BOOT
The boot tailgate (when unlocked) can be opened only from the
outside through the electric opening handle set above the number
plate holder.
If doors are unlocked the boot can be opened at any time.
Through the set-up menu of the cluster display (see “Reconfigurable
multifunction display” in the present chapter) it is possible to activate
the “Independent boot unlocking”: in this way the boot is not
unlocked together with the doors; to open it press button
Ron the
remote control.
The tailgate opening is indicated by double flashing of direction
indicators.L0D0104m
L0D0016m
REAR MANUAL WINDOW CONTROLS
(where fitted)
Operate the handle to open or to close the window.
L0D0156m

284
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
IN AN
EMERGENCY
Fuse box in engine compartment
USERFUSE AMPERE
Dashboard control unit 1F1 70
Power steering control unitF2 70
Ignition switchF3 20
Dashboard control unit 2F4 50
ABS / ESP control unitF5 60
Radiator electric fan (low speed) (all versions)F6 30
Radiator electric fan (high speed) (all versions excluded 1.4 16V heated) F7 40
Climate control electric fanF8 30
Headlight washerF9 20
HornF10 15
Electronic injection secondary servicesF11 15
Right main beam headlightF14 10
Left main beam headlightF15 10
Electronic injection primary servicesF17 10
+30 Engine control unit / Radiator electric fan remote control switch (1.9 Multijet) (*) F18 7,5
CompressorF19 7,5
Heated diesel oil filter (Multijet)F20 30
Fuel pumpF21 15
Electronic injection primary services (1.4 16V)F22 15
Electronic injection primary services (Multijet)F22 20
Dual FuNction System gearbox oil pumpF23 15
Dual FuNction System gearbox fuse box power supply (+ key) F16 7,5
+15 Electric power steering (*)F24 7,5
Front fog lightsF30 15
(*) +30 = battery directive positive terminal (not under key)
+15 = positive terminal under key

286
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
IN AN
EMERGENCY
IF THE BATTERY IS FLAT
WARNING The battery charging procedure is
described only for information purposes. This
operation should be carried out by Lancia
Dealership.
Charging should be slow at low amp rating for 24
hours. Charging for a longer time may damage the
battery.
Charge the battery as follows:
❒disconnect battery negative terminal;❒connect the charger cables to the battery
terminals, observing the poles;
❒turn on the charger;
❒when you have finished, turn the charger off
before disconnecting the battery;
❒reconnect battery negative terminal.
WARNING If the vehicle is fitted with alarm system,
turn it off with the remote control (see “Alarm” in
the “Dashboard and controls” chapter).
The liquid in the battery is poisonous and corrosive. Do not let it touch the skin or
eyes. Recharging the battery should be done in a well ventilated area away from
naked flames or possible sources of sparks: explosion and fire risk.
WARNING
WARNING
Do not attempt to recharge a frozen battery. Thaw it first, otherwise it could
explode. If the battery froze, make sure the internal elements are not broken
(short-circuit risk) and that the casing is not cracked (risk of spilling the
poisonous and corrosive fluid).
