2007 HONDA ACCORD SEDAN display

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .56
............................
Instrument Panel .57
..........
Instrument Panel Indicators . 58
.............................................
Gauges .64
Odometer/Outside .............
Temperature Display . 64
.....................................
Odometer .64
...
Outside Temperature Display . 64
...................................
Trip Meter .65
...................
Temperature Gauge . 65..................................
Fuel Gauge .66
..........
Check Fuel Cap Indicator . 66
....
Maintenance Minder Display . 66
Controls Near the Steering ...........................................
Wheel .67
......................
Wipers and Washers .68
.................
Turn Signal, Headlights . 69
Automatic Lighting Off .........................................
Feature .70
................
Daytime Running Lights . 70
........
Instrument Panel Brightness . 71
..............................
Hazard Warning .71
.................
Rear Window Def ogger . 72
..........
Steering Wheel Adjustment . 73
...............................
Keys and Locks .74
........................
Immobilizer System .75
................................
Ignition Switch .76
......................................
Door Locks .77
..............
Childproof Door Locks . 78
.......................
Remote Transmitter .78
................................................
Trunk .82
........
Emergency Trunk Opener . 83
....................................
Seat Heaters .84
.................................................
Seats .85
.............
Power Seat Adjustment . 85
...........
Driver’s Lumbar Support . 85.............
Front Seat Adjustments . 86
Driver’s Seat Manual Height ..............................
Adjustment .86
Driver’s Seat Power Height ..............................
Adjustment .87
..........................
Head Restraints .87
.......................
Folding Rear Seat .88
.............................................
Mirrors .90
....
Adjusting the Power Mirrors . 90
..............................
Power Windows .91
Power Window Control ...............................
Operations .93
.........................................
Moonroof .94
.................................
Parking Brake .95
..........................................
Sun Visor .96
..................................
Vanity Mirror .96
.................................
Interior Lights .97
................................
Ceiling Light .97
...........
Individual Interior Lights . 97
...........
Interior Convenience Items . 98
.......................
Beverage Holders .99
..........
Accessory Power Sockets . 99
...............
Console Compartment . 99
....................
Sunglasses Holder .100
..................................
Glove Box .100
Instruments and Controls
Inst rument s and Cont rols
55
Power Mirror Heaters ............... 90

This indicator comes on for a few
seconds when you turn the ignition
switch to the ON (II) position. It will
gooffifyouhaveinserteda
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch from the ON (II) position to
the ACCESSORY (I) or LOCK (0)
position.
This indicator comes on when the
washer fluid level is low. Add washer
fluidwhenyouseethisindicator
come on (see page ).
This
indicator comes on when you
turn on the cruise control master
button (see page ).
This indicator comes on when you
set the cruise control. See page
for information on operating the
cruise control. This
indicator comes on for a few
seconds when you turn the ignition
switch to the ON (II) position. It
remindsyouthatitistimetotake
your vehicle in for scheduled
maintenance. The maintenance main
items and sub items will be displayed
in the information display. See page
f or more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service. 75
145 193
145
210
Canadian models only
Immobilizer System
Indicator
Cruise Control Main
Indicator Maintenance Minder
Indicator
Washer Level Indicator
Cruise Control Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
63

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.The temperature sensor is in the
f ront bumper. Theref ore, the
temperature reading can be af f ected
by heat ref lection f rom the road
surf ace, engine heat, and the
exhaust f rom surrounding traf f ic.
This can cause an incorrect
temperature reading when your
speed is under 19 mph (30 km/h).
The sensor delays the display update
until it reaches the correct outside
temperature. This may take several
minutes.
The odometer and the outside
temperature display use the same
display. To switch the display
between the odometer and the
outside temperature, press the
select/reset knob.
When you turn
the ignition switch to ON (II), what
you last selected is displayed. This display shows the outside
temperature in Fahrenheit (U.S.
models) or Centigrade (Canadian
models). To see the outside
temperature, press and release the
select/reset
knob until the
temperature is displayed.
EX-L and EX-V6
Odometer
Odometer/Outside T emperature
Display Outside Temperature Display
Gauges
64
TACHOMETER
SPEEDOMETER
FUEL GAUGE
TEMPERATURE
GAUGE
TRIP METER
ODOMETER/OUTSIDE
TEMPERATURE INDICATOR
SELECT/RESET KNOB
U.S. model shown INFORMATION
DISPLAY

