ATC-102
A/C CONTROLLER
Revision: 2006 November2007 350Z
A/C CONTROLLERPFP:27500
Removal and InstallationNJS0001E
REMOVAL
1. Remove console finisher (A/T) or console boot (M/T). Refer to IP-10, "INSTRUMENT PANEL ASSEM-
BLY" .
2. Remove mounting screws (A) and clips (B), and then remove A/
C controller (1) from console finisher (A/T) or console boot (M/
T).
INSTALLATION
Installation is basically the reverse order of removal.
Disassembly and AssemblyNJS000CT
NOTE:
When disassembling controller, wind gummed tape around each dial assembly and pull out the dial assembly
together with switch from the A/C controller assembly.
SJIA1084J
1. A/C controller assembly 2. Mode control dial 3. Rear window defogger switch
4. Intake switch 5. A/C switch 6. Fan control dial
7. Temperature control dial
SJIA1903E
AUTO AMP
ATC-103
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
AUTO AMPPFP:27760
Removal and Installation of Unified Meter and A/C Amp.NJS0001F
REMOVAL
1. Remove console finisher (A/T) or console boot (M/T). Refer to IP-10, "INSTRUMENT PANEL ASSEM-
BLY" .
2. Remove mounting screws, and then remove unified meter and
A/C amp.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA1409E
