2007 MERCEDES-BENZ S CLASS service indicator

ContentsOperation......................................... 477
The first 1000 miles (1500 km) ......... 478
Driving instructions ............................ 479
Drive sensibly – save fuel ............. 479
Drinking and driving ..................... 479
Pedals .......................................... 479
Power assistance ......................... 479
Brakes .......................................... 480
Driving off..................................... 481
Parking ......................................... 481
Tires ............................................. 482
Hydroplaning ................................ 483
Tire traction .................................. 483
Tire speed rating .......................... 484
Winter driving instructions ........... 484
Standing water ............................. 485
Passenger compartment .............. 486
Driving abroad .............................. 486
Control and operation of radio
transmitters.................................. 486
Catalytic converter ....................... 487
Emission control........................... 488
Coolant temperature .................... 488At the gas station .............................. 489
Refueling ...................................... 489
Check regularly and before
a long trip ..................................... 490
Engine compartment ......................... 492
Hood ............................................ 492
Engine oil ..................................... 494
Transmission fluid level ................ 497
Active Body Control* (ABC*)
fluid level...................................... 497
Coolant level ................................ 497
Windshield washer system and
headlamp cleaning system ........... 498
Tires and wheels ................................ 500
Important guidelines .................... 500
Tire care and maintenance ........... 501
Direction of rotation ..................... 503
Loading the vehicle ...................... 503
Recommended tire inflation
pressure ....................................... 509
Checking tire inflation pressure ... 511
Tire labeling.................................. 518
Load identification ....................... 521DOT, Tire Identification Number
(TIN) ............................................. 522
Maximum tire load ....................... 523
Maximum tire inflation pressure .. 523
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 524
Tire ply material ........................... 525
Tire and loading terminology........ 526
Rotating tires ............................... 529
Winter driving .................................... 530
Winter tires .................................. 530
Snow chains................................. 531
Maintenance...................................... 532
Maintenance service indicator
message ...................................... 532
Calling up the maintenance
service indicator display .............. 533
Resetting the maintenance
service indicator .......................... 533
Vehicle care....................................... 534
Cleaning and care of vehicle ........ 534

75 Safety and Security
Anti-theft systems
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating
With the SmartKey: Remove the
SmartKey from the starter switch.

With the KEYLESS-GO*: Turn off the
engine (
page 317) and open the driv-
er’s door.
Deactivating

Switch on the ignition (
page 315).
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens:

a door


the trunk


the hood
The alarm will stay on even if the activating
element (a door, for example) is immedi-
ately closed.
The alarm system will also be triggered
when


the vehicle is raised


the vehicle is opened with the
mechanical key


a door is opened from the inside
To cancel the alarm after it has been trig-
gered, see “Canceling the alarm”
(
page 76).1Indicator lamp

Arming: Lock your vehicle with the
SmartKey or KEYLESS-GO*.
The turn signal lamps flash three times
to indicate that the alarm system is ac-
tivated. The indicator lamp1 flashes
to indicate that the alarm system is
armed.
i
Starting the engine will also deactivate the
immobilizer.
In case the engine cannot be started (yet the ve-
hicle’s battery is charged), the system is not op-
erational. Contact an authorized Mercedes-Benz
Center or call 1-800-FOR-MERCedes (in the
USA), or 1-800-387-0100 (in Canada).
i
If the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 462) provided Tele Aid service was sub-
scribed to and properly activated, and that nec-
essary mobile phone, power supply and GPS
coverage are available.


253 Control systems
Instrument cluster control system
Switching on the Dynamic Rear View
Monitor* automatically
Press ( or & to select the
“Assistance” menu.

Press % or $ to select the
“Rearview camera” function.

Press #.

Press # again if you would like to
change the current status.The following settings are available:
Service menu
The “Service” menu is used for

calling up messages


checking tire inflation pressure elec-
tronically with the Advanced TPMS*
(standard on U.S. vehicles)


activating Run Flat Indicator
(Canada only)


calling up the maintenance service in-
dicator display


check engine oil level*Calling up vehicle malfunction, warning
and system status messages stored in
memory
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.
The vehicle status message memory menu
only appears if there are any messages
stored.
i
The image from the Dynamic Rear View
Monitor is shown on the COMAND display.
“On when in
Reverse”
The Dynamic Rear View
Monitor automatically
switches on when reverse
gear is engaged.
“OFF”
The Dynamic Rear View
Monitor is not switched on.
i
The menu overview can be found on
(
page 243).
Warning!
G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks


254 Control systemsInstrument cluster control system
Press ( or & to select the
“Service” menu.
If conditions have occurred causing
status messages to be recorded, the
number of messages appears in the
multifunction display: “2 Messages”.

Press % or $ to select the mes-
sage.

Press # to confirm.Checking tire inflation pressure
For information about checking tire infla-
tion pressure (
page 511).
Activating Run Flat Indicator*
For information about activating Run Flat
Indicator (
page 515).
Calling up the maintenance service in-
dicator display
For information about maintenance
(
page 532).
Checking engine oil level (S 600)*
For information about checking engine oil
level (
page 494).
Settings menu
In the “Settings” menu, you can:

switch the daytime driving lamps on or
off


switch the additional speedometer on
or off


switch the radar sensors* on or off.
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 557).
i
See the “Practical hints” section for mal-
function and warning messages (
page 557).
i
If you turn the SmartKey in the starter
switch to position0 and then back to position2,
all messages will be deleted from the message
memory.
i
The menu overview can be found on
(
page 243).


