2007 MERCEDES-BENZ SL-Class navigation system

153 Navigation
Route guidance
Important map symbols:
Current vehicle location and direction
of travel y
If the map orientation
2D Heading Up
(page 169) is chosen, the arrow will
always point upward.
The remaining route section is
highlighted in blue color.
Display example 2:On the right side of the display, the symbol
for the next driving maneuver is indicated
(here: right turn).
On the very right side next to turn symbol
is the distance bar. It indicates the
distance to the next driving maneuver
(here: 300 ft).
The status bar shows the name of the
street after the driving maneuver, if
available, here:
PARK AVE
The destination is marked with a flag $ on
the map, an intermediate destination is
marked with a flag showing the letter
S.
Altering the map scale
The current map scale is indicated on the
left side of the status bar.
Press any soft key.
The soft key displays appear.
i
The colored highlight only appears
when the system has completed the
route calculation.
i
Using the multifunction steering wheel
buttons, the display unit can be
changed between km or miles (see
your vehicle’s Operator’s Manual).
When the display unit is set to
miles, the COMAND will indicate
distances in miles (mi) or feet (ft).
When the display unit is set to km,
the COMAND will indicate
distances in kilometers (km) or
meters (m).
i
If no other action is taken within
approx. 8 seconds, the soft key
displays will disappear again.

157 Navigation
Route guidance
Route guidance to an off-road destina-
tionCOMAND can guide you to destinations
within the area covered by the digital map,
even if a destination is not located at a
road known to the system.
These destinations are shown as off-road
destinations, which you can enter using
the map, for example.
In these cases, COMAND guides you for as
long as possible with navigation announce-
ments and displays on roads known to the
system.
Shortly before you reach the last known
point in the digitized road network, you will
hear the announcement “The destination
is nearby. Follow the arrow on the display”.
You will then see an arrow that indicates
the direction to the off-road destination.
When the off-road destination is close to
the road, “Area of dest. reached” appears
in addition below the arrow.The section of the route from the last
known point on the map to the off-road
destination is highlighted blue. It simply
shows the direction to the off-road
destination without taking into account
any type of obstacles in the way.
1Current vehicle position, the triangle
indicates the vehicle’s direction of
travel
2Off-road section of the route
3Off-road destination
4Direction arrow, shows compass
heading to destination, the distance to
destination and
OFF ROAD indication
Off-road and off-map
WarningG
The COMAND navigation system may direct
you to off-road routes that your vehicle may
not be capable of traversing through without
damaging your tires, wheels or vehicle. It is
the driver's sole responsibility to determine
the suitability of the route. Off-road routes
may be of varying conditions and their ap-
propriateness for use may be affected by va-
rious factors such as time of day, time of
year and immediate weather conditions that
cannot be judged or taken into considerati-
on by the COMAND system.

158 Navigation
Route guidance
On the off-road section of the route, direc-
tion arrows showing the compass heading
to the destination guide you. You will also
see the “Direction to destination” display.
Route guidance from an off-road
location to a destination
If there is no road available on map at cur-
rent position of the car, vehicle is off road.
COMAND is also able to guide you to a des-
tination from such a location.
At the start of the route guidance, you will
see the “Off Road” message and a direc-
tion arrow. The direction arrow shows the
compass heading to the actual destina-
tion.
The route is highlighted blue from the
nearest road known to the system.
As soon as the vehicle is back on a road
known to the system, route guidance con-
tinues in the usual way.Route guidance from an off-map
location to a destination
If the vehicle position is outside the area
covered by the digital map, then the vehi-
cle is in an off-map location.
COMAND is also able to guide you to a des-
tination from such a location.
At the start of the route guidance, you will
see the “Off Map” message and a direction
arrow. The direction arrow shows the com-
pass heading to the actual destination.
The route is highlighted blue from the near-
est road known to the system.
As soon as the vehicle is back on a road
known to the system, route guidance con-
tinues in the usual way.Off-road during route guidance
The road layout may differ from the data on
the digital map, due to road construction
measures, for example.
In such cases, the system cannot allocate
the vehicle’s position to the digital map
and the vehicle is therefore in an off-road
position.
The “Off Road” message and an arrow
showing the compass heading to the
destination appear on the display.
As soon as the system can allocate the
vehicle position’s to the map again, route
guidance continues in the usual way.

