41 Getting started
Unlocking
SmartKey with KEYLESS-GO*
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function and a
removable KEYLESS-GO start/stop
button.
With the KEYLESS-GO start/stop button
inserted and the SmartKey with
KEYLESS-GO present in the vehicle, press-
ing the KEYLESS-GO start/stop button

without the brake pedal depressed
corresponds to the various starter
switch positions (
page 42)


with the brake pedal firmly depressed
will start the engine (
page 54)
If you wish or should there be a need to
insert the SmartKey with KEYLESS-GO in
the starter switch, the KEYLESS-GO
start/stop button can be easily removed
by pulling it out of the starter switch.1KEYLESS-GO start/stop button
2Starter switch
KEYLESS-GO start/stop button3USA only
4Canada only
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Insert KEYLESS-GO start/stop
button1 into starter switch2 (if not
inserted already).

Make sure the automatic transmission
is set toP (
page 187).

Do not depress the brake pedal.
i
The KEYLESS-GO start/stop button does
not need to be removed from the starter switch
when you leave the vehicle. However, always
take the SmartKey with KEYLESS-GO with you
when you leave the vehicle. As long as the
SmartKey with KEYLESS-GO is in the vehicle, the
vehicle’s electrical systems can be switched on
or the engine can be started using the
KEYLESS-GO start/stop button.

42 Getting startedUnlockingPosition 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have status0 (as with
SmartKey removed).
Position 1
Press the KEYLESS-GO start/stop
button once.
This supplies power for some electrical
consumers, such as seat adjustment.Ignition (or Position 2)

Press the KEYLESS-GO start/stop
button twice.
This supplies power for all electrical
consumers.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If
a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 414).For information on starting the engine
using the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 55).
For more information on KEYLESS-GO, see
“SmartKey with KEYLESS-GO*”
(page 112).
i
If you now press the KEYLESS-GO
start/stop button


once more, the ignition (position
2) is
switched on


twice more, the power supply is again
switched off
i
If you now press the KEYLESS-GO
start/stop button once more, the power supply
is again switched off.
i
When you switch on the ignition, the
indicator and warning lamps (except high beam
headlamp indicator lamp and turn signal indica-
tor lamps unless activated) in the instrument
cluster come on. The indicator and warning
lamps (except high beam headlamp indicator
lamp and turn signal indicator lamps if activated)
should go out when the engine is running. This
indicates that the respective systems are
operational.

46 Getting startedAdjustingHead restraint fore and aft adjustment
Manually adjust the angle of the head
restraint.
While seated, reach behind you with
both hands and find lower edge of the
head restraint.

Adjust the head restraint to the desired
position by pushing or pulling on the
lower edge of the head restraint cush-
ion.
For more information, see “Seats”
(
page 128).
Steering wheel
Easy-entry/exit feature*
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the steering wheel is in
its uppermost position.
The easy-entry/exit feature can be
activated or deactivated in the
Comfort

submenu of the control system
(
page 177).With the easy-entry/exit feature activated,
the steering wheel will return to its last set
position when you:


close the driver’s door with the ignition
switched on
or


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 41) once
with the driver’s door closed
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:

Move steering wheel adjustment stalk*
(page 49).


Press one of the memory position
buttons or the memory buttonM*
(page 135).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

47 Getting started
Adjusting
With the easy-entry/exit feature activated,
the steering wheel tilts upwards when you:

remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button in position1 (
page 41)Steering wheel adjustment, manualMake sure that


you can reach the steering wheel with
your arms slightly bent at the elbows


you can move your legs freely


all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
The steering wheel adjustment release
handle is located on the lower left of the
steering column.
i
The last set steering wheel position is stored
when


the ignition is switched off (
page 39)


the position is stored in memory
(page 135)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
The adjustment procedure is briefly interrupted,
when the engine is started.
Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All steering wheel adjustment must be
completed before setting the vehicle in mo-
tion. Driving off with the steering wheel still
adjusting could cause the driver to lose con-
trol of the vehicle.Warning!
G
Only adjust the steering wheel with the vehi-
cle at a standstill and make sure the steer-
ing wheel is securely locked in place before
driving off.
Driving without the steering wheel adjust-
ment locked may cause an unexpected
steering wheel movement which could
cause the driver to lose control of the vehi-
cle. Make sure the steering wheel is secure-
ly locked by trying to move it up and down,
and in and out before driving off.

