2007 MERCEDES-BENZ CL-CLASS snow chains

Contents
Operation......................................... 497
The first 1000 miles (1500 km) ......... 498
Driving instructions ............................ 499
Drive sensibly – save fuel ............. 499
Drinking and driving ..................... 499
Pedals .......................................... 499
Power assistance ......................... 499
Brakes .......................................... 500
Driving off..................................... 501
Parking ......................................... 502
Tires ............................................. 502
Hydroplaning ................................ 503
Tire traction .................................. 503
Tire speed rating .......................... 504
Winter driving instructions ........... 504
Standing water ............................. 505
Passenger compartment .............. 506
Driving abroad .............................. 506
Control and operation
of radio transmitters .................... 506
Catalytic converter ....................... 507
Emission control........................... 507
Coolant temperature .................... 508At the gas station .............................. 509
Refueling ...................................... 509
Check regularly
and before a long trip ................... 511
Engine compartment ......................... 512
Hood ............................................ 512
Engine oil ..................................... 513
Transmission fluid level ................ 517
Active Body Control
(ABC) fluid level ............................ 517
Coolant level ................................ 518
Windshield washer system and
headlamp cleaning system ........... 519
Tires and wheels ................................ 520
Important guidelines .................... 520
Tire care and maintenance ........... 521
Direction of rotation ..................... 523
Loading the vehicle ...................... 523
Recommended
tire inflation pressure ................... 528
Checking tire inflation pressure ... 530
Tire labeling.................................. 536
Load identification ....................... 540
DOT,
Tire Identification Number (TIN) ... 540
Maximum tire load ....................... 541Maximum tire inflation pressure .. 542
Uniform Tire Quality
Grading Standards (U.S. vehicles) 542
Tire ply material ........................... 544
Tire and loading terminology ........ 544
Rotating tires ............................... 548
Winter driving .................................... 549
Winter tires .................................. 549
Snow chains................................. 550
Maintenance...................................... 551
Maintenance
service indicator message ........... 551
Calling up the maintenance
service indicator display .............. 553
Resetting the maintenance
service indicator .......................... 553
Vehicle care....................................... 554
Cleaning and care of vehicle ........ 554
ProCarManuals.com

64 Safety and Security
Driving safety systems
This section contains information about
Adaptive Brake Lights as well as the follow-
ing driving safety systems:

ABS (Antilock Brake System)

Adaptive Brake

BAS (Brake Assist System)

BAS Plus* (Brake Assist System Plus)

EBP (Electronic Brake Proportioning)

ESP® (Electronic Stability Program)

PRE-SAFE® Brake* (Preventive Occu-
pant Safe
ty Brake)
ABS
The Antilock Brake System (ABS) regulates
the brake pressure so that the wheels do
not lock during braking. This allows you to
maintain the ability to steer your vehicle.
The ABS is functional above a speed of ap-
proximately 5 mph (8 km/h) independent
of road surface conditions.
On slippery road surfaces, the ABS will re-
spond even to light brake pressure.
The - indicator lamp in the instrument
cluster (
page 30) comes on when you
switch on the ignition (
page 336). It goes
out when the engine is running.
Warning!G
The following factors increase the risk of ac-
cidents:

Excessive speed, especially in turns

Wet and slippery road surfaces

Following another vehicle too closely
The driving safety systems described in this
section cannot reduce these risks or pre-
vent the natural laws of physics from acting
on the vehicle.
Always adapt your driving style to the pre-
vailing road and weather conditions and
keep a safe distance to other road users and
objects on the street.
iIn winter operation, the maximum effective-
ness of the ABS, Adaptive Brake, BAS,
BAS Plus*, EBP and ESP
® only achieved with
winter tires (
page 549), or snow chains as re-
quired.
Warning!G
Do not pump the brake pedal. Use firm,
steady brake pedal pressure instead. Pump-
ing the brake pedal defeats the purpose of
the ABS and significantly reduces braking
effectiveness.
ProCarManuals.com

