2007 HUMMER H3 headlamp

Heavy-Duty Trailer Wiring Package
If your vehicle is equipped with a trailer towing
package, the rear bumper harness will have
a seven-pin universal heavy-duty trailer connector
attached to a bracket on the hitch platform.The trailer towing harness contains the following
seven trailer circuits:
Yellow: Left Stop/Turn Signal
Dark Green: Right Stop/Turn Signal
Brown: Taillamps
White: Ground
Light Green: Back-up Lamps
Red: Battery Feed
Dark Blue: Trailer Brake
If you are charging a remote (non-vehicle) battery,
turn on the headlamps to boost the vehicle
system voltage to properly charge the battery.
308

Headlamp Aiming........................................ 358
Bulb Replacement....................................... 361
Halogen Bulbs........................................... 361
Headlamps................................................ 362
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps............................... 363
License Plate Lamp................................... 364
Replacement Bulbs................................... 365
Windshield Wiper Blade Replacement....... 366
Tires............................................................ 367
Tire Sidewall Labeling............................... 368
Tire Terminology and Denitions............... 372
Ination - Tire Pressure............................. 375
Tire Pressure Monitor System................... 376Tire Inspection and Rotation...................... 381
When It Is Time for New Tires.................. 383
Buying New Tires...................................... 383
Different Size Tires and Wheels................ 385
Uniform Tire Quality Grading..................... 386
Wheel Alignment and Tire Balance............ 387
Wheel Replacement.................................. 387
Tire Chains............................................... 389
If a Tire Goes Flat.................................... 390
Changing a Flat Tire................................. 391
Removing the Spare Tire and Tools.......... 393
Removing the Flat Tire and Installing
the Spare Tire....................................... 396
Storing a Flat or Spare Tire and Tools...... 403
Spare Tire................................................. 405
Section 5 Service and Appearance Care
312

The proper level is from 0 to 3/8 inch (0 mm to
10 mm) below the bottom of the ller plug
hole, located on the rear axle.
What to Use
SeeRecommended Fluids and Lubricants on
page 440to determine which kind of lubricant
to use.
Four-Wheel Drive
It is recommended that the four-wheel drive
transfer case uid be checked and lled by
your dealer.
Front Axle
It is not necessary to regularly check front axle
uid unless you suspect there is a leak or you hear
an unusual noise. A uid loss could indicate a
problem.
It is recommended that the front axle uid be
checked and lled by your dealer.
Headlamp Aiming
The vehicle has a visual optical headlamp aiming
system. The aim has been preset at the factory
and should need no further adjustment.
However, if the vehicle is damaged in an accident,
the headlamp aim may be affected and adjustment
may be necessary.
If oncoming vehicles ash their high beams at
you, this may also mean the vertical aim needs to
be adjusted.
It is recommended that the vehicle is taken to your
dealer for service if the headlamps need to be
re-aimed. It is possible however, to re-aim
the headlamps as described in the following
procedure.
358

The vehicle should be properly prepared as follows:
The vehicle should be placed so the headlamps
are 25 ft. (7.6 m) from a light colored wall or
other at surface.
The vehicle must have all four tires on a level
surface which is level all the way to the wall or
other at surface.
The vehicle should be placed so it is
perpendicular to the wall or other at surface.
The vehicle should not have any snow, ice, or
mud on it.
The vehicle should be fully assembled and all
other work stopped while headlamp aiming is
being performed.
The vehicle should be normally loaded with a
full tank of fuel and one person or 160 lbs
(75 kg) sitting on the driver’s seat.
Tires should be properly inated.
The spare tire is in its original location in
the vehicle.To adjust the vertical aim, do the following:
1. Open the hood. SeeHood Release on
page 321for more information.
2. Find the aim dot on the lens of the headlamp.
3. Measure the distance from the ground to
the aim dot on the headlamp. Record the
distance.
359

4. At the wall or other at surface, measure from
the ground upward the recorded distance from
Step 2 and mark it.
5. Draw or tape a horizontal line the width of the
vehicle at the wall or other at surface where
it was marked it Step 4.
Notice:Do not cover a headlamp to improve
beam cut-off when aiming. Covering a
headlamp may cause excessive heat build-up
which may cause damage to the headlamp.
6. Turn on the headlamps and place a piece of
cardboard or equivalent in front of the
headlamp not being aimed. This should allow
only the beam of light from the headlamp
being aimed to be seen on the at surface.7. Locate the vertical headlamp aiming screws,
which are under the hood near each headlamp
assembly.
The adjustment screw can be turned with an
E8 Torx
®socket or T15 Torx®screwdriver.
Passenger’s Side Shown
360

8. Turn the vertical aiming screw until the
headlamp beam is aimed to the horizontal
tape line. If you turn it clockwise, it will raise
the beam and if you turn it counterclockwise, it
will lower the beam.
The top edge of the cut-off should be positioned
at the bottom edge of the horizontal tape line.
9. Repeat Steps 7 and 8 for the opposite
headlamp.
Bulb Replacement
For the proper type of replacement bulbs, see
Replacement Bulbs on page 365.
For any bulb changing procedure not listed in this
section, contact your dealer.
Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas
inside and can burst if you drop or
scratch the bulb. You or others could be
injured. Be sure to read and follow the
instructions on the bulb package.
361

Headlamps
To replace a headlamp bulb, do the following:
1. Open the hood. SeeHood Release on
page 321for more information.
2. Reach in and access the headlamp bulb
socket from inside the engine compartment.
3. Turn the bulb socket counterclockwise to
remove it from the headlamp assembly
and pull it straight out.4. Unplug the electrical connector by pushing
the release tab and pulling the bulb
socket out.
5. Replace with a new bulb socket.
6. Reinstall the electrical connector.
7. Reinstall the new bulb socket into the
headlamp assembly and turn it clockwise
to secure.
8. Close the hood.
362

4. Turn the bulb socket counterclockwise and
pull the bulb straight out of the license plate
lamp assembly.
5. Install the new bulb into the socket.
6. Insert the bulb socket into the license plate
lamp assembly and turn it clockwise to
secure.
7. Replace the license plate lamp assembly and
tighten the two screws.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up Lamp, Stoplamp,
Taillamp and Turn Signal Lamp3157K
License Plate Lamp 194
Low-Beam and High-Beam
HeadlampH13
For replacement bulbs not listed here, contact
your dealer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for
wear and cracking. SeeScheduled Maintenance
on page 429for more information.
Replacement blades come in different types and
are removed in different ways. For proper type and
length, seeNormal Maintenance Replacement
Parts on page 442.
365
