ATC-108
BLOWER UNIT
Revision: 2006 November2007 350Z
BLOWER UNITPFP:27200
Removal and InstallationNJS0001K
REMOVAL
1. Remove remote keyless entry receiver. Refer to BL-92, "Removal and Installation of Remote Keyless
Entry Receiver" .
2. Remove mounting nuts (A), and then remove ECM (1) with
bracket attached.
3. Disconnect intake door motor and blower motor connector (B).
4. Remove mounting screws (C) and bolt (D), and then remove
blower unit (2).
CAUTION:
Move blower unit rightward, and remove location pin (1
part) and joint. Then remove blower unit downward.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure location pin (1 part) and joint are securely inserted.
PJIA0171E
RJIA1414E
