14 Introduction
Operator’s Manual
Warning!G
This Sport Utility Vehicle is designed for both on-road and off-road use. It can go places and perform tasks for which conventional 2-wheel drive
passenger cars are not intended. This vehicle will handle and maneuver differently from conventional passenger cars in driving conditions which
may occur on streets, highways and off-road use.
This vehicle has a higher ground clearance and a higher center of gravity than many passenger cars. As with other vehicles of this type, if you make
sharp turns at excessive speeds or abrupt maneuvers, the vehicle may roll over or may go out of control and crash. Utility vehicles have a signifi-
cantly higher rollover rate than other types of vehicles. Failure to operate this vehicle safely may result in an accident, rollover of the vehicle, and
severe or fatal injury.
Before you start to drive this vehicle, read the Operator’s Manual. Take time to become familiar with the driving characteristics of this vehicle. Be
sure you are familiar with all vehicle controls. Learn how your vehicle handles on different road surfaces. Do not attempt sharp turns at excessive
speeds or abrupt maneuvers or other unsafe driving actions that can cause loss of vehicle control. When driving off-road or working the vehicle
hard, do not overload it. And, always wear your seat belts at all times. In a rollover crash, an unbelted person is significantly more likely to die than
a person wearing a seat belt.

282 Controls in detail
Driving systems
The parked vehicle begins adjusting to the
set vehicle level as soon the doors and tail-
gate are

unlocked
or

opened or closed with the vehicle
unlocked
In order to operate the vehicle level control
switch (
page 283), however, the engine
must be running.
For information on off-road driving, see
“Off-road driving” (
page 357).
Warning!G
Make sure that no one is near the wheel
housing or under the vehicle when you lower
the vehicle while it is standing still. Limbs
could become wedged into or under the ve-
hicle.
For safety reasons, the vehicle can only be
lowered with all doors and the tailgate
closed. Lowering is interrupted if a door or
the tailgate is opened and will continue after
the door is closed again.
Warning!G
Please be aware that by raising the vehicle
level, the center of gravity also rises. There-
fore, always ensure that the vehicle level is
as low as possible. With higher ride height
the ESP
® may activate earlier in certain
situations.
Adapt your speed and driving to possible
changed driving behavior of the vehicle after
changing the vehicle level. The ESP
® cannot
prevent accidents, including those resulting
from excessive speed. The ESP
® cannot pre-
vent the natural laws of physics from acting
on the vehicle.
!Keep in mind that in rough or uneven ter-
rain, adjusting the vehicle to a lower level may
cause the vehicle underbody to come in contact
with the ground and result in damage to the vehi-
cle underbody. Always make sure the vehicle has
sufficient ground clearance before adjusting it to
a lower level.
!Before jacking up the vehicle with equip-
ment that lifts one or more of the wheels com-
pletely off of the ground, remove the SmartKey
from the starter switch.
!Please also note the information in the sec-
tion on towing (
page 540).

284 Controls in detail
Driving systems
Raised level
Only select the raised level if appropriate
for the driving situation encountered.
Otherwise:

fuel consumption may increase

handling characteristics of the vehicle
may be unfavorable
Start the engine (page 41).
If indicator lamp2 (
page 283) is off.
Press switch1 (page 283).
Indicator lamp2 flashes. The vehicle
adjusts to the raised level.The following message appears in the mul-
tifunction display while the level is being
set:
When the raised level is reached, indicator
lamp2 (
page 283) comes on continu-
ously and the following message appears
in the multifunction display for 5 seconds:Highway level
Start the engine (page 41).
If indicator lamp2 (
page 283) is on.
Press switch1 (page 283).
Indicator lamp2 flashes. The vehicle
adjusts to the highway level.
The following message appears in the
multifunction display while the level is
being set:
iYou can select the raised level at speeds up
to 40 mph (64 km/h). At higher speeds, the
messagen
Level selection not
permitted
appears in the multifunction dis-
play.
iThe message can be cleared by pressing
theèÿk or buttonj on the
multifunction steering wheel.
!Keep in mind that in rough or uneven roads,
adjusting the vehicle to a lower level may cause
the vehicle underbody to come in contact with
the road and result in damage to the vehicle un-
derbody. Always make sure the vehicle has suffi-
cient ground clearance before adjusting it to a
lower level.

289 Controls in detail
Driving systems
You will see, for example, the following
message in the multifunction display:

At speeds above 60 mph (96 km/h)
the off-road level 1 setting is canceled
and the vehicle is lowered to the high-
way level.
You will see, for example, the following
message in the multifunction display:

Depending on the ADS setting
(
page 280), the vehicle will be low-
ered to the high-speed level when trav-
eling at higher speeds. At speeds below
25 mph (40 km/h) at the latest, it will
be returned to the highway level.
Highway level
Start the engine (page 41).If one or more of the indicator lamps
(
page 283) are on:
Press switch2 (page 285)
repeatedly until all lit indicator
lamps3 flash.
The vehicle adjusts to the highway
level.
The following message appears in the
multifunction display while the level is
being set:
iThe setting is stored when you turn off the
engine.
!Keep in mind that in rough or uneven roads,
adjusting the vehicle to a lower level may cause
the vehicle underbody to come in contact with
the road and result in damage to the vehicle un-
derbody. Always make sure the vehicle has suffi-
cient ground clearance before adjusting it to a
lower level.
iThe message can be cleared by pressing
theèÿk or buttonj on the
multifunction steering wheel.