This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
There are two trip meters: Trip A
and Trip B. Switch between these
displays and the odometer/outside
temperature display by pressing the
select/resetknob repeatedly. Each
trip meter works independently, so
you can keep track of two different
distances. This
shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise into the
upperhalfofthegauge.Ifitreaches
the red (Hot) mark, pull safely to the
side of the road. Turn to page f or
instructions and precautions on
checking the engine’s cooling
system.
If the outside temperature is
incorrectly displayed, you can adjust
it up to 5°F ( 3°C) warmer or
cooler.
NOTE: The temperature must be
stabilized bef ore doing this
procedure.
Select the outside temperature
display, then
press the select/reset
knob f or 10 seconds. The f ollowing
sequences appear, 1 second at a
time:0,1,2,3,4,5, 5, 4, 3, 2, 1, 0, 1 (0, 1, 2, 3, 3, 2, 1, 0, 1).
When the temperature reaches the
desired value, release the select/
r eset knob. Yo u should see the new
outside temperature displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace. When you turn the ignition switch to
the ON (II) position, what you last
selected is displayed.
To reset a trip meter, display it, and
then press and
hold the select/reset
knob until the number resets to ‘‘0.0’’. 160
Trip Meter
Temperature Gauge
Gauges
Inst rument s and Cont rols
65
µµ
µ µ
µ µµ
µ

This shows how much fuel you have.
It may show slightly more or less
th an the actual amount. The needle
returns to the bottom after you turn
off the ignition. The
information display in the
instrument panel shows you the
engine oil life and maintenance
service items when the ignition
switch is in the ON (II) position. This
information helps to keep you aware
of the periodic maintenance your
vehicle needs for continued trouble-
free driving. Refer to page for
more information.
If
your fuel cap is loose or missing, a
‘‘CHECK FUEL CAP’’ message will
appear in the information display. As
soon as it is safely possible, turn the
engine off and check that the fuel
cap is installed. If it is, loosen the cap
and tighten it to at least 1 click.
Al though you can use the select/
resetknobtocyclethefuelcap
warningo ffofthedisplay,itwillbe
displayedagai neachtimetheengine
isstarted.Itwillta keseveraldaysof
normaldrivingforthevehicletotu rn
thewarningoff.
Ifthevehicleonboarddiagnostic
systemcontinue stodetecta
problem,the mal function indicator
lamp(MIL)willilluminate.Ifthe
MILdoesnotgo off, have your
de aler inspect the vehicle. For more
info rmation, see page . 193
254
Fuel Gauge
Check Fuel Cap IndicatorMaintenance Minder Display
Gauges
66
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.

Vents, Heating, and A/C
102
TEMPERATURE
CONTROL DIAL
MAX A/C BUTTON REAR WINDOW
DEFOGGER BUTTON
TEMPERATURE
CONTROL DIAL
(DRIVER’S SIDE)
FAN CONTROL
BUTTONS
TEMPERATURE
CONTROL DIAL
(PASSENGER’S SIDE)
MODE
BUTTON
RECIRCULATION BUTTON AIR
CONDITIONING
BUTTON
AUTO BUTTON
OFF BUTTONDUAL BUTTON WINDSHIELD DEFROST BUTTON
FAN SPEED
INDICATOR
AIR
CONDITIONING
BUTTON MODE BUTTONS RECIRCULATION BUTTON
REAR WINDOW
DEFOGGER
BUTTON
WINDSHIELD
DEFROST BUTTON
FAN CONTROL DIAL
TEMPERATURE DISPLAY
EX-L and EX-V6
without navigation system
U.S.VP,LX,SE,EX,LX-V6,andSE-V6
Canadian DX-G, SE, and SE-V6

Vents, Heating, and A/C
Features
103
AUTO BUTTONMODE ICONS A/C BUTTON
AIR CONDITIONING ICONS
FAN CONTROL ICONS
DUAL BUTTON TEMPERATURE CONTROL
BUTTONS (PASSENGER’S SIDE)
RECIRCULATION BUTTON WINDSHIELD DEFROST BUTTONREAR WINDOW DEFOGGER BUTTON
TEMPERATURE CONTROL
BUTTONS (DRIVER’S SIDE)
OFF BUTTONTEMPERATURE DISPLAY
E
X-L and EX-V6 with navigation system

The climate control system can also
be operated by voice control. See the
Navi section in your quick start
guide f or an overview of this system,
and the navigation system manual
f or complete details.
You can manually select the f an
speed by pressing the f an control
buttons. The f an speed is
represented by vertical bars in the
display.Press the DUAL button. The
indicator in the button will come on.
The driver and passenger can each
select the temperature control
buttons ( or ) to the
desired setting.
When the indicator in the DUAL
button is off, both sides adjust to the
driver’s side temperature.
Turn this dial to increase or decrease
the fan speed and airflow. You can manually select the f an
speed by pressing the A/C button
next to the display, and then
pressing the f an control icons.
Turning this dial clockwise increases
the temperature of the airflow.
The driver and passenger can select
independent temperature settings by
selecting the DUAL button.
Push the DUAL button. When the
indicator in the button is on, turn the
dials to adjust the temperature.
Only on models equipped with
Navigation system
Except EX-L and EX-V6 with navigationsystem
EX-L and EX-V6
EX-L and EX-V6 without navigationsystem EX-L and EX-V6 with navigation system
EX-L and EX-V6
EX-L and EX-V6 with navigation system
EX-L and EX-V6 without navigation system
U.S. VP, LX, SE, EX, LX-V6, and SE-V6
Canadian DX-G, SE, and SE-V6
Vents, Heating, and A/C
Voice Control System
Fan Control T emperature Control
104
ÛÝ
