NOTE:If your vehicle is equipped with a non-matching
full size spare tire, a low non-matching full size spare tire
will not display any text messages, or cause the “Tire
Pressure Monitoring Telltale Light” to illuminate or the
chime to sound.
NOTE:Your system can be set to display pressure units
in PSI, kPa, or BAR.Should a low tire condition occur on any of the four
active road tire(s), you should stop as soon as possible,
and inflate the low tire(s) that is flashing on the graphic
display to the vehicle’s recommended cold tire pressure.
The system will automatically update, the graphic dis-
play of the pressure value(s) will stop flashing, and the
“Tire Pressure Monitoring Telltale Light” will extinguish
once the updated tire pressure(s) have been received. The
vehicle may need to be driven for up to 10 minutes above
15 mph (24 km/h) to receive this information.
Service Tire Pressure System
The “Tire Pressure Monitoring Telltale Light” will flash
on and off for 60 seconds, and an audible chime will
sound when a system fault is detected. The flash cycle
will repeat every ten minutes, without an audible chime,
until the fault condition no longer exists.
STARTING AND OPERATING 303
5

The EVIC will display the “SERVICE TIRE PRESS. SYS-
TEM” message for 3 seconds. This text message is then
followed by a graphic, with “- -“ displayed for the pressure
value(s) indicating which of the Tire Pressure Monitoring
Sensor(s) is not being received. Refer to “Electronic Vehicle
Information Center (EVIC)” in Section 4 of this manual.
NOTE:Your system can be set to display pressure units
in PSI, kPa, or BAR.If the ignition key is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault
no longer exists, the “Tire Pressure Monitoring Telltale
Light” will no longer flash, theSERVICE TIRE PRESS.
SYSTEMtext message will no longer display, and a
pressure value will be displayed instead of dashes.
NOTE:If your vehicle is equipped with a matching full
size spare tire, it has a tire pressure monitoring sensor,
and can be monitored by the Tire Pressure Monitoring
System (TPMS). In the event that the matching full size
spare tire is swapped with a low pressure road tire, the
next ignition key cycle will still show the “Tire Pressure
Monitoring Telltale Light” to be ON, a chime to sound, a
Low Pressure message to appear in the EVIC, and the
graphic display will still show the low tire pressure value
flashing. Driving the vehicle for up to 10 minutes above
15 mph (24 km/h) will turn OFF the “Tire Pressure
Monitoring Telltale Light” as long as the matching full
size spare tire or any other road tire(s) are not below the
304 STARTING AND OPERATING

low pressure warning threshold. The EVIC will display a
“Spare Low Pressure” text message, and the graphic
display will show a new tire pressure value in place of
the flashing low tire pressure value.
NOTE:If your vehicle is equipped with a non-matching
full size spare tire, it does not have a tire pressure
monitoring sensor. Therefore, it will not be monitored by
the Tire Pressure Monitor System (TPMS). In the event
that the non-matching full size spare tire is swapped with
a low pressure road tire, every ignition key cycle will still
show the “Tire Pressure Monitoring Telltale Light” to be
ON, a chime to sound, a Low Pressure message to appear
in the EVIC, and the graphic display will still show the
low tire pressure value flashing. After the original road
tire has been properly repaired and put back onto the
vehicle in place of the non-matching full size spare tire,
the TPMS will update the graphic display on the EVIC
with a new tire pressure value instead of the flashing low
tire pressure value, and the “Tire Pressure MonitoringTelltale Light” will be OFF as long as none of the road
tire(s) are below the low pressure warning threshold. The
vehicle may need to be driven for up to 10 minutes above
15 mph (24 km/h) to receive this information.
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures have
been established for the tire size equipped on your
vehicle. Undesirable system operation or sensor
damage may result when using replacement equip-
ment that is not of the same size, type, and/or style.
After-market wheels can cause sensor damage. Do
not use tire sealant from a can, or balance beads if
your vehicle is equipped with a TPMS, as damage to
the sensors may result.
STARTING AND OPERATING 305
5