161 Navigation
During route guidance
Available soft keys
Route soft key:
Brings you to the route display on the
map.
Mode soft key:
Brings you to the route mode selection
menu (
page 132).
Setting soft key:
Brings you to the audio settings for the
navigation announcements
(
page 133).Displaying the route on the map
In the Info menu (page 160), press
the
Route soft key.
The map will appear. The route ahead
is blue-colored.
The destination is marked with a flag $
on the map, a stopover destination is
marked with a flag showing the letter
S.
Displaying the route list
In the Info menu (page 160), press
the
Route soft key.
The route appears on the map.
Press the List soft key.
The list of the remaining roads/route
sections appears.
The road currently travelled on is at the
top of the list.
Press G or g to scroll through the
list.
Use the
Page V and Page v soft keys
to display the next or previous page.
i
If a stopover destination has been
entered:
The estimated time of arrival and the
remaining distance to the destination
are displayed.
When the stopover destination is
reached, the system calculates the
route to the main destination and
indicates estimated time of arrival and
remaining distance.
i
Depending on the distance to the
destination, it may take some time
before the route display appears. i
Depending on the distance to the
destination, it may take a few moments
before the route list is completed.
The list will only be complete when the
route is completely calculated. This is
indicated by the word
Destination in
front of the last list entry.

162 Navigation
During route guidance
With the via function you can influence
how the route is calculated.
Example:
You wish to travel from Chicago to New
York. You can use the via function to define
whether the route will lead via Cleveland or
Pittsburgh.
In the Info menu (page 160), press
the
Route soft key.
The route is shown on the map.
Press the Via soft key.If the via function is not yet active, you may
now select a via route.
If the via function is already active, the
message
Via Already Active will
appear. You can delete (
page 163) or
change (
page 163) the via route.
Selecting a via route
You can select one via route at a time.
Press G or g to select a list entry.
Press E.
The system calculates the new route.
Via function (soft key via)
i
The Via soft key has no function if the
route cannot offer any via routes.
i
The selection list always refers to the
currently active route.
Example:
You have entered a main and a
stopover destination. First, the system
will calculate your route to the stopover
destination, so that route is the active
route.
The selection list only shows possible
via routes to the stopover destination.

163 Navigation
During route guidance
Deleting the active via route
Press g to select option Delete
Active Via
.
Press E.
The system deletes the via route and
recalculates the route to the
destination.Changing the active via route
Press g to select option Change
Active Via
.
Press E.
The list for selecting another via route
appears.
Use G or g to select the desired via
route.
Press E.
The system recalculates the route.The detour function blocks a route section
ahead. If possible, the system will
calculate a detour. You can adjust the
length of the route section to be blocked.
Switching on
Activate the soft key display (page 160).
Press the Detour soft key.i
If you enter a new destination, the sys-
tem will automatically delete any active
via route.
Selecting a detour
i
If the system does not allow you to
block a route section, the message
No
Detour Possible
is displayed.
Traffic jams are identified by the driver,
not by the COMAND. The detour
function may also be possible if the
vehicle is traveling on a road that does
not appear on the DVD.
i
If you have already placed a block on a
route section,
Detour appears written
in black. A menu will appear instead of
the map (
page 164).

164 Navigation
During route guidance
You can now enter the length of the route
section to be blocked.
Press the More soft key until the
desired length is set.
Press the Less soft key to reduce the
length of the traffic jam.
Press E.
The system calculates a new route
around the blocked route section.Switching off
Activate the soft key display by
pressing any soft key (
page 160).
Press the Detour soft key.
Press g to select Delete Detour.
Press E.
The blocked route section is deleted.
The system calculates the new route.Changing the blocked route section
Activate the soft key display
(
page 160).
Press the Detour soft key.
Use G to select item Reset Detour.
Press E.
You can now change the length of the
route section to be blocked.
Press the More soft key until the
desired length is set.
Press the Less soft key to reduce the
length of the blocked route section.
Press E.
The system calculates a new route
around the blocked route section.
i
The route directly in front of the current
position can be blocked in the range of
0 to 6.2 miles.

165 Navigation
During route guidance
This function allows you to select an
intermediate destination while route
guidance is active. A stopover destination
may be a gas station or a restaurant or any
other place. When the stopover
destination is reached, the system
calculates the route to the main
destination.
Entering a stopover destination
Activate the soft key display
(
page 160).
Press the St-over soft key.
The map is displayed in full view.Available soft keys
 soft key:
Shows a list of Mercedes-Benz Centers
near your location.
 soft key:
Shows a list of filling stations around
you.
 soft key:
Shows a list of parkings and multi-
storey car parks around you.
 soft key:
Shows a list of restaurants around you.
 soft key:
Shows a list of hospitals around you.
More soft key:
If you press this soft key, the
Navigation main menu will appear.
Enter Stopover will appear on the
status bar.
You can now enter an stopover
destination by
selecting one from the destination
memory (
page 172)
typing one in the Destination Entry
menu (
page 137)
selecting one in the Last
destinations
memory
(
page 171)
selecting a POI (page 176)
Stopover function
