Maintenance
After driving through deep water, inspect your vehicle
fluids and lubricants (engine oil, transmission oil, axle,
transfer case) to assure the fluids have not been contami-
nated. Contaminated fluid (milky, foamy in appearance)
should be flushed/changed as soon as possible to pre-
vent component damage.
Driving In Snow, Mud and Sand
In heavy snow, when pulling a load, or for additional
control at slower speeds, shift the transmission to a low
gear and shift the transfer case to 4L or 4LO if necessary.
Refer to “Four-Wheel Drive Operation” in this section.
Do not shift to a lower gear than necessary to maintain
headway. Over-revving the engine can spin the wheels
and traction will be lost.
Avoid abrupt downshifts on icy or slippery roads, be-
cause engine braking may cause skidding and loss of
control.
Hill Climbing
NOTE:Before attempting to climb a hill, determine the
conditions at the crest and/or on the other side.
Before climbing a steep hill,shift the transmission to a
lower gear and shift the transfer case to 4L or 4LO. Use
first gear and 4L or 4LO for very steep hills.
If you stall or begin to lose headwaywhile climbing a
steep hill, allow your vehicle to come to a stop and
immediately apply the brakes. Restart the engine and
shift to R (Reverse). Back slowly down the hill allowing
the compression braking of the engine to help regulate
your speed. If the brakes are required to control vehicle
speed, apply them lightly and avoid locking or skidding
the tires.
STARTING AND OPERATING 237
5

WARNING!
If the engine stalls or you lose headway or cannot
make it to the top of a steep hill or grade, never
attempt to turn around. To do so may result in
tipping and rolling the vehicle. Always back care-
fully straight down a hill in R (Reverse) gear. Never
back down a hill in N (Neutral) using only the brake.
Remember, never drive diagonally across a hill-always
drive straight up or down.
If the wheels start to slip as you approach the crest of a
hill, ease off the accelerator and maintain headway by
turning the front wheels slowly left and right. This may
provide a fresh “bite” into the surface and will usually
provide traction to complete the climb.
Traction Downhill
Shift the transmission into a low gear and the transfer
case to 4L or 4LO range. Let the vehicle go slowly down
the hill with all four wheels turning against engine
compression drag. This will permit you to control the
vehicle speed and direction.
When descending mountains or hills, repeated braking
can cause brake fade with loss of braking control. Avoid
repeated heavy braking by downshifting the transmis-
sion whenever possible.
After Driving Off-Road
Off-road operation puts more stress on your vehicle than
does most on-road driving. After going off-road it is
always a good idea to check for damage. That way you
can get any problems taken care of right away and have
your vehicle ready when you need it.
238 STARTING AND OPERATING

Call Toll Free at:
•1–800–890–4038 (U.S.)
•1–800–387–1143 (Canada)
Or
Visit us on the World Wide Web at:
•www.techauthority.daimlerchrysler.com
•www.daimlerchrysler.ca/manuals
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES
The following describes the tire grading categories estab-
lished by the National highway Traffic Safety Adminis-
tration. The specific grade rating assigned by the tire’s
manufacturer in each category is shown on the sidewall
of the tires on your car.All Passenger Car Tires Must Conform to Federal Safety
Requirements in Addition to These Grades.
Treadwear
The treadwear grade is a comparative rating based on the
wear rate of the tire when tested under controlled con-
ditions on a specified government test course. For ex-
ample, a tire graded 150 would wear one and a half (1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to variations
in driving habits, service practices and differences in road
characteristics and climate.
Traction Grades
The traction grades, from highest to lowest, are AA, A, B,
and C. Those grades represent the tire’s ability to stop on
wet pavement as measured under controlled conditions
IF YOU NEED CONSUMER ASSISTANCE 397
9

on specified government test surfaces of asphalt and
concrete. A tire marked C may have poor traction perfor-
mance.
WARNING!
The traction grade assigned to this tire is based on
straight-ahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
Temperature Grades
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of heat
and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden tire failure. Thegrade C corresponds to a level of performance which all
passenger car tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades B and A repre-
sent higher levels of performance on the laboratory test
wheel than the minimum required by law.
WARNING!
The temperature grade for this tire is established for
a tire that is properly inflated and not overloaded.
Excessive speed, under inflation, or excessive load-
ing, either separately or in combination, can cause
heat buildup and possible tire failure.
398 IF YOU NEED CONSUMER ASSISTANCE

Rear Servicing........................ 365
Rear Tail............................ 365
Seat Belt Reminder..................... 173
Security Alarm (Theft Alarm).............. 172
Sentry Key........................... 172
Service.............................. 362
Side Marker.......................... 365
Tire Pressure Monitoring (TPMS)........... 166
Traction Control....................130,175
Transfer Case......................171,172
Transmission Warning................... 171
Turn Signal............... 117,119,166,363,365
Warning (Instrument Cluster Description)..... 166
Loading Vehicle......................... 280
Tires ............................... 249
Locks................................. 26
Automatic Door........................ 29
Child Protection........................ 30
Door.............................. 26,28Power Door........................... 29
Steering Wheel......................... 16
Lower Anchors and Tether for CHildren
(LATCH)............................ 68,69
Lubrication, Body....................... 331
Luggage Carrier......................... 159
Luggage Rack (Roof Rack)................. 159
Maintenance Free Battery.................. 327
Maintenance Procedures................... 320
Maintenance Schedule.................... 370
Schedule “A”......................... 385
Schedule “B”......................... 373
Maintenance Schedules.................... 370
Maintenance, Sunroof..................... 150
Malfunction Indicator Light (Check Engine) . . 168,318
Manual, Service......................... 396
Manual Transmission..................216,344
Fluid Level Check...................... 344
INDEX 409
10

Towing ............................282,311
Disabled Vehicle....................... 311
Guide .............................. 287
Recreational.......................... 296
Weight .............................. 287
Trac-Lok Rear Axle...................... 234
Traction Control......................... 127
Traction Control Light.................... 175
TrailerTowing .......................... 282
Cooling System Tips.................... 296
Hitches............................. 286
Minimum Requirements................. 290
Trailer and Tongue Weight................ 289
Wiring .............................. 293
TrailerTowingGuide ..................... 287
TrailerWeight .......................... 287
Transfer Case........................226,343
Four-Wheel-Drive Operation.............. 226
Maintenance.......................... 343Transmission
Automatic........................221,345
Maintenance.......................344,345
Manual............................. 216
Shifting ............................. 220
Warning Light........................ 171
Transmitter Battery Service
(Remote Keyless Entry).................... 26
Transmitter, Garage Door Opener (HomeLink) . . 143
Transmitter Programming
(Remote Keyless Entry).................... 24
Transporting Pets........................ 73
Tread Wear Indicators.................... 257
Trip Odometer.......................... 170
Turn Signals................... 119,166,363,365
UConnect™ (Hands-Free Phone).............. 85
Underhood Fuses........................ 356
Uniform Tire Quality Grades................ 397
416 INDEX