NOTE:Tighten the gas cap about 1/4 turn until you
hear one click. This is an indication that cap is properly
tightened.
If the gas cap is not tighten properly, the Malfunction
Indicator Light will come on. Be sure the gas cap is
tightened every time the vehicle is refueled.
Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged, a
“CHECK GASCAP” message will be displayed in the
EVIC (Electronic Vehicle Information Center). Refer to
“Electronic Vehicle Information Center” in Section 4 of
this manual. Tighten the fuel filler cap until a “clicking”
sound is heard. This is an indication that the fuel filler
cap is properly tightened. Refer to “Onboard Diagnostic
System — OBDII” in Section 7 of this manual for more
information.
WARNING!
A fire may result if gasoline is pumped into a
portable container that is inside of a vehicle. You
could be burned. Always place gas containers on the
ground while filling.
CAUTION!
Damage to the fuel system or emission control
system could result from using an improper fuel
tank filler cap (gas cap). A poorly fitting cap could let
impurities into the fuel system.
316 STARTING AND OPERATING

Shifting Into Neutral (N)
Use the following procedure to prepare your vehicle for
recreational towing.
CAUTION!
It is necessary to follow these steps to be certain that
the transfer case is fully in N (Neutral) before
recreational towing to prevent damage to internal
parts.
1. Depress brake pedal.
2. Turn the ignition key ON, engine off.
3. Shift transmission into N (Neutral).
4. Shift transfer case into N (Neutral).
Hold down N (Neutral) “pin” switch (with a pen, etc.) for
4 seconds until the LED lamp by the switch starts to blink
indicating shift in progress. Lamp will stop blinking (stay
on solid) when Neutral shift is complete. A “4WD
SYSTEM IN NEUTRAL” message will display on the
EVIC (Electronic Vehicle Information Center). Refer to
“Electronic Vehicle Information Center (EVIC)” in Sec-
tion 4 of this manual. (See page 184 for more informa-
tion.)
334 STARTING AND OPERATING

Shifting Out Of Neutral (N)
Use the following procedure to prepare your vehicle for
normal usage.
1. Depress brake pedal.
2. Turn the ignition key ON, engine off.
3. Shift transmission into N (Neutral).
4. Shift transfer case out of N (Neutral).
Hold down N (Neutral) “pin” switch (with a pen, etc.) for
4 seconds until the LED lamp by the switch starts to blink
indicating shift in progress. Lamp will stop blinking (go
out) when shift is complete. The “4WD SYSTEM IN
NEUTRAL” message will no longer be displayed on the
EVIC (Electronic Vehicle Information Center). Refer to
“Electronic Vehicle Information Center (EVIC)” in Sec-
tion 4 of this manual. (See page 184 for more informa-
tion.)5. Shift transmission into P (Park).
6. Start the engine.
7. Shift transmission into D (Drive).
Neutral Switch
336 STARTING AND OPERATING

Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose, improperly installed,
or damaged. A “CHECK GASCAP” message will be dis-
played in the EVIC (Refer to Section 4 of this manual).
Tighten the gas cap until aclickingsound is heard. This is
an indication that the gas cap is properly tightened.
This message may be temporarily overridden by pressing
either the C/T, STEP, or MENU buttons. However, after
one minute of no customer interaction, the EVIC will
display again the “CHECK GASCAP” message. The
message will remain displayed until the vehicle diagnos-
tic system can retest the fuel system. The test will
perform the next time the vehicle is started, if the vehicle
was keyed off above 40°F (4°C) outside temperature and
the following vehicle start is above 40°F (4°C) outside
temperature. It may be possible to have a message that
will not clear due to the test being disabled due to low
outside temperatures. If the test is performed and the
problem is gone, the message will disappear.If the problem persists, the message will appear the next
time the vehicle is started. This might indicate a damaged
cap. If the problem is detected twice in a row, the system
will turn on the Malfunction Indicator Light (MIL).
Resolving the problem will turn the MIL light off. See
your authorized dealer for service.EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Lamp)
is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
MAINTAINING YOUR VEHICLE 359
7

Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner to remove accumulations
of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to wipe frost or ice from the
windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield Washers — Front and Rear
On vehicles equipped with a Vehicle Information Center,
the low washer fluid level will be indicated. When the
sensor detects a low fluid level, the windshield will light
on the vehicle graphic outline and the “Washer Fluid
Low” message will be displayed.The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the front of
the engine compartment (on the driver side), and should
be checked for fluid level at regular intervals. Fill the
reservoir with windshield washer solvent (not
antifreeze/coolant) and operate the system for a few
seconds to flush out the residual water.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
374 MAINTAINING YOUR VEHICLE