358 Operation
Driving instructions
Special driving features for off-road
driving
The following driving features are available
for specific kind of operation:

Off-road – ABS (page 104)

Off-road – ESP® (page 108)

Off-road – 4-ETS (page 110)

Hill start assist system (page 199)

LOW RANGE mode* (page 203)

Differential locks* (page 206)

Downhill Speed Regulation (DSR)
(
page 275)

Off-road driving program (Vehicles
without enhanced off-road package*)
(
page 279)

Air suspension (page 280)Off-road driving rules

Engage the off-road driving program
(
page 279) or LOW RANGE mode*
(
page 203) before driving under
off-road conditions.

If necessary, activate differential
locks* (
page 206).

Make sure you select a vehicle level
(
page 281) appropriate to the topo-
graphical conditions. Always make
sure the vehicle has enough ground
clearance.

Fasten items being carried as securely
as possible (
page 297).

Always navigate gradients with the en-
gine on and with the transmission en-
gaged in a gear. Switch on the DSR
(
page 276) to help maintain a preset
speed.
!Observe the following during off-road
driving:

Keep doors, tailgate, windows, and
tilt/sliding sunroof* closed whenever driving
off-road.

Adjust vehicle speed to condition of terrain.
The more uneven, rutty and steeper the ter-
rain, the lower the speed should be. Drive
through water slowly at an even speed,
avoiding a bow wave.

Be especially careful when driving in un-
known territory. It may be necessary to get
out of the vehicle and scout the path you in-
tend to take.

Watch out for obstacles, such as rocks,
holes, tree stumps and ruts.

Before driving through water, determine its
depth.

Do not stop vehicle while immersed in water,
and do not shut off the engine.

363 Operation
Driving instructions

Do not stop vehicle while immersed in
water, and do not shut off the engine.

There is a very high level of driving re-
sistance in water. The surface is slip-
pery and may not be firm, making
pulling away in water difficult and dan-
gerous.

Make sure that only small bow waves
are formed when driving the vehicle
through water.

Clean mud off the tire tread after driv-
ing through water.

To dry the brakes, apply pressure to the
brake pedal several times while driving
after leaving the water.Crossing obstaclesWhen driving over tree stumps, big rocks
and other obstacles, observe the following
rules:

Make sure the off-road driving program
(
page 279) or if equipped the LOW
RANGE mode* (
page 203) is
switched on.

Avoid high engine speeds.

Shift automatic transmission to
position1 (
page 200).

Check the vehicle clearance before
crossing obstacles.

Cross obstacles (e.g. tree stumps or
big rocks) very slowly by aiming one of
the front wheels at the center of the ob-
stacle, and repeat same with the rear
wheel.
!Do not open any of the vehicle’s doors while
driving through water. Water could otherwise en-
ter the vehicle interior and damage the vehicle’s
electronics, as well as the interior equipment.
!Obstacles can damage the vehicle
underbody or suspension components. If possi-
ble use the assistance of a second person out-
side the vehicle to scout the path you intend to
take and check for adequate ground clearance
when you cross obstacles with your vehicle. The
person assisting you outside the vehicle should
always be a safe distance away from the vehicle
and positioned so that he or she cannot get hurt
in case of any unexpected vehicle movement.
After off-road driving or crossing obstacles, in-
spect vehicle for any damage, especially vehicle
underbody and suspension components. Failure
to do so can adversely affect the vehicle’s future
performance, including increased chance of an
accident.
!Special attention is needed when you cross
obstacles on a steep incline.
The vehicle could slide sideways as a result of its
possible slanted position which in turn may
result in the vehicle tipping or rolling over.

364 Operation
Driving instructions
Driving on sand
When driving on sand, observe the follow-
ing rules:

Set the raised level (page 281).

Avoid high engine speeds.

Shift automatic transmission into a
gear range that is appropriate for the
terrain.

In sandy soil, drive at a steady speed as
conditions permit. This helps overcome
the vehicle rolling resistance and re-
duce the likelihood of the vehicle sink-
ing into the ground.

Drive in tracks of other vehicles if they
are not too deep and you have suffi-
cient clearance.
Ruts
A number of off-road tracks or other by-
ways have deep ruts which can cause the
underbody to come in contact with the
ground.

Make sure the off-road driving program
(
page 279), or if equipped, the LOW
RANGE mode* (
page 203) is
switched on.

Set the raised level (page 281).

Avoid high engine speeds.

Shift automatic transmission to
position1 (
page 200).

Drive next to the ruts rather than
through them if at all possible.

If the ruts are too deep to drive in, drive
with one side of the vehicle on the
grassy center strip if the route permits.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 396) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.
!Check that the ruts are not too deep and
your vehicle’s clearance is sufficient. Otherwise:

your vehicle may be damaged

the underbody of the vehicle may come in
contact with the ground and you may get
stuck

558 Technical data
Main Dimensions
ModelGL 320 CDI, GL 450
Overall vehicle length200.6 in (5096 mm)
Vehicle width (exterior rear view mirrors folded out)83.7 in (2127 mm)
Vehicle width (exterior rear view mirrors folded in)76.0 in (1930 mm)
Overall vehicle height, depending on set vehicle level72.4 in - 75.6 in (1840 mm - 1920 mm)
Overall vehicle height, depending on set vehicle level
(vehicles with enhanced off-road package*)72.4 in - 76.8 in (1840 mm - 1950 mm)
Wheelbase121.1 in (3075 mm)
Ground clearance, depending on set vehicle level7.8 in - 10.9 in (197 mm - 277 mm)
Ground clearance, depending on set vehicle level
(vehicles with enhanced off-road package*)7.8 in - 12.1 in (197 mm - 307 mm)
Turning circle39.7ft (12.1m)
Track, front65.0 in (1651 mm)
Track, rear65.1 in (1654 mm)
