DESCRIPTION
Revision: 2007 April2007 M35/M45

Items of output signal to be checked with “DATA MONITOR”.

Items of output signal to be checked with “ACTIVE TEST”.
Shift position signal×
TCMD RANGE SW
[ON/OFF]ICC sensor integrated unit receives shift position signal from
TCM with CAN communication.
×NP RANGE SW
[ON/OFF]ICC sensor integrated unit receives shift position signal from
TCM with CAN communication.
Output shaft revo-
lution signal×VHCL SPD AT
[km/h] or [mph]ICC sensor integrated unit receives A/T vehicle speed sen-
sor signal (output shaft revolution signal) from TCM with
CAN communication.
Current gear posi-
tion signal×GEAR
[1, 2, 3, 4, 5]ICC sensor integrated unit receives current gear position sig-
nal from TCM with CAN communication.
Vehicle speed sig-
nal×ABS actuator and
electric unit (con-
trol unit)VHCL SPEED SE
[km/h] or [mph]ICC sensor integrated unit receives vehicle speed signal
(wheel speed) from ABS actuator and electric unit (control
unit) with CAN communication.
Front wiper request
signal×BCMWIPER SW
[OFF/LOW/HIGH]ICC sensor integrated unit receives front wiper request signal
from BCM with CAN communication. Signal name CAN Transmission unitMonitored Item
[unit]Description
Signal name CAN Reception unitMonitored Item
[unit]Description
Meter display signal×
Combination
meter
(through unified
meter and A/C
amp.)CRUISE LAMP
[ON/OFF]
ICC sensor integrated unit transmits meter display signal to
combination meter (through unified meter and A/C amp.)
with CAN communication. ×OWN VHCL
[ON/OFF]
×VHCL AHEAD
[ON/OFF]
×SET DISP IND
[ON/OFF]
ICC system warning
lamp signal×ICC WARNING
[ON/OFF]ICC sensor integrated unit transmits ICC system warning
lamp signal to combination meter (through unified meter and
A/C amp.) with CAN communication.
Buzzer output signal×BUZZER O/P
[ON/OFF] ICC sensor integrated unit transmits buzzer output signal to
combination meter (through unified meter and A/C amp.)
with CAN communication.
ICC brake hold relay
drive signalICC brake hold
relaySTP LMP DRIVE
[ON/OFF]ICC sensor integrated unit outputs stop lamp drive output
signal to ICC brake hold relay.
Signal name CAN Reception unit Test Item Description
Buzzer output signal×Combination
meter
(through unified
meter and A/C
amp.)ICC BUZZERAble to beep the ICC warning chime with a driving signal
from ICC sensor integrated unit.

Meter display signal

ICC system warn-
ing lamp signal×METER LAMPAble to illuminate the ICC system warning lamp and the
MAIN switch indicator lamp with a driving signal from the
ICC sensor integrated unit.
ICC brake hold relay
drive signalICC brake hold
relaySTOP LAMPAble to turn ON the ICC brake hold relay with a driving sig-
nal from the ICC sensor integrated unit.

DESCRIPTION
ACS-9
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
Components DescriptionNKS004CH
CAN CommunicationNKS004CI
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-52, "CAN Communication Signal Chart" .
ComponentVehicle-to-
vehicle
distance
control modeConventional
(fixed speed)
cruise
control modeBrake assist
(with pre-
view func-
tion)Description
ICC sensor integrated unit×××

Controls vehicle distance by operating electric throttle
control actuator based on that sensor signals and
CAN communication data.

Controls vehicle distance by transmitting deceleration
degree commandment value signal to ABS actuator
and electric unit (control unit) when deceleration with
brake is needed.

Irradiates laser beam, and receives reflected laser
beam to measure distance from preceding vehicle.
ECM×××Transmits accelerator pedal position signal, ICC brake
switch signal, stop lamp switch signal and ICC steering
switch signal to ICC sensor integrated unit through CAN
communication.
ABS actuator and electric
unit (control unit)×××

Transmits vehicle speed signal (wheel speed) and
stop lamp switch signal to ICC sensor integrated unit
through CAN communication.

Receives deceleration degree commandment value
signal from ICC sensor integrated unit, and controls
brake fluid pressure with the ABS motor.
BCM×Transmits front wiper request signal to ICC sensor inte-
grated unit through CAN communication.
TCM××Transmits gear position signal and output shaft revolu-
tion signal to ICC sensor integrated unit through CAN
communication.
Unified meter and A/C amp.×××Receives meter display signal, ICC warning lamp signal
and buzzer output signal from ICC sensor integrated
unit through CAN communication.
ICC brake switch×××Transmits operating signal to ECM when depressing
brake pedal. ICC sensor integrated unit cancels cruise
system at driver's brake operation.
Stop lamp switch×××Transmits operating signal to ECM and ABS actuator
and electric unit (control unit) when depressing brake
pedal. ICC sensor integrated unit cancels cruise system
at driver's brake operation.

