2007 MAZDA MODEL 3 HATCHBACK Quick Tips (in English)

Lower Octane Fuel Usage
If 91 octane fuel is not available,
fuel as low as 87 octane
can be used temporarily for
emergency purposes, use
of fuel lower than 91 octane
can decrease performance
and deteriorate shift quality,
refueling vehicle with correct
octane fuel a couple of
times will restore vehicle
performance and shift quality.This Quick Tips® guide is provided
by Mazda North American
Operations to make your Mazda
ownership experience more
convenient. It is not intended
to replace your Owner’s Manual.
If you have any questions about your
vehicle, you are invited to contact
your local dealer. Or if you need
additional help, feel free to call our
Customer Assistance Center
at 1-800-222-5500
Monday through Friday,
8 a.m.- 4:45 p.m., Pacific
9 a.m.- 5:45 p.m., Eastern/Central Mazda Roadside Assistance
Exhilaration, liberation and inspiration,
are great reasons to drive a
Mazda car, truck, SUV or minivan.
In addition to all the other great
standard features, you also get peace
of mind with our basic warranty
period Emergency Roadside
Assistance Plan, it’s just a phone
call away, 24 hours a day, 365
days a year, call 1-800-866-1998.
Mazda ‘’bumper-to-bumper”
Limited Warranty
We design and build every Mazda
to give you driving pleasure now
and far down the road. We’re so
confident in our quality that we cover
the entire vehicle against defects
in materials and workmanship for
36 months/36,000 miles, whichever
comes first, plus we provide a
powertrain warranty for 60 months/
60,000 miles, whichever comes first.
©2006 Calcar, Quick Tips®is a trademark
of Calcar, made in USA 2/06 102.195M DOT
Mazda North American Operations reserves
the right to change product specifications at
any time without incurring obligations.
9999-95-038C-07QT
ROADSIDE ASSISTANCE/WARRANTY
Unleaded
Gasoline
MAZDA3
87-octane
MAZDASPEED3
91-93-octane
14.5-gallon/
55-liter tank
2007
Reference
Guide for
Controls and
Functions
Quick Tips®
®
MAZDA3/
MAZDASPEED3MAZDA3/
MAZDASPEED3

DRIVER’S VIEW
Always check the Owner’s Manual for more operating information and safety features
1. Power window switches*,
see Windows/Mirrors
2. Door locks*, see Locks
3. Mirror controls*,
see Windows/Mirrors
4. Xenon headlight leveling
switch*,see Getting Started
5. Air vents
6. Turn signal/lighting control
lever, see Getting Started7. Fog light switch*,see Getting Started8. Audio control switches*,see Getting Started
9. Horn/Air bag, To beep: Press
10. Cruise control*, see Getting Started11. Wiper/washer control
lever,see Getting Started
12. Hazard warning switch
Push to activate/deactivate
13. NAVI display*,see Owner’s Manual
14. Information display/
trip computer*,
see Information Display15. Audio system,see Audio Systems
16. Passenger air bag
17. Bottle holder
CAUTION: Use plastic
bottles with caps, cups may
spill when door is closed
18. Traction Control/
Dynamic Control System
off*,
see Driving Tips19. NAVI DVD*20. Climate control panel,
see Climate Controls
21. Cigarette lighter
22. Passenger air bag off
indicator,see Getting Started
23. Ashtray
24. NAVI remote control*25. Parking-brake lever
26. Center console
DSCOFF
Driver’s
View
231
34
17
352723
20
54516618711513129108
30313332
2
17
1415
25
19212229
24
28
1
263736
*Denotes optional equipment
27. Cup holder
Tip: Rear cup holders
located in rear center armrest
28. Gearshift lever, see Transaxle29. Heated seats*Press on/off
30. Tilt/telescopic steering
wheel lever,
see Getting Started
31. Hood release handle
Pull release handle to unlock
32. Instrument cluster
lighting, see Getting Started
33. Storage
34. Fuel-filler lid release
To open: Pull lever up
35. Remote trunk-lid
release (4-Door only)
To open: Pull lever up
36. Auxiliary jack
37. Accessory socket

