2007 MINI Hardtop 2 Door Owner's Manual

ReferenceAt a glance Controls Driving tips Mobility
127

Reference Controls
Driving tips
Mobility At a glance
Reference

Technical data
130
Technical data
Engine data
MINI CooperMINI Cooper S
Displacement cu in/cmµ1,598 1,598
Number of cylinders 4 4
Maximum power output hp 118 172
at engine speed rpm 6,000 5,500
Maximum torque
with overboost functionlb ft/Nm 114/155
–177/240
192/260
at engine speed
with overboost functionrpm 4,250
–1,600-5,000
1,700-4,500

ReferenceAt a glance Controls Driving tips Mobility
131
Dimensions
All dimensions given in inches/mm. Smallest turning circle diam.: 35 ft 10 in/10.7 m.
Figures following the semicolon: values that differ for the MINI Cooper S.

Technical data
132
Weights
Never exceed either the approved axle loads or
the gross vehicle weight.
MINI CooperMINI Cooper S
Curb weight, ready for travel, with all optional extras
>Manual transmission lbs/kg 2,546/1,155 2,668/1,210
>Automatic transmission lbs/kg 2,634/1,195 2,723/1,235
Approved gross weight
>Manual transmission lbs/kg 3,362/1,525 3,483/1,580
>Automatic transmission lbs/kg 3,450/1,565 3,538/1,605
Approved front axle load lbs/kg 1,929/875 1,984/900
Approved rear axle load lbs/kg 1,653/750 1,664/755
Approved roof load capacity lbs/kg 165/75 165/75
Cargo area capacity cu ft/l 5.7/160 5.7/160

ReferenceAt a glance Controls Driving tips Mobility
133
Capacities
US gal/US quartsLitersNotes
Fuel tank Fuel grade: page85
>MINI Cooper 10.6/– approx. 40
>MINI Cooper S 13.2/– approx. 50
including reserve of 2.1/– approx. 8
Window washer system incl.
headlamp washer system –/4.8 approx. 4.5For more details:
page42

From A to Z
134
From A to Z
Index
A
ABS Antilock Brake System54
Accessories, refer to Your
individual vehicle5
Activated-charcoal filter for
automatic climate control68
Additives
– coolant96
– engine oil96
Adjusting temperature inside
the car, refer to Air
conditioner65
Adjusting temperature inside
the car, refer to Automatic
climate control66
Airbags57
– sitting safely28
– warning lamp58
Air conditioner64
Air conditioning mode
– air conditioner65
– automatic climate control66
– ventilation68
Air distribution
– automatic67
– individual65
– manual65
Air flow rate65,66
– air conditioning system65
– automatic climate control66
– heating, ventilation65
Airing, refer to Ventilation68
Air outlets, refer to Air vents64
Air pressure, checking, refer to
Tire inflation pressure86
Air recirculation, refer to
Recirculated-air
mode65,67
Air supply
– air conditioner65
– automatic climate control66
– ventilation68Air vents64
AKI, refer to Fuel
specifications85
Alarm system, preparation
package24
Alarm system preparation
package24
All-season tires, refer to Winter
tires93
All-Season Traction Control
ASC54
Ambient air, refer to
Recirculated-air
mode65,67
Âmbient lighting63
Antenna, care100
Antifreeze
– coolant96
– washer fluid
42
Anti-theft system19
Approved axle loads, refer to
Weights132
Approved engine oils96
Approved gross vehicle
weight, refer to Weights132
Armrest, refer to Center
armrest71
Arrival time
– computer46
ASC All-Season Traction
Control54
Ashtray72
Assistant systems, refer to
– All-Season Traction Control
ASC54
– Dynamic Stability Control
DSC54
AUC Automatic recirculated-
air control67
Audio device, external71Automatic
– air distribution67
– air flow rate67
– cruise control42
– headlamp control59
Automatic climate control64
– automatic air distribution67
Automatic recirculated-air
control AUC67
Automatic transmission with
Steptronic37
– interlock37
– overriding selector lever
lock39
– shiftlock38
– sport program38
AUTO program for automatic
climate control67
AUX-In, refer to External audio
device71
Average fuel consumption45
– setting the units47
Average speed46
Axle loads, refer to
Weights132
B
Background lighting, refer to
Ambient lighting63
Backrests, refer to Seats28
Backup lamps
– replacing bulb105
Backup lamps, refer to Tail
lamps105
Band-aids, refer to First aid
pouch112
Bar, refer to Tow-starting,
towing away114