ATC-3
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45 INSPECTION FLOW .......................................... 110
Memory Function ................................................. . 111
INSPECTION FLOW ......................................... . 111
Ambient Sensor Circuit ......................................... 112
COMPONENT DESCRIPTION .......................... 112
AMBIENT TEMPERATURE INPUT PROCESS .. 112
DIAGNOSIS PROCEDURE FOR AMBIENT
SENSOR ............................................................ 112
COMPONENT INSPECTION ............................. 114
In-vehicle Sensor Circuit ....................................... 115
COMPONENT DESCRIPTION .......................... 115
DIAGNOSIS PROCEDURE FOR IN-VEHICLE
SENSOR ............................................................ 116
COMPONENT INSPECTION ............................. 117
Sunload Sensor Circuit ......................................... 118
COMPONENT DESCRIPTION .......................... 118
SUNLOAD INPUT PROCESS ........................... 118
DIAGNOSIS PROCEDURE FOR SUNLOAD
SENSOR ............................................................ 118
COMPONENT INSPECTION ............................ 120
Intake Sensor Circuit ............................................ 121
COMPONENT DESCRIPTION ......................... 121
DIAGNOSIS PROCEDURE FOR INTAKE SEN-
SOR .................................................................. 121
COMPONENT INSPECTION ............................ 122
CONTROLLER ....................................................... 123
Removal and Installation of Multifunction Switch . 123
REMOVAL ......................................................... 123
INSTALLATION ................................................. 123
AUTO AMP ............................................................. 124
Removal and Installation of Unified Meter and A/C
Auto Amp. ............................................................ 124
REMOVAL ......................................................... 124
INSTALLATION ................................................. 124
AMBIENT SENSOR ................................................ 125
Removal and Installation ...................................... 125
REMOVAL ......................................................... 125
INSTALLATION ................................................. 125
IN-VEHICLE SENSOR ............................................ 126
Removal and Installation ...................................... 126
REMOVAL ......................................................... 126
INSTALLATION ................................................. 126
SUNLOAD SENSOR .............................................. 127
Removal and Installation ...................................... 127
REMOVAL ......................................................... 127
INSTALLATION ................................................. 127
INTAKE SENSOR ................................................... 128
Removal and Installation ...................................... 128
REMOVAL ......................................................... 128
INSTALLATION ................................................. 128
BLOWER UNIT ....................................................... 129
Removal and Installation ...................................... 129
REMOVAL ......................................................... 129
INSTALLATION ................................................. 129
Disassembly and Assembly ................................. 130
BLOWER MOTOR .................................................. 131
Removal and Installation ...................................... 131
REMOVAL ......................................................... 131
INSTALLATION ................................................. 131INTAKE DOOR MOTOR .........................................132
Removal and Installation ......................................132
REMOVAL .........................................................132
INSTALLATION .................................................132
IN-CABIN MICROFILTER .......................................133
Removal and Installation ......................................133
FUNCTION ........................................................133
REPLACEMENT TIMING ..................................133
REPLACEMENT PROCEDURES .....................133
HEATER & COOLING UNIT ASSEMBLY ...............134
Removal and Installation ......................................134
REMOVAL .........................................................134
INSTALLATION .................................................135
Disassembly and Assembly ..................................137
MODE DOOR MOTOR ............................................139
Removal and Installation ......................................139
REMOVAL .........................................................139
INSTALLATION .................................................139
AIR MIX DOOR MOTOR .........................................140
Removal and Installation ......................................140
REMOVAL .........................................................140
INSTALLATION .................................................140
UPPER VENTILATOR DOOR MOTOR ..................141
Removal and Installation ......................................141
REMOVAL .........................................................141
INSTALLATION .................................................141
HEATER CORE .......................................................142
Removal and Installation ......................................142
REMOVAL .........................................................142
INSTALLATION .................................................142
DUCTS AND GRILLES ...........................................143
Removal and Installation ......................................143
COMPONENT LAYOUT ....................................143
REMOVAL .........................................................145
INSTALLATION .................................................149
REFRIGERANT LINES ...........................................150
HFC-134a (R-134a) Service Procedure ...............150
SETTING OF SERVICE TOOLS AND EQUIP-
MENT ................................................................150
Components .........................................................152
VQ35DE ............................................................152
VK45DE .............................................................153
Removal and Installation of Compressor ..............153
REMOVAL .........................................................153
INSTALLATION .................................................156
Check Disc to Pulley Clearance ...........................156
Removal and Installation of Low-pressure Flexible
Hose and Pipe ......................................................157
REMOVAL .........................................................157
INSTALLATION .................................................157
Removal and Installation of High-pressure Flexible
Hose .....................................................................158
REMOVAL .........................................................158
INSTALLATION .................................................159
Removal and Installation of High-pressure Pipe 1
(Engine Compartment) .........................................159
REMOVAL .........................................................159
INSTALLATION .................................................160
Removal and Installation of Low-pressure Pipe 1

ATC-36
AIR CONDITIONER CONTROL
Revision: 2007 April2007 M35/M45
REAR TEMPERATURE CONTROL SWITCH

Increases or decreases the set temperature.