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting Started
MAZDA3/MAZDASPEED3
Quick Tips
®are designed to
quickly familiarize you with
some important features of
your MAZDA3/MAZDASPEED3
The Driver’s View tab is your
index to the Quick Tips
®, locate
the item you would like to
learn more about and then
turn to the listed tab
This Getting Started section
contains important operating
tips about your MAZDA3/
MAZDASPEED3
Items identified in blue text
call out important informationMAZDASPEED3
Turbocharger tips
To get maximum performance
from your turbocharged engine,
take note of the following:
Use 91 octane or above premium
unleaded gasoline only, extra fuel
additives are NOT recommended
Change engine oil and filter
every 7,500 miles, or sooner if
needed, see Owner’s Manual
Use engine oil with API SL or
ILSAC GF-3 service grade or
higher, extra oil additives are
NOT recommended
After driving at freeway speeds
or up a long hill, idle engine
at least 30 seconds to cool turbo,
avoid shutting engine off abruptly
after a hard or long drive,
turbocharger damage may
result otherwiseDo NOT race or over-rev ANY
engine when starting, particularly
a turbocharged engine
Do NOT add aftermarket devices
to alter the engine’s ignition, fuel
delivery, or turbo boost pressure,
this may lead to serious engine
damage and void your warranty
Tire Pressure Monitoring
System (TPMS)
Warning light illuminates for
a few seconds with ignition on
If tire pressure is low, warning
light illuminates with audible
beep sound, adjust tire pressure
to correct specifications, perform
tire pressure adjustment before
driving, a digital tire pressure
gauge is recommended
Flashing warning light may
indicate malfunction, dealer
inspection required
If the total seated weight
is greater than approximately
93 lb., light does not illuminate,
and the air bag/pretensioner
will deploy/activate in an
appropriate accident
See Owner’s Manual for additional
information on this feature and
the air bag system
Passenger sensing
operation
See Driver’s View
Passenger air bag deactivation
indicator on dash will illuminate
when passenger air bag is
deactivated, child-restraint seat
with child that weighs a combined
total of 66 lbs. or less will deactivate
front passenger air bag/pretensioner
See Owner’s Manual
Getting
Started
Getting
Started
WARNINGS: Even with
a deactivation system,
never place rear-facing
infant-safety seat in front
of any air bag, an infant
is in serious danger of being
injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
Fuel filler door
Located on
passenger side
Passenger air bag
deactivation indicator light
Front air bag deactivation indicator
light (1) provides current status
of front passenger air bag and
pretensioner system
If total seated weight on front
passenger seat is less than
approximately 66 lb., front
passenger air bag deactivation
indicator light illuminates,
air bag/pretensioner will not
deploy/activate in an accident
*Denotes optional equipment
1
PASS AIR BAG
OFF

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Steering-
wheel
audio
controls*
To increase/
decreasevolume:
Press (5)
Radio: Press (6) less than
one second to select next/previous
preset station, press (6)
more than one second until
beep sound is heard to seek
next/previous station
Cassette*/CD: Press (6) to
select next selection/track,
press (6) to repeat current
selection/track
Press (7) to select FM1, FM2, AM,
SAT 1*, 2*, 3*, CD, Cassette*and
other media devices plugged into
auxiliary jack (auxiliary jack located
in center console, see Driver’s View)
Press (8) to mute audio/NAVI system
/
/
Tilt/
telescopic
steering-
wheel lever
Pull lever (9) down
to unlock column,
position tilt angle and
length of steering
column position
Tip: Telescopic function allows
steering wheel to be adjusted
closer or farther according to
driver’s reach
WARNING: Do not adjust
steering-wheel while driving
Panic alarm: Press (3); horn sounds,
parking lights flash; press any
button on transmitter to stop
After unlocking with the transmitter,
all doors or the liftgate will
automatically lock if a door or
the liftgate is not opened within
about 30 seconds
HID headlights
leveling switch*
Adjusts headlight angle to
compensate for weight
of passengers and cargo,
see Owner’s Manual
Getting
Started
Getting
Started
Instrument panel lighting
With headlights ON:
To brighten/dim
turn thumbwheel
up/down
Headlights/parking lights
ON, ignition key must
be ON: Illumination
changes brightness
when dimmer switch (4) is pressed
(if equipped with black-out meter)
With headlights OFF
†, key ON:
Press instrument cluster dimmer
select button (4) to select
between 5 brightness settings
for instrument cluster
Cruise
control*
Operates
above 19 mph
Press MAIN (1)
to turn system
on/off
To set speed: Accelerate to desired
speed and press SET/COAST (3)
To accelerate: Press and hold
RES/ACCEL (2); release button
at desired speed
To decelerate: Press and hold
SET/COAST (3); release button
at desired speed
Incremental acceleration: Press and
release (2); each tap = plus 1 mph
Incremental deceleration: Press and
release (3); each tap = minus 1 mph
To cancel: Press CANCEL (4) or
MAIN (1); tap brake pedal or
depress clutch pedal*
Remote entry system* Functions only with ignition
key not inserted
To lock doors: Press LOCK (1);
pressing again within 5 seconds
causes doors/liftgate to re-lock,
horn to beep onceand hazard
warning lights to flash once if
doors/liftgate properly closed
To unlock: Press UNLOCK (2) for
driver’s door, hazard warning
lights will flash twice, press again
within 5 seconds for all other doors
576
8
RES
ACCEL
SET
COAST ON
OFF
CANCEL
1
42
3
9
4
LOCK
UNLOCK1
2
3
123
*Denotes optional equipment†See Owner’s Manual

