61 Getting started
Driving
Switching on windshield wipers
Turn the combination switch to the
desired position depending on the
intensity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wipingIntermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.
When you select intermittent wiping, the
rain sensor is activated. The rain sensor
automatically sets a suitable wiping
interval depending on the wetness of the
sensor surface.

Turn the combination switch to
positionU orV.After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe

Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.


Remove blockage.


Turn the windshield wipers on again.
If windshield wipers fail to function at all in
combination switch positionU orV,


set the combination switch to the next
higher wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Light
Truck Center
!
Do not leave windshield wipers in intermit-
tent setting when the vehicle is taken to an auto-
matic car wash or during windshield cleaning.
Wipers will operate in the presence of water
sprayed on the windshield, and windshield
wipers may be damaged as a result.
!
If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
i
Intermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when


all doors are closed
and


the automatic transmission is set to
positionD orR
or


the wiper setting is changed using the
combination switch

62 Getting startedDrivingWiping with windshield washer fluid
Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 363).
Rear window wiper/washer
The combination switch is located on the
left of the steering column.Combination switch1Rear window wiper switch
2Wiping rear window with washer fluid
3Intermittent wiping
4Rear window wiper off
5Wiping rear window with washer fluid6Rear window wiper indicator

Switch on the ignition (
page 40).
Activating intermittent wipe

Turn rear window wiper switch1 to
position3 (
page 62).
In the lower multifunction display you
will see indicator6, indicating that
the rear window wiper is activated.
i
To prevent smears on the windshield, wipe
with windshield washer fluid every now and then
even when it is raining.
i
The rear window wiper engages automatical-
ly when the automatic transmission is shifted to
positionR with the windshield wipers switched
on.

362 OperationEngine compartmentTransmission fluid level
The transmission fluid level does not need
to be checked. If you notice transmission
fluid loss or gear shifting malfunctions,
have an authorized Mercedes-Benz Light
Truck Center check the automatic trans-
mission.Coolant level
The engine coolant is a mixture of water
and anticorrosion/antifreeze. To check
the coolant level, the vehicle must be
parked on level ground.
The coolant expansion tank is located on
the driver’s side of the engine compart-
ment.1Cap
2Coolant expansion tank
3Indicator wall
4Coolant level

Using a rag, turn cap1 slowly approx-
imately one half turn counterclockwise
to release any excess pressure.
Warning!
G
In order to avoid potentially serious burns:

Use extreme caution when opening the
hood if there are any signs of steam or
coolant leaking from the cooling system,
or if the coolant temperature gauge indi-
cates that the coolant is overheated.


Do not remove pressure cap on coolant
reservoir if coolant temperature is
above 158°F (70°C). Allow engine to
cool down before removing cap. The
coolant reservoir contains hot fluid and
is under pressure.


Using a rag, slowly open the cap approx-
imately
1/2 turn to relieve excess pres-
sure. If opened immediately, scalding
hot fluid and steam will be blown out un-
der pressure.


Do not spill antifreeze on hot engine
parts. Antifreeze contains ethylene gly-
col which may burn if it comes into con-
tact with hot engine parts.

543 Technical data
Fuels, coolants, lubricants
Fuels, coolants, lubricants
Capacities
Vehicle components and their respective
lubricants must match. Therefore only use
products tested and approved by
Mercerdes-Benz.
Please refer to the Factory Approved
Service Products pamphlet, or inquire at
your Mercedes-Benz Light Truck Center.
Warning!
G
Comply with all valid regulations with re-
spect to handling, storing and disposing of
service fluids. Otherwise you could
endanger persons or the environment.
Keep service fluids out of the reach of
children.
If a service fluid is swallowed, contact a
physician immediately.
Model
Capacity
Fuels, coolants, lubricants, etc.
Engine with oil filter
ML 320 CDI
9.5 US qt (9.0 l)
Approved engine oils
ML 350
8.5 US qt (8.0 l)
Approved engine oils
ML 500
9.0 US qt (8.5 l)
Approved engine oils
ML 63 AMG
10.3 US qt (9.7 l)
Approved engine oils
Automatic transmission
All models
9.5 US qt (9.0 l)
MB Automatic Transmission Fluid
Transfer case single speed
All models
0.53 US qt (0.5 l)
MB Automatic Transmission Fluid

