2007 JEEP COMPASS Owners Manual

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (175 000) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, or at 3
months whichever comes first.XXXXXX
Change Automatic Transaxle (CVT) Fluid and FilterX
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X
Check spare tire for proper pressure and correct stowage.XXX
Inspect brake linings. X
Replace engine air cleaner filter.XX
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required.XX
Flush and replace engine coolant, if not replaced at
102,000 miles (170 000 km).X
** This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions
warranty.
SCHEDULE “B” 377
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule “A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000 ) (50 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X
Inspect auto tension drive belt and replace, if re-
quired.X
Inspect engine air cleaner filter, replace if neces-
sary.
Replace engine air cleaner filter.XX
Replace spark plugs.X
378 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54000 60,000 66,000
(Kilometers) (60 000) (70 000) (80 000) (90 000) (100 000) (110 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X XXXXX
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X XXXXX
Check spare tire for proper pressure and correct
stowage.X X XXXX
Flush and replace engine coolant at 60 months, if
not replaced at 102,000 miles (170 000 km).X
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if necessary.X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
Inspect auto tension drive belt and replace, if required.X
SCHEDULE “A” 379
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 72,000 78,000 84,000 90,000 96,000
(Kilometers) (120 000) (130 000) (140 000) (150 000) (160 000)
[Months] [72] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X X
Inspect engine air cleaner filter, replace if neces-
sary.XX
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
380 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102,000 108,000 114,000 120,000
(Kilometers) (170 000) (180 000) (190 000) (200 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Change Rear Drive Assembly (RDA) fluid. X
Change Power Transfer Unit (PTU) fluid. X
Rotate tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Flush and replace engine coolant, if not done at 60 months. X
Flush and replace engine coolant, if not done at 102,000
miles (170 000 km)X
Inspect brake linings. X
Inspect auto tension drive belt and replace, if required. X X
Inspect engine air cleaner filter, replace if necessary.X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.**X
SCHEDULE “A” 381
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

** This maintenance is recommended by the manufac-
turer to the owner, but not required to maintain the
emissions warranty.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
382 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle ..............................384
▫Prepare For The Appointment............384
▫Prepare A List........................384
▫Be Reasonable With Requests.............384

If You Need Assistance...................384

Warranty Information (U.S. Vehicles Only).....387

MoparParts.........................387
Reporting Safety Defects..................387
▫In Canada..........................387

Publication Order Forms..................388

Department Of Transportation Uniform Tire
Quality Grades........................389
▫Treadwear..........................389
▫Traction Grades......................389
▫Temperature Grades...................390
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
384 IF YOU NEED CONSUMER ASSISTANCE