21
AUTO
GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Turn signal/lighting
control lever
OFF= Lights off
= Tail, parking and
dashboard lights on: Rotate
knob (1) to first notch
= Tail, parking, dashboard
and headlights on: Rotate
knob (1) to second notch
AUTO*= With ignition switch
in ON position; headlights and
exterior lights automatically turn
ON/OFF depending on surrounding
darkness/lightness; rotate knob
(1) to third notch
High beams on/off: Push
forward/pull back to detent
To flash high beams: Pull back
slightly and release
Turn signals right/left: Move
lever up/down
= Fog lights* on: Rotate (
2);
functions only with headlight
low beams on
Tip: Headlights switch off,
parking lights remain on,
if lights are left on and
switch is in lock position
or key removed
REAR
1
REAR
13
INT
REAR
12
INT
Wiper/washer control leverSingle wipe: Push lever up
Washer: Pull back, also
operates wipers
Intermittent wiper: One click down
To change interval speed:
Rotate inner ring* (2)
Normal wiper speed: Two clicks down
High-speed wiper: Three clicks down
Auto*: One click down
Rain sensor senses rain amount
on windshield, then controls
wiper automatically
Rain sensor sensitivity is adjusted
from high sensitivity (+) to less
sensitivity (
-) by rotating ring (3)
Getting
Started
Getting
Started
Rear window wiper/
washer (5-Door only)
To activate rear interval wiper:
Rotate knob (1) up to INT
To activate rear normal speed
wiper: Rotate knob (1) up to ON
To activate rear washer: Rotate
knob (1) to and release
*Denotes optional equipment

INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
WARNING LIGHTS
• Cruise control on*,Amber light: Cruise control
system activated
Green light: Cruising speed set;
see Getting Started
• Tire Pressure Monitoring
System (TPMS)*,
see Getting Started
• Turn signals/hazard
warning on
• High beams on
• Engine oil-pressure
warning light
Stop car when safe and turn
off engine; check oil level
• Brake system
Parking brake on/low brake fluid
GAUGES
1. Fuel gauge
15-gallon/55-liter tank
(2.0L and 2.3L engines)
2. Odometer/Trip meter
3. Gear indicator (A/T only)*
Displays current gear
position
4. Tachometer
• Always fasten seat belts
• Security indicator light*
• Lights on
• Charging system
warning light
Charging system malfunction;
dealer inspection required
• Air bag/front seat belt
pretensioner system
If light flashes or stays on, the air
bags/front seat belt pretensioners
may not operate in an accident;
dealer inspection required
• Dynamic Stability
Control (DSC)*,
see Driving Tips
• Traction Control/
Dynamic Control System off*DSC
OFF
5. Instrument cluster
dimmer select button*,
see Getting Started
6. Speedometer
7. Odometer/Trip meter
selector
Press to view odometer; press
again to reset trip odometer
A/B settings
Instrument
Cluster
Instrument
Cluster
nim/0001x
H
P
TRIPA80.0
RNDM8
C
F
E
5748
6
1 32
hpm
km/h
80220 200 180
160
140
120
100
60
40
20
0
0 20 40 6080100120
1400 1 2 3 4567
8
• Door ajar
• Power steering
malfunction
Dealer inspection required if light
remains on
• Check engine
Dealer inspection required
• OLow fuel
• Automatic
transaxle warning light*
Automatic transaxle malfunction;
dealer inspection required
• Anti-lock Brake
System (ABS)*
ABS malfunction, normal brakes
only; dealer inspection required
• Low washer fluid
level warning light
8. Engine coolant
temperature gauge
Stop car if above normal
range, turn off engine, let
vehicle cool; check coolant
level when safe
CRUISE
*Denotes optional equipment

