2007 JEEP GRAND CHEROKEE fog light bulb

21. Electronic Throttle Control (ETC) Warning Light
This light informs you of a problem with the
Electronic Throttle Control system. If a problem
is detected the light will come on while the
engine is running. Cycle the ignition key when
the vehicle has completely stopped and the gear selector
is placed in the P (Park) position. The light should turn
off. If the light remains lit with the engine running your
vehicle will usually be drivable, however, see your dealer
for service as soon as possible. If the light is flashing
when the engine is running, immediate service is re-
quired and you may experience reduced performance, an
elevated/rough idle or engine stall and your vehicle may
require towing. The light will come on when the ignition
is first turned on and remain on briefly as a bulb check.
If the light does not come on during starting, have the
system checked by an authorized dealer.22. Front Fog Light Indicator LightÐ If Equipped
This light shows the front fog lights are ON.
23. Voltage Warning Light
This light monitors the electrical system voltage.
The light should turn on momentarily as the
engine is started. If the light stays on or turns on while
driving, it indicates a problem with the charging system.
Immediate service should be obtained.
24. Low Fuel Warning Light
When the fuel level reaches approximately 2.3 U.S.
Gallons (8.7 Liters) this light will come on and
remain on until fuel is added. The Low Fuel
Warning Light may turn on and off again, especially
during and after hard braking, accelerations, or turns.
This occurs due to the shifting of the fuel in the tank.
Also, a single chime will sound.
178 UNDERSTANDING YOUR INSTRUMENT PANEL

insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Lights Bulb Type
Glove Box Light......................... 194
Grab Handle Light................L002825W5W
Overhead Console Reading Lights..........VT4976
Rear Cargo Light.......................214±2
Visor Vanity Light.....................V26377
Underpanel Courtesy Lights................. 906
Instrument Cluster (General Illumination)....... 103
Telltale/Hazard Light...................... 74
* Available only from authorized dealers.Exterior Lights Bulb Type
Backup Lights.........................3157K
Front Fog Lights........................9145
Front Park/Turn Light...................3157K
Front Side Marker.......................2825
Headlights (Low Beam)...................9006
Headlights (High Beam)...................9005
Rear License Plate Light.................... 168
Rear Stop/Tail Lights....................3157K
Rear Turn/Tail Lights (2)..................3157
NOTE:Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
340 MAINTAINING YOUR VEHICLE

3. Turn the turn signal bulb 1/4 turn counter clockwise
to remove from housing.
4. Disconnect the electrical connector and replace the
bulb.CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
Front Fog Light
1. Reach behind the front fascia from under the vehicle.
2. Turn the front fog light bulb 1/4 turn counter clock-
wise to remove from housing.
3. Disconnect the electrical connector and replace bulb.
MAINTAINING YOUR VEHICLE 343
7

LATCH
(Lower Anchors and Tether for CHildren).....58,60
Lead Free Gasoline...................... 270
Leaks, Fluid............................ 67
Life of Tires............................ 264
Liftgate................................ 32
Liftgate Flipper Glass...................... 33
Liftgate Window Wiper/Washer............. 164
Lights..............................67,114
Airbag............................52,173
Alarm............................... 66
Anti-Lock........................... 173
Automatic Headlights................... 115
Back-Up............................. 344
Battery Saver......................... 114
Brake Assist Warning.................136,176
Brake Warning........................ 172
Bulb Replacement...................... 341
Cargo .............................. 158Center Mounted Stop................... 345
Cruise.............................. 177
Daytime Running...................... 117
Dimmer Switch, Headlight............. 114,119
Electronic Stability Program (ESP)
Indicator.......................136,174,176
Electronic Throttle Control Warning......... 178
Fog .......................... 118,178,343
Fuses............................... 333
Hazard Warning Flasher................. 292
Headlight Switch...................... 115
Headlights........................... 341
Headlights On With Wipers............... 115
High Beam Indicator.................... 172
Illuminated Entry....................... 19
Instrument Cluster................... 115,117
Interior........................... 117,119
Lights On Reminder.................... 118
Low Fuel............................ 178
INDEX 385