A temperature for the rear seat with respect to a set temperature for the front seat can be adjusted by
operating switch.

Rear temperature control switch allows to select a temperature every 0.5°C (1°F) in the 18°C (60°F) to
32°C (90°F) range.

When the DUAL switch is ON, temperature for the rear seat changes keeping the temperature difference
between two front seats. [e.g. When lowering the set temperature for the rear seat 1°C (2°F) by operating
rear control switch at a set temperature of 25°C (77°F) for the driver’s seat and 26°C (79°F) for the pas-
senger’s seat, the set temperature for the driver’s seat and passenger’s seat lower 1°C (2°F) and become
24°C (75°F) for the driver’s seat and 25°C (77°F) for the passenger’s seat.]
NOTE:
A set temperature for the rear seat is tied to a set temperature for the passenger’s seat. Therefore, a set
temperature for the rear seat changes in conjunction with a set temperature for the passenger’s seat
(When the set temperature of front seats are independent).
Fail-Safe FunctionNJS000G9

If a communication error exists between the unified meter and A/C amp.,and the AV control unit or NAVI
control unit and multifunction switch for 30 seconds or longer, air conditioner is controlled under the follow-
ing conditions:
Compressor : ON
Air outlet : AUTO
Air inlet : FRE (Fresh)
Blower fan speed : AUTO
Set temperature : Setting before communication error occurs
Display : OFF

ATC-60
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
11 . CHECK INTAKE SENSOR
Press (DEF) switch for the third time. Temperature detected by
intake sensor is indicated on the display.
NOTE:
If the temperature indicated on the display greatly differs from the
actual temperature, check sensor circuit first, and then check sensor.
OK or NG
OK >> GO TO 12.
NG >> Go to Intake Sensor Circuit. Refer to ATC-121, "
Intake
Sensor Circuit" .
12. CHECK CAN COMMUNICATION ERROR
1. Press intake switch.
2. CAN communication error between each unit that uses the uni-
fied meter and A/C amp. can be detected as self-diagnosis
results. (If plural errors occur, the display of each error will blink
twice for 0 - 5 second intervals.)
OK or NG
OK >> 1. Turn ignition switch OFF or AUTO switch ON.
2. INSPECTION END
NG >> Go to CAN communication. Refer to DI-35, "
DTC
[U1000] CAN Communication Circuit" .

Unified meter and A/C amp. - AV control unit or NAVI
control unit
PJIA0153E
SJIA1763E

ATC-68
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
COMPONENT DESCRIPTION
Unified Meter and A/C Amp. (Automatic Amplifier)
The unified meter and A/C amp. has a built-in microcomputer which
processes information sent from various sensors needed for air con-
ditioner operation. The air mix door motor, mode door motor, upper
ventilator door motor, intake door motor, blower motor and compres-
sor are then controlled.
When the various switches and temperature control switch are oper-
ated, data is input to the unified meter and A/C amp. from the AV
control unit / NAVI control unit using CAN communication.
Self-diagnosis functions are also built into unified meter and A/C
amp. to provide quick check of malfunctions in the auto air condi-
tioner system.
Potentio Temperature Control (PTC)
The PTC is built into the multifunction switch. It can be set at an
interval of 0.5°C (1.0°F) in the 18°C (60°F) to 32°C (90°F) tempera-
ture range by pressing temperature control switch. The set tempera-
ture is displayed.
DIAGNOSIS PROCEDURE FOR A/C SYSTEM
SYMPTOM: A/C system does not come on.
RJIA4032E
RJIA4048E
RJIA4049E

ATC-78
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
Mode Door Control Specification
COMPONENT DESCRIPTION
Mode Door Motor
The mode door motors are attached to the heater & cooling unit
assembly. It rotates so that air is discharged from the outlet set by
the unified meter and A/C amp. Motor rotation is conveyed to a link
which activates the mode door.
DIAGNOSIS PROCEDURE FOR MODE DOOR MOTOR
SYMPTOM: Mode door motor does not operate normally.
Perform diagnosis procedure. Refer to AT C - 7 1 , "
DIAGNOSIS PROCEDURE FOR LAN CIRCUIT" .
RJIA1778E
RJIA4057E
RJIA4058E

TROUBLE DIAGNOSIS
ATC-81
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45
Upper Ventilator Door Control Specification
COMPONENT DESCRIPTION
Upper Ventilator Door Motor
The upper ventilator door motor is attached to the heater & cooling
unit assembly. It rotates so that air is discharged from the outlet set
by the unified meter and A/C amp. Motor rotation is conveyed to a
rod which activates the upper ventilator door.
DIAGNOSIS PROCEDURE FOR UPPER VENTILATOR DOOR MOTOR
SYMPTOM: Upper ventilator door motor does not operate normally.
Perform diagnosis procedure. Refer to AT C - 7 1 , "
DIAGNOSIS PROCEDURE FOR LAN CIRCUIT" .
RJIA4061E
RJIA4062E