48 Getting startedAdjusting1Release handle
To unlock the steering column, pull
release handle1 out to its stop limit.

Move steering wheel to the desired
position.

Push release handle1 back to its
original position to relock the steering
column.
The steering column is locked into po-
sition again.

Make sure the steering column is
securely locked by trying to move the
steering wheel up and down as well as
in and out before driving off.Steering wheel adjustment, electrical*
Make sure that


you can reach the steering wheel with
your arms slightly bent at the elbows


you can move your legs freely


all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
The steering wheel adjustment stalk is
located on the lower left of the steering
column.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the steering
wheel adjustment feature can be operated
when the driver’s door is open. Therefore,
do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
i
The memory function* (
page 134) lets
you store the settings for the steering wheel col-
umn together with the settings for seat positions
and the exterior rear view mirrors.

55 Getting started
Driving
Starting with the SmartKey
For information on turning off the engine
with the SmartKey, see “Turning off the en-
gine” (
page 66).
Gasoline engine

Make sure the automatic transmission
is set toP.
The transmission position indicator in
the multifunction display should be
on
P (page 147).

Do not depress the accelerator.

Turn the SmartKey in the starter switch
to position3 (
page 39) and hold until
the engine starts.Diesel engine

Make sure the automatic transmission
is set toP.
The transmission position indicator in
the multifunction display should be
on
P (page 147).

Do not depress the accelerator.

Turn the SmartKey in the starter switch
to position2 (
page 40).
Preglow indicator lampqin the
instrument cluster comes on.

As soon as preglow indicator
lampq goes out, turn the SmartKey
in the starter switch to position3
(page 40) and release it.
The engine starts automatically.Starting with KEYLESS-GO*
You can start your vehicle without the
SmartKey in the starter switch using the
KEYLESS-GO start/stop button in the
starter switch.
The SmartKey with KEYLESS-GO must be
located in the vehicle.
i
You can also use the “touch-start” function.
Turn the SmartKey to position3 and release it
again immediately. The engine then starts auto-
matically.
i
If the engine is at operating temperature,
preglow indicator lampqmay not stay on
and you can start the engine without preglowing.
Warning!
G
As long as the SmartKey with KEYLESS-GO
is in your vehicle, the vehicle can be started.
Therefore, never leave children unattended
in the vehicle, as they could otherwise acci-
dentally start the engine.
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle.

56 Getting startedDrivingKEYLESS-GO start/stop button1USA only
2Canada only
Make sure KEYLESS-GO start/stop
button1 is inserted in the starter
switch (
page 41).
For information on turning off the engine
with KEYLESS-GO, see “Turning off with
KEYLESS-GO*” (
page 67).Gasoline engine

Make sure the automatic transmission
is set toP.
The transmission position indicator in
the multifunction display should be
on
P (page 147).

Depress the brake pedal during the
starting procedure.

Do not depress the accelerator.

Press KEYLESS-GO start/stop
button1 once.
The engine starts if the SmartKey with
KEYLESS-GO is in the vehicle.Diesel engine

Make sure the automatic transmission
is set toP.
The transmission position indicator in
the multifunction display should be
on
P.

Depress the brake pedal during the
starting procedure.

Do not depress the accelerator.

Press KEYLESS-GO start / stop
button1 once.
The engine preglows and starts if the
SmartKey with KEYLESS-GO is in the
vehicle.
i
If you wish to start the engine using the
SmartKey instead of the KEYLESS-GO feature,
remove the KEYLESS-GO start/stop button from
the starter switch (
page 41).
i
If the engine is at operating temperature,
the time the engine needs to preglow is reduced.

57 Getting started
Driving
Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.

If you are starting the engine with
KEYLESS-GO*: Close any doors that
may be open to allow for better
detection of the SmartKey with
KEYLESS-GO*.
Or:

Remove KEYLESS-GO* start/stop
button from starter switch (
page 41).

Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO*.

Repeat the starting procedure
(page 54). Remember that extended
starting attempts can drain the battery.

Get a jump start (
page 515).
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.

Notify an authorized Mercedes-Benz
Light Truck Center.
Parking brake
1Parking brake pedal
2Release handle

Release the parking brake by pulling on
release handle2.
The warning lamp; (USA only)
or3(Canada only) in the
instrument cluster goes out.Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake, which could result in an acci-
dent and/or serious injury.