LOCKS
Always check the Owner’s Manual for more operating information and safety features
Locks
Locks
Key
Operates ignition and
all locks
Tip: Use key number
plate to purchase a new
key; store in safe place
separate from vehicle
Retractable key
To fold/unfold press release
button (1)
Remote entry system*See Getting Started
Immobilizer system
Prevents engine from running
unless coded key is used,
see Owner’s Manual
Illuminated entry system
Activates interior lights when dome
light switch set to DOOR position;
lights off after driver’s door is
locked or ignition in ON positionPower door
locks*
Master
front door
locks
switches
To lock/unlock all doors:
Press bottom/top of switch (2)
To lock doors without key:
With door open, press bottom
of door lock switch, exit car,
close doors
To unlock: Use key to unlock
driver’s front door, rotate key to
counterclockwise position for
more than one second to unlock
other doors
Manual door locks
Lock button
To lock: Press front of button
(3) toward door handle
To unlock: Pull front of button
away from door handle
LOCK
UNLOCK
Child-safety locks
Located at the edge of rear doors
To activate: Rotate childproof lock
(1) in direction of arrow using key
tip (doors open from outside only);
rotate in opposite direction
to deactivate
WARNINGS: Since children
may access either rear door,
child-safety locks for both rear
doors should be activated
Never leave a child in car
with key in the vehicle
Liftgate
To open: Pull up on handle (2)
and raise
To close: Push liftgate down with
both hands until it securely locks;
do not slam liftgateLuggage
compartment
internal safety
release
Allows you to
escape should you
become locked
in trunk
Slide illuminated release lever in
direction of arrow; lever will glow
if it has been exposed to light
Located on interior trunk lid
LOCKFERME12
LOCK UNLOCK
23
1
*Denotes optional equipment

1. Map/reading light switch*
Press on/off
2. Interior light switch
DOOR = light on when door open
ON = light always on
OFF = light always off
3. Front interior light
4. Rear interior light
OFFDOOR
T
IL
TS
L
ID
E
121
3356
ONOFFDOOR
2
47
ON
O
FF
WINDOWS/MIRRORS
Always check the Owner’s Manual for more operating information and safety features
Windows/
Mirrors
Interior
Lights
Power windows*
Ignition must be on
All windows controlled from the
driver’s armrest; passenger doors
have separate switches
1.Driver’s window: One-touch-
down; push down firmly and
release, window goes down
all the way; pull switch back
briefly to stop; press lightly and
hold for normal operation2.Passenger window
switches: Push down
and hold to open, pull
back and hold to close
3.Power window lockout switch:
Press down until it clicks, only
driver’s window operates;
press again and passenger
window switches function again
AU
TO
1
3
2
Dual power mirrors*
Ignition must be in ACC or ON
To adjust left/right mirror:
Press control switch (1) left/right,
press switch (2) in direction of
desired mirror movement
Tip: To lock mirrors in
place, move control switch
to center position
Manual
mirrors
To adjust:
Move knob (3)
on door
1
23
5. Moonroof tilt switch*
Press rear of switch to tilt
rear of moonroof
Press front of switch to close
6. Moonroof slide switch*
Press rear of switch to
open moonroof
Press front of switch to close7. Cargo light* (5-Door)
ON = Light always on
OFF = Light always off
Cargo light* (4-Door)
Light on with trunk open
See Trunk/Cargo Area
Driver/passenger
covered visor mirrors
To access mirror: Lower visor
*Denotes optional equipment
