIRCNormal voltage not applied to solenoid due to functional mal-
function, cut line, short, or the like.P1772 P1772AT-153
LC/B SOLENOID FNCT

TCM detects an improper voltage drop when it tries to
operate the solenoid valve.

Condition of ATF pressure switch 2 is different from moni-
tor value, and relation between gear position and actual
gear ratio is irregular.P1774
P1774*2AT-155
MANU MODE SW/
CIRCWhen an impossible pattern of switch signals is detected, a
malfunction is detected.P1815 —AT-157
NO DTC IS DETECTED
FURTHER TESTING
MAY BE REQUIREDNo NG item has been detected. X X — Items (CONSULT-III
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIIMIL
*1 ,
“ENGINE” with
CONSULT-III
or GST
