2007 MERCEDES-BENZ GL320CDI air conditioning

Contents
Control system .................................. 157
Multifunction display .................... 157
Multifunction steering wheel ........ 158
Menus .......................................... 160
Standard display menu ................ 164
Audio menu .................................. 166
NAV* menu .................................. 168
Off-road menu .............................. 168
DISTRONIC* menu ....................... 169
Vehicle status message
memory menu .............................. 169
Settings menu .............................. 170
Vehicle configuration ................... 185
Trip computer menu..................... 187
TEL* menu ................................... 189
Automatic transmission ..................... 192
Gear selector lever ....................... 192
Shifting procedure ....................... 195
Transmission positions................. 195
Driving tips ................................... 198
Gear ranges ................................. 200
Steering wheel gearshift control .. 201
Emergency operation
(Limp-Home Mode) ...................... 202
Transfer case ..................................... 203
LOW RANGE mode* ..................... 203Differential locks* .............................. 206
A few words about differentials
and differential locks* .................. 206
Switching differential locks* ......... 207
Good visibility ..................................... 210
Headlamp cleaning system* ......... 210
Rear view mirrors.......................... 210
Power folding exterior
rear view mirrors*......................... 211
Sun visors ..................................... 213
Rear panorama roof sunshade ...... 214
Rear window defroster .................. 215
Climate control ................................... 216
Deactivating the
climate control system ................. 220
Operating the climate control
system in automatic mode............ 220
Setting the temperature................ 221
Adjusting air distribution............... 221
Adjusting air volume ..................... 222
Air vents in the roof liner
over the second-row seats* .......... 222
Front defroster.............................. 223
Air recirculation mode .................. 224
Air conditioning............................. 226
Residual heat and ventilation ........ 227Rear climate control* ................... 228
3-zone automatic climate control* ..... 230
Deactivating the automatic
climate control system ................. 234
Operating the automatic
climate control system
in automatic mode ........................ 235
Setting the temperature ............... 235
Adjusting air distribution .............. 236
Adjusting air volume ..................... 237
Front defroster ............................. 237
Maximum cooling MAXCOOL ........ 239
Air recirculation mode .................. 239
Air conditioning ............................ 241
Using driver-side settings
for all temperature zones.............. 242
Residual heat and ventilation ........ 242
Rear automatic climate control..... 243
Power windows .................................. 248
Opening and closing ..................... 248
Synchronizing the door windows .. 251
Summer opening feature .............. 251
Convenience closing feature......... 252

Contents
Replacing wiper blades ...................... 520
Front wiper blades ....................... 520
Rear wiper blade .......................... 521
Flat tire .............................................. 523
Preparing the vehicle.................... 523
Mounting the spare wheel ............ 524
Bleeding the fuel system
(diesel engine only) ............................ 529
Battery ............................................... 530
Disconnecting, removing,
reinstalling and
reconnecting the battery .............. 532
Charging the battery .................... 537
Jump starting ..................................... 538
Towing the vehicle ............................. 540
Installing towing eye bolt.............. 542
Stranded vehicle .......................... 543
Fuses ................................................. 544
Fuse box in engine compartment . 545
Fuse box in cargo compartment ... 545
Fuse box in
passenger compartment .............. 546
Emergency engine shut-down ...... 546
Technical data................................. 547
Parts service ...................................... 548
Warranty coverage............................. 549
Loss of Service and Warranty
Information Booklet ..................... 549
Identification labels ........................... 550
Layout of poly-V-belt drive ................. 552
GL 320 CDI .................................. 552
GL 450 ......................................... 552
Engine................................................ 553
Rims and tires.................................... 554
Same size tires ............................. 555
Minispare wheel ........................... 556
Electrical system ............................... 557
Main Dimensions ............................... 558
Weights.............................................. 559Fuels, coolants, lubricants ................. 560
Capacities .................................... 560
Engine oils ................................... 562
Engine oil additives ...................... 562
Air conditioning refrigerant .......... 562
Brake fluid.................................... 562
Premium unleaded gasoline
(gasoline engine) .......................... 563
Fuel requirements ........................ 563
Gasoline additives
(gasoline engine) .......................... 564
Coolants ...................................... 565
Windshield washer system and
headlamp cleaning system*......... 567
Index................................................. 569