362 Controls in detailDriving and parking
For more information, see “Driving instruc-
tions” (
page 479).
Turn signalsCombination switch1Turn signals, right
2Turn signals, left

Press the combination switch up1 or
down2.
The corresponding turn signal indicator
lampL orK flashes in the in-
strument cluster (
page 28).
The combination switch resets automati-
cally after major steering wheel move-
ments.
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.Warning!
G
It is dangerous to shift the gear selector le-
ver out of P or N if the engine speed is high-
er than idle speed. If your foot is not firmly
on the brake pedal, the vehicle could accel-
erate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.!
Shift the automatic transmission toP or R
only when the vehicle is stopped in order to avoid
damaging the transmission.
!
Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the en-
gine.
!
Simultaneously depressing the accelerator
pedal and applying the brake reduces engine
performance and causes premature brake and
drivetrain wear.
i
To signal minor directional changes, e.g.
passing or changing lanes, move combination
switch to point of resistance only and release.
The corresponding turn signal flashes three
times.


464 Controls in detailUseful featuresThe Tele Aid system is available if

it has been activated and is operation-
al. Activation requires a subscription
for monitoring services, connection,
and cellular air time


the relevant mobile phone and GPS
coverage are available and pass the in-
formation on to the Response Center


there is sufficient voltage in the vehicle
batteries
Initiating an emergency call manually
1SOS button
2Cover

Briefly press button on cover2 to
open.
Cover 2 will open.

Press SOS button1 (for longer than
2 seconds).
The indicator lamp in SOS button1
will flash until the emergency call is
concluded.

Wait for a voice connection to the
Response Center.

Close cover2 after the emergency
call is concluded.
i
Location of the vehicle on a map is only pos-
sible if the vehicle is able to receive signals from
the GPS satellite network and pass the informa-
tion on to the Response Center.Warning!
G
If the indicator lamp in the SOS button is
flashing continuously and there was no
voice connection to the Response Center
established, then the Tele Aid system could
not initiate an emergency call (e.g. the rele-
vant mobile phone network is not available).
The message:

“Call failed” appears in the multifunction
display for approximately 10 seconds


A pop-up window with the message:
“Call could not be connected! Please dial
911 directly using the mobile telephone
keypad.” appears in the COMAND dis-
play. Confirm the message pressing
n

(
page 82).
Should this occur, assistance must be sum-
moned by other means.
Warning!
G
If you feel at any way in jeopardy when in the
vehicle (e.g. smoke or fire in the vehicle, ve-
hicle in a dangerous road location), please
do not wait for voice contact after you have
pressed the emergency button. Carefully
leave the vehicle and move to a safe loca-
tion. The Response Center will automatically
contact local emergency officials with the

466 Controls in detailUseful features
Information button¡
Press and hold Information button
¡ (for longer than 2 seconds).
A call to the Customer Assistance Cen-
ter will be initiated. The button will
flash while the call is in progress. The
message:

“Connecting call” appears in the
multifunction display


“Information Call Activated” ap-
pears in the COMAND display
and the audio system is muted.
When the connection is established, the
message:


“Call connected” appears in the multi-
function display


“Information Call Activated” appears in
the COMAND display
The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. Information regarding the operation
of your vehicle, the nearest authorized
Mercedes-Benz Center or Mercedes-Benz
USA products and services is available to
you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only).
i
The indicator lamp in the Roadside Assis-
tance button• remains illuminated in red for
approximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Information
button¡).
See system self-check (
page 462) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Roadside Assistance
button• is flashing continuously and no
voice connection to the Response Center was
established, the Tele Aid system could not ini-
tiate a Roadside Assistance call (e.g. the relevant
mobile phone network is not available). The mes-
sage:


“Call failed” appears in the multifunction dis-
play for approximately 10 seconds


“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing
n
(page 82).
Roadside Assistance calls can be terminated us-
ing button t on the multifunction steering
wheel or COMAND (page 115).
i
The indicator lamp on the Information
button¡ remains illuminated in red for ap-
proximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Roadside Assis-
tance button•).
See system self-check (
page 462) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Information
button¡ is flashing continuously and no
voice connection to the Response Center was
established, then the Tele Aid system could not
initiate an Information call (e.g. the relevant

467 Controls in detail
Useful features
Destination Download to the COMAND
System
Destination Download allows you access
to a database of over 10,000,000 Points Of
Interest (POIs) that can be downloaded to
your vehicle's navigation system. If you
know the destination the address can be
downloaded. Or if you are unsure of your
destination you can be provided with
Points Of Interests near your location.
The Response Center can transmit desti-
nation data to the COMAND during the
connection with the Roadside Assistance
or Customer Assistance Center.
The transmitted data can contain address
details for a Mercedes-Benz Center or POIs
(Points of Interest).Route guidance
A prompt appears for confirmation if route
guidance to the address is to be started.

Slide rmq or rotate ymz to select
“Yes” menu item and confirm by
pressingn.
The system starts the route calculation
and subsequently the route guidance
to the defined address (
page 140).
Call priority
If other service calls such as a Roadside
Assistance call or Information call are ac-
tive, an emergency call is still possible. In
this case, the emergency call will take pri-
ority and override all other active calls.
mobile phone network is not available). The mes-
sage:

“Call failed” appears in the multifunction dis-
play for approximately 10 seconds


“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing n (
page 82).
Information calls can be terminated using button
t on the multifunction steering wheel or
COMAND (
page 115).
!
If the indicator lamps do not start flashing
after pressing one of the buttons or remain illu-
minated (in red) at any time, the Tele Aid system
has detected a fault or the service is not current-
ly activated, and may not initiate a call. Visit an
Mercedes-Benz Center and have the system
checked or contact the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada) as soon as possi-
ble.
i
The components and operating principles of
COMAND can be found on (
page 79).
i
If you select “No”, you can save the address
in your address book (
page 202).
i
The destination download feature is avail-
able if the relevant mobile phone network is
available and data connection is possible.
