164 Controls in detailControl systemShould the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display

when the SmartKey in the starter
switch is turned to position0 or
removed from the starter switch.
or


when you turn off the engine by
pressing the KEYLESS-GO* start/stop
button (
page 67) in the starter
switch once and open the driver’s door
(this puts the starter switch in
position0, same as with the SmartKey
removed from the starter switch)
Settings menu
In the
Settings
menu there are two
functions:


The function
Reset to factory
settings?
, with which you can reset all
the settings to the original factory
settings.


A collection of submenus with which
you can make individual settings for
your vehicle.

Press buttonè orÿ repeatedly
until the
Settings
menu appears in the
multifunction display.The following settings and submenus are
available in the
Settings
menu:
i
The vehicle status message memory will be
cleared when you turn the SmartKey in the start-
er switch to position1 or2, or when you press
the KEYLESS-GO* start/stop button once or
twice without depressing the brake pedal. You
will then only see high priority messages in the
multifunction display (
page 428).
Function
Page
Resetting all settings
165
Submenus in the settings menu
165
Instrument cluster submenu
167
Time/date submenu
169
Lighting submenu
171
Vehicle submenu
174
Comfort submenu*
177

165 Controls in detail
Control system
Resetting all settings
You can reset the functions of all
submenus to the factory settings.
Press the reset button in the instru-
ment cluster (
page 145) for
approximately 3 seconds.
The request to press the reset button
once more to confirm appears in the
multifunction display.

Press the reset button once more.
The functions of all the submenus will
reset to factory settings.Submenus in the Settings menu

Press buttonj.
The collection of the submenus
appears in the multifunction display.

Press buttonç.
The selection marker moves to the next
submenu.
The submenus are arranged by hierarchy.
Scroll down with buttonç, scroll up
with the buttonæ.
With the selection marker on the desired
submenu, use the jbutton to access
the individual functions within that sub-
menu. Once within that submenu, you can
use thej button to move to the next
function or thek button to move to the
previous function within that submenu.
The settings themselves are made with
buttonæ orç.
i
The settings you have changed will not be
reset unless you confirm the action by pressing
the reset button a second time.
After approximately 5 seconds, the
Settings

menu reappears in the multifunction display
(
page 164).
i
For safety reasons, the function
Lamp circuit headlamp
in the
Lighting

submenu cannot be reset while driving.
The following message appears in the multifunc-
tion display:
Settings
Cannot be
completely reset
to factory settings
while driving

166 Controls in detailControl systemThe table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.INSTRUMENT CLUSTER
TIME/DATE
LIGHTING
VEHICLE
COMFORT*
(page 167)
(page 169)
(page 171)
(page 174)
(page 177)
Selecting speedometer
display mode
Setting the time (hours)
Setting daytime running
lamp mode (USA only)
Compass adjustment
Activating
easy-entry/exit
feature*
Selecting language
Setting the time (minutes)
Setting locator lighting
Compass calibration
Setting fold-in func-
tion* for exterior rear
view mirrors
Selecting display (digital
speedometer or outside
temperature) for status in-
dicator
Setting the date (month)
Setting night security
illumination
Audio search function
Setting the date (day)
Setting interior lighting
delayed shut-off
Setting automatic
locking
Setting the date (year)
Limiting opening
height of tailgate*

167 Controls in detail
Control system
Instrument cluster submenu
Access the
Instr. cluster
submenu via
the
Settings
menu. Use the
Instr.
cluster
submenu to change the instru-
ment cluster display settings.
The following functions are available:Selecting speedometer display mode

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Display unit
Digital speedometer
appears in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ or ç to set
speedometer unit to
km or
miles
.Selecting language

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Language
appears in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the language to be used for the
multifunction display messages.
Function
Page
Selecting speedometer display
mode
167
Selecting language
167
Selecting display (digital
speedometer or outside
temperature) for status indica-
tor
168


168 Controls in detailControl system
Available languages:

German


English


French


Italian


Spanish


Dutch


Swedish


Danish


Turkish


Portuguese


Russian (Canada only)Selecting display (digital speedometer
or outside temperature) for status
indicator

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Status line
display
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired setting.
The selected display is then shown
continuously in the status indicator
(lower display).
The other display now appears in the
menu of the standard display
(page 154):


Digital speedometer
or


Outside temperature


169 Controls in detail
Control system
Time/Date submenu
Access the
Time/Date
submenu via the
Settings
menu. Use the
Time/Date

submenu to change the time and date
settings.
The following functions are available:Setting the time (hours)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.

Move the selection marker with
buttonæ or ç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Clock Set hour

appears in the multifunction display.
The selection marker is on the hour
setting.

Press buttonæ orç to set the
hour.Setting the time (minutes)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.

Move the selection marker with
buttonæ or ç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Clock Set
minute(s)
appears in the multifunction
display.
The selection marker is on the minute
setting.

Press buttonæ orç to set the
minutes.
Function
Page
Setting the time (hours)
169
Setting the time (minutes)
169
Setting the date (month)
170
Setting the date (day)
170
Setting the date (year)
170
i
If your vehicle is equipped with the
COMAND system and navigation module*, see
separate COMAND system operating instruc-
tions for information on how to set the date and
time.

170 Controls in detailControl systemSetting the date (month)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ or ç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Date Set month

appears in the multifunction display.
The selection marker is on the month
setting.

Press buttonæ orç to set the
month.Setting the date (day)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Date Set day

appears in the multifunction display.
The selection marker is on the day
setting.

Press buttonæ orç to set the
day.Setting the date (year)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Date Set year

appears in the multifunction display.
The selection marker is on the year
setting.

Press buttonæ orç to set the
year.

171 Controls in detail
Control system
Lighting submenu
Access the
Lighting
submenu via the
Settings
menu. Use the
Lighting

submenu to change the lamp and lighting
settings on your vehicle.
The following functions are available:
Setting daytime running lamp mode
(USA only)

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Lamp circuit
headlamp
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to select
manual operation (
Manual
) or daytime
running lamp mode (
Constant
).
With daytime running lamp mode activated
and the exterior lamp switch at
positionMorU, the low beam
headlamps are switched on when the
engine is running.In low ambient light conditions the
following lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps
For more information on the daytime
running lamp mode, see “Lighting”
(
page 136).
Function
Page
Setting daytime running lamp
mode (USA only)
171
Setting locator lighting
172
Setting night security illumination
172
Setting interior lighting delayed
shut-off
173
i
This function is not available in countries
where the daytime running lamp mode is
mandatory and therefore in a constant mode.
i
For safety reasons, changing the setting for
the daytime running lamp mode is not possible
while the vehicle is in motion. The following
message appears in the multifunction display:
Settings
only possible
at standstillFor safety reasons, resetting to factory settings
(page 165) while driving will not deactivate the
daytime running lamp mode.