219 Controls in detail
Climate control
The climate control is operational whenev-
er the engine is running. You can operate
the climate control system in either the
automatic or manual mode. The system
cools or heats the interior depending on
the selected interior temperature and the
current outside temperature.Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.
The air conditioning will not engage (no
cooling) if the A/C mode is deactivated
(
page 226).
Warning!G
When operating the climate control, the air
that enters the passenger compartment
through the air vents can be very hot or very
cold (depending on the set temperature).
This may cause burns or frostbite to unpro-
tected skin in the immediate area of the air
vents.
Always keep sufficient distance between un-
protected parts of the body and the air
vents. If necessary, use the air distribution
controls (
page 218) to direct the air to air
vents in the vehicle interior that are not in
the immediate area of unprotected skin.
Warning!G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iSevere conditions (e.g. strong air pollution)
may require replacement of the filter before its
scheduled interval. A clogged filter will reduce
the air volume to the interior.
If the vehicle interior is hot, ventilate the interior
before driving off, see “Summer opening fea-
ture” (
page 251). The climate control will then
adjust the interior temperature to the set value
much faster.
Keep the air intake grille in front of the wind-
shield free of snow and debris.

223 Controls in detail
Climate control
Adjusting air distribution
Move air vent slider2 to the left, right,
up, or down to direct the air in the de-
sired direction.
Front defroster
You can use this setting to defrost the
windshield, for example if it is iced up. You
can also use it to defog the windshield and
door windows.
Activating
Press button0 or, depending on
vehicle production date, button|
(
page 218).
The indicator lamp on the button
comes on.The climate control switches to the follow-
ing functions automatically:

most efficient blower speed and
heating power, depending on outside
temperature

air flows onto the windshield and the
door windows (side air vents must be
open)

the air conditioning compressor
switches on at outside temperatures
above approximately 41°F (5°C) for
air-drying
Adjustments
You can adjust the air volume and the tem-
perature when the front defroster is
switched on. The air flow will remain on the
windshield and door windows.
Press button
to decrease or
buttonQ to increase air volume
(
page 218) to the desired level.The air volume decreases/increases to
the next lower/higher blower speed
and heating switches to the tempera-
ture that was set before the front de-
froster was switched on.
The indicator lamp on button0 or,
depending on vehicle production date,
button| goes out. The indicator
lamp on button9 comes on.
or
Turn temperature control1
and/or7 (
page 218) slightly in any
direction.
Heating switches to the temperature
that was set before the front defroster
was switched on.
The indicator lamp on button0 or,
depending on vehicle production date,
button| goes out. The indicator
lamp on button9 comes on.iKeep this setting selected only until the
windshield or the door windows are clear again.


224 Controls in detail
Climate control
Deactivating
Press button0 or, depending on
vehicle production date, button|
(
page 218) once more.
The indicator lamp on the button goes
out. Defrosting is turned off.
The previous settings are in effect
again. The air conditioning compressor
remains switched on.Windshield fogged on the outside
Switch the windshield wipers on
(
page 64).
Press button0 or, depending on
vehicle production date, button|
(
page 218).
The indicator lamp on the button
comes on.
The climate control switches automatically
to the following functions:

most efficient blower speed and
heating power, depending on outside
temperature

air flows onto the windshield and the
door windows (side air vents must be
open)

the air conditioning compressor
switches on at outside temperatures
above approximately 41°F (5°C) for
air-dryingIf the automatic air distribution is switched
off:
Press air distribution button9 ora
(
page 218).
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside (e.g. before driving
through a tunnel). This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment.
iThe air conditioning compressor remains on
even if the indicator lamp in button0 or, de-
pending on vehicle production date, button|
goes out. This helps to prevent the windshield
from fogging.
iTo switch off, you can also press
button´ orU (
page 218).
iKeep this setting selected only until the
windshield is clear again.
Warning!G
Fogged windows impair visibility,
endangering you and others. If the windows
begin to fog on the inside, switching off the
air recirculation mode immediately should
clear interior window fogging. If interior win-
dow fogging persists, make sure the air
conditioning (
page 218) is activated, or
press button0 or, depending on vehicle
production date, button|.