71 Safety and Security
Driving safety systems
Electronic traction system
The electronic traction system is a compo-
nent of ESP
®.
The electronic traction system improves
the vehicle’s ability to utilize available trac-
tion, especially under slippery road condi-
tions by applying the brakes to a spinning
wheel.
When you switch off the ESP
®, the elec-
tronic traction system is still enabled.Switching off the ESP
®
To improve the vehicle’s traction, turn off
the ESP® in driving situations where it
would be advantageous to have the drive
wheels spin and thus cut into surfaces for
better grip such as:

when driving with snow chains

in deep snow

in sand or gravelWhen you switch off the ESP
®

the ESP® does not stabilize the vehicle

the engine output is not limited, which
allows the drive wheels to spin and
thus cut into surfaces for better grip

the electronic traction system will still
apply the brakes to a spinning wheel

the ESP® continues to operate when
you are braking

you cannot activate the cruise control
or the DISTRONIC Plus*
Warning!G
If you are driving too fast, the electronic
traction system cannot reduce the risk of an
accident.
The electronic traction system cannot pre-
vent the natural laws of physics from acting
on the vehicle.
Warning!G
The ESP® should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
Warning!G
Switch on the ESP® immediately if the afore-
mentioned circumstances do not apply any-
more. Otherwise the ESP
® will not stabilize
the vehicle when it is starting to skid or a
wheel is spinning.
ProCarManuals.com

429 Controls in detail
Driving systems
Active Body Control (ABC)
The ABC system is an active, comput-
er-controlled system that hydraulically ad-
justs the suspension at all four wheels in
response to various driving situations. It
automatically selects the optimum suspen-
sion tuning and ride height for your vehicle.
Vehicle level controlYour vehicle automatically adjusts its ride
height to:

increase vehicle safety

reduce fuel consumption
The vehicle chassis ride height is raised or
lowered according to the selected level
setting and to the vehicle speed:

With increasing speed, ride height is re-
duced by up to approximately 0.4 in
(10 mm).

With decreasing speed, the ride height
is again raised to the selected vehicle
level.The following vehicle level settings can be
selected when the vehicle is stationary:
Select the “Raised” level setting only when
required by current driving conditions.
Otherwise:

Fuel consumption may increase.

Handling may be impaired.
Warning!G
To help avoid personal injury, keep hands
and feet away from wheel housing area, and
stay away from under the vehicle when
lowering the vehicle chassis.
iThese height adjustments are so small that
you may not notice any change.
Level
NormalFor driving on normal roads.
The indicator lamp is off.
RaisedFor driving on rough roads or
with snow chains. The indica-
tor lamp is on.
iThe selected vehicle level setting remains
stored in memory even if the engine is turned off
and restarted.
ProCarManuals.com

504 Operation
Driving instructions
Tire speed rating
Regardless of the tire speed rating, local
speed limits should be obeyed. Use pru-
dent driving speeds appropriate to prevail-
ing conditions.
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).The factory equipped tires on your vehicle
may have a tire speed rating above the
maximum speed permitted by the elec-
tronic speed limiter.
Make sure your tires have the required tire
speed rating as specified for your vehicle in
the “Technical data” section (
page 678),
for example when purchasing new tires.
For information on how to identify the tire
speed rating on a tire’s sidewall, see “Tire
size designation, load and speed rating”
(
page 536).
If you are uncertain about the correct read-
ing of the information given on a tire’s side-
wall, any authorized Mercedes-Benz
Center will be glad to assist you.
Winter driving instructions
The most important rule for slippery or icy
roads is to drive sensibly and to avoid
abrupt acceleration, braking and steering
maneuvers. Do not use the cruise control
or DISTRONIC Plus* system under such
conditions.
When the vehicle is in danger of skidding,
move gear selector lever to position N. Try
to keep the vehicle under control by cor-
rective steering action.
Warning!G
Even when permitted by law, never operate
a vehicle at speeds greater than the maxi-
mum speed rating of the tires.
Exceeding the maximum speed for which
tires are rated can lead to sudden tire fail-
ure, causing loss of vehicle control and pos-
sibly resulting in an accident and/or serious
personal injury and possible death, for you
and for others.
iFor information on speed ratings for winter
tires, see (
page 539) and (page 549).
iFor information on driving with snow chains,
see “Snow chains” (
page 550).
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of control loss.
ProCarManuals.com