554 IndexAutomatic climate control (3-zone)* 220
Air conditioning, Cooling 230, 231
Air distribution, Front 226
Air distribution, Rear 234
Air recirculation mode 228
Air vents, Front 226
Air volume 227
Control panel, Front 222
Control panel, Rear 232
Deactivating system 224
Defogging 227
Defrosting 227
Maximum cooling, MAX COOL 228
Rear passenger compartment 232
Rear window defroster 205
Residual engine heat (REST) 232
Using driver-side settings for
all temperature zones 231
Automatic headlamp mode 137
Automatic lighting control, Interior
lighting 143
Automatic locking when driving 126
Automatic shift program
(ML 63 AMG only) 196Automatic transmission 54
Accelerator position 191
Automatic shift program
(ML 63 AMG only) 196
Emergency operation
(Limp-Home Mode) 198
Gear ranges 193
Gear selector lever 54, 185
Gear shifting malfunctions 198
Hill start assist system 192
Kickdown 191
Kickdown, manual shift program
(ML 63 AMG only) 198
Manual shift progam
(ML 63 AMG only) 196
Program mode selector switch
(ML 63 AMG only) 195
Shift program (ML 63 AMG only) 195
Shifting procedure 188
Starting the engine 54
Steering wheel gearshift control 194
Towing a trailer 192
Transmission fluid level 362
Transmission positions 189
Automatic Transmission Fluid see ATFB
Backrest
Seat 44
Seat, Lumbar support 130
Seat, Multicontour* 130
Backup lamps
Messages in the
multifunction display 458
Replacing bulbs 490
Bar 395
BAS 97
Lamps in instrument cluster 414
Messages in the
multifunction display 430
Basic carrier bars* 281
Batteries, SmartKey
Check lamp 108, 112
Checking battery condition 111
Messages in the
multifunction display 446
Replacing 480
Battery, Vehicle 507
Charging 514
Disconnecting and connecting 509
Jump starting 515
Removing and installing 509

560 IndexETD 80, 423
Safety guidelines 73
Expanding cargo compartment 284
Exterior rear view mirrors 49, 201
Folding 202
Power folding* 202
Synchronizing 202
F
Fastening the seat belts 51
Filler neck, Engine oil
(ML 350, ML 320 CDI) 361
Filler neck, Engine oil
(ML 500, ML 63 AMG) 361
First aid kit 469
Flat tire 497
Collapsible tire
(ML 63 AMG only) 474, 538
Lifting the vehicle 498
Lowering the vehicle 504
Minispare wheel
(except ML 63 AMG) 473
Mounting the spare wheel 498
Preparing the vehicle 498
Spare wheel 538Flexible Service System PLUS see FSS
PLUS
Floormats* 303
Fluids
Automatic transmission fluid 362
Brake fluid 354, 544, 546
Capacities 543
Engine coolant 354, 362, 549
Engine oil 358, 546
Power steering fluid 544
Windshield washer and
headlamp cleaning system* 355,
545, 551
Fog lamps 139
Corner-illuminating front fog
lamps* 140
Messages in the
multifunction display 458
Rear fog lamp 139
Replacing bulbs 488
4-ETS 102
Off-road - 4-ETS 102Front air bags 75
Front defroster 213, 227
Front lamps see Headlamps
Front passenger front air bag 70, 75
Messages in the multifunction
display 440, 441, 442, 443
Front passenger front air bag off indicator
lamp 31, 89, 426, 427
Front seat heat restraints see
Head restraints
Front towing eye 520
FSS PLUS (Canada vehicles) 361, 402
Fuel 353
Additives 547
Capacities, Fuel tank 545
Consumption statistics 180, 181
Diesel fuel 545
Filling the tank 352
Fuel filler flap and cap 352, 477
Fuel gauge 29
Fuel tank reserve warning lamp 29,
420
Premium unleaded gasoline 353,
547, 548
Requirements, Octane rating 548

566 IndexMON 353, 548
Multicontour seat* 130
Multifunction display 147
Changing settings see Control
system menus and Control system
submenus
Selecting display 168
Selecting language 167
Multifunction display messages 428
ABS 430
Air suspension package* 467
Brake fluid 449
Brake lamps 458
Brake pads 447
Check engine 449
Coolant 452
Cruise control 431
Distronic* 432
Doors 455
Downhill Speed Regulation 447
EBP 448
Engine coolant 450, 452
Engine oil 453
ESP
®
419Fog lamps, Front 458
Fog lamps, Rear 461
Front passenger front air bag 440,
441, 442, 443
Fuel cap 455
Gear selector lever 438
Headlamps 458, 460, 461, 463
Hood 455
Key, SmartKey 457
Key, SmartKey with
KEYLESS-GO* 456, 457
Lamps 458, 460, 461, 463
Low tire pressure 444, 465, 466
Parking brake 438, 448
Parking lamps 459
Tele Aid* 464
Telephone* 464
Turn signals 463
Vehicle battery 446
Windshield washer fluid 464
Multifunction steering wheel 30, 148
Button operation 148N
Navigation system* 161
See separate COMAND system
operating instructions
Net, Parcel 297
Net, Partition* 287
Neutral gear position, Automatic
transmission 185, 189
New vehicle, Break-in period 324
Night security illumination 139, 172
Normal occupant weight 396
Number, Vehicle Identification (VIN) 530
O
Occupant distribution 396
Occupant safety 70
Active head restraint 80
Air bags 71
Children and air bags 73, 82, 84
Children in the vehicle 82
Fastening the seat belt 51
Front passenger front air bag off
indicator lamp 86, 89, 90
Infant and child restraint systems 82