225 Controls in detail
Climate control
Activating
Press button: (page 218).
The indicator lamp on the button
comes on.DeactivatingPress button:.
The indicator lamp on the button goes
out.Air recirculation mode with conve-
nience closing and opening feature
iThe air recirculation mode is activated auto-
matically at high outside temperatures.
The indicator lamp on button: is not lit when
the air recirculation mode is switched on auto-
matically.
A quantity outside air is added after
approximately 30 minutes.
If you have turned off the air conditioning
(
page 226) or the outside temperature is
below 41°F (5°C), the air recirculation mode will
not switch on automatically.
iTo cool the interior as fast as possible, the
climate control automatically switches to air
recirculation. The indicator lamp on button:
is not lit when the air recirculation mode has
been switched on automatically.
iThe air recirculation mode is deactivated
automatically

after 5 minutes if the outside temperature is
below approximately 41°F (5°C)

after 5 minutes if the air conditioning and
air-drying is turned off

after 30 minutes if the outside temperature
is above approximately 41°F (5°C)
Warning!G
Never operate the windows and tilt/sliding
sunroof* if there is the possibility of anyone
being harmed by the opening or closing pro-
cedure.
When using the air recirculation mode with
convenience closing feature, should the up-
ward movement of a window be blocked by
some obstruction including but not limited
to arms, hands, fingers, etc., the automatic
reversal feature will not operate.
In case the procedure causes potential
danger:
Vehicles with or without tilt/sliding sun-
roof*: The closing of the windows can be im-
mediately halted by pressing or pulling the
respective window switch. The closing of the
tilt/sliding sunroof* can be immediately
halted by moving the switch for the tilt/slid-
ing sunroof* in any direction.


226 Controls in detail
Climate control
Convenience closing
Press button: for approximately
2 seconds.
The windows and/or tilt/sliding sun-
roof* will close. You can release
button: once the closing proce-
dure has begun. The windows and
tilt/sliding sunroof* continue closing
until they are fully closed. The indicator
lamp on the button comes on. The air
recirculation mode is activated.Convenience opening
Press button: for approximately
2 seconds.
The windows and/or tilt/sliding sun-
roof* will return to their previous posi-
tions. You can release button:
once the opening procedure has be-
gun. The windows and tilt/sliding sun-
roof* continue opening until they have
reached their previous positions. The
indicator lamp on the button goes out.
The air recirculation mode is deactivat-
ed.
Air conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator.
In addition, the air conditioning dehumidi-
fies the interior air at outside temperatures
above 41°F (5° C) and helps prevent
window fogging.The closing of the windows and the
tilt/sliding sunroof* can be reversed by
again pressing and holding the :button.
iA window or the tilt/sliding sunroof* will
only return to its previous position if it has not
been moved to another position using the re-
spective window switch or tilt/sliding sunroof*
switch after it was closed with button:.
iCondensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.
Warning!G
If you turn off the cooling function, the
interior air is not dried. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.


227 Controls in detail
Climate control
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.
Press button9 (page 218).
The indicator lamp on the button goes
out.
Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.
Press button9 (page 218) again.
The indicator lamp on the button
comes on.
The air conditioning uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.Activating
Switch off the ignition (page 42).
Press button9 (page 218).
The indicator lamp on the button
comes on.
Deactivating
Press button9 (page 218).
The indicator lamp on the button goes
out.
!If the air conditioning cannot be turned on
again, this indicates that the air conditioning is
losing refrigerant. The compressor has turned
off.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Light Truck Center.
iHow long the system will provide heating
depends on

the coolant temperature

the battery voltage
Regardless of the temperature and air volume
set on the climate control panel, the interior tem-
perature is set to 72°F (22°C) and the blower
runs on low speed to protect the vehicle battery.
iThe residual heat is automatically turned off:

when the ignition is switched on

after about 30 minutes

if the coolant temperature is too low

if the battery voltage drops