550 Operation
Winter driving
Snow chainsSnow chains should only be driven on
snow-covered roads at speeds not to
exceed 30 mph (50 km/h). Remove chains
as soon as possible when driving on roads
without snow.
Please observe the following guidelines
when using snow chains:

Use of snow chains is not permissible
with all wheel/tire combinations
(
page 678).

Use snow chains in pairs and rear
wheels only. Follow the manufacturer’s
mounting instructions.

Only use snow chains that are
approved by Mercedes-Benz. Your
authorized Mercedes-Benz Center will
be glad to advise you on this subject.

Use of snow chains may be prohibited
depending on location. Always check
local and state laws before installing
snow chains.

Do not use snow chains on the spare
wheel (
page 681).
Warning!G
If you use your spare tire when winter tires
are fitted on the other wheels, be aware that
the difference in tire characteristics may
very well impair turning stability and that
overall driving stability may be reduced.
Adapt your driving style accordingly.
Have the spare tire replaced with a winter
tire at the nearest authorized
Mercedes-Benz Center.
!When driving with snow chains, always se-
lect the raised level of the level control system
ABC (
page 429). Other settings may result in
damage to your vehicle.
!Some tire sizes do not leave adequate clear-
ance for snow chains. To help avoid serious dam-
age to your vehicle or tires, make sure that the
use of snow chains is permissible as specified in
the “Technical data” section of this Operator’s
Manual, see “Rims and tires” (
page 678).
!If snow chains are mounted to the front
wheels, they may scrape against the body or axle
components. The tires or the vehicle could be
damaged as a result.
iWhen driving with snow chains, you may
wish to deactivate the ESP® (page 71) before
setting the vehicle in motion. This will improve
the vehicle’s traction.
ProCarManuals.com

679 Technical data
Rims and tires
Same size tires
ModelCL 550CL 600
CL 550 (Sport Package*)
CL 600 (Sport Package*)
Rims (light alloy)8.5 J x18 H28.5 J x18 H2
Wheel offset1.69 in (43 mm)1.69 in (43 mm)
All-season tires*1
1Radial-ply tires.
255/45 R18 99H M+S –
Winter tires1,2,3
2For use with snow chains contact an authorized Mercedes-Benz Center.3Not available as factory equipment.
255/45 R18 99H M+S.255/45 R18 99H M+S.
ProCarManuals.com

681 Technical data
Rims and tires
Minispare wheel
ModelCL 550
CL 550 (Sport Package*)
CL 600
CL 600 (Sport Package*)
Rim4.5 B x 19
Wheel offset1.38 in (35 mm)
Minispare tire1
1Must not be used with snow chains.
T 155/70 R19 113M
!Please compare the recommended tire in-
flation pressure for your vehicle with the tire in-
flation pressure on the yellow label located on
the Minispare wheel rim.
If the tire inflation pressure on the yellow label
on the Minispare wheel rim differs from the val-
ues given in this Operator’s Manual, inflate the
spare wheel tire to the recommended tire infla-
tion pressure given on the yellow label on the
Minispare wheel rim.iPlease note that the tire inflation pressure of
the Minispare differs from the tire inflation pres-
sure of the road tires.
Make sure the Minispare tire is inflated to ap-
proximately 61 psi (4.2 bar).
ProCarManuals.com
