2007 FORD FUSION (AMERICAS) automatic transmission fluid

SERVICE RECOMMENDATIONS
To help you service your vehicle, we providescheduled maintenance
informationwhich makes tracking routine service easy.
If your vehicle requires professional service, your authorized dealer can
provide the necessary parts and service. Check yourWarranty
Guide/Owner Information Guideto find out which parts and services
are covered.
Use only recommended fuels, lubricants, fluids and service parts
conforming to specifications. Motorcraft parts are designed and built to
provide the best performance in your vehicle.
PRECAUTIONS WHEN SERVICING YOUR VEHICLE
•Do not work on a hot engine.
•Make sure that nothing gets caught in moving parts.
•Do not work on a vehicle with the engine running in an enclosed
space, unless you are sure you have enough ventilation.
•Keep all open flames and other lit material away from the battery and
all fuel related parts.
Working with the engine off
•Automatic transmission:
1. Set the parking brake and shift to P (Park).
2. Turn off the engine and remove the key.
3. Block the wheels.
•Manual transmission:
1. Set the parking brake, depress the clutch and place the gearshift in
1 (First).
2. Turn off the engine and remove the key.
3. Block the wheels.
Working with the engine on
•Automatic transmission:
1. Set the parking brake and shift to P (Park).
2. Block the wheels.
•Manual transmission:
1. Set the parking brake, depress the clutch and place the gearshift in
N (Neutral).
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
227

1. Start the engine and let it run until it reaches normal operating
temperature (the engine coolant temperature gauge indicator will be
near the center of the normal area between H and C).
2. While the engine idles, turn the steering wheel left and right several
times.
3. Turn the engine off.
4. Check the fluid level in the reservoir. It should be between the
MIN/MAX or upper and lower lines. Do not add fluid if the level is in this
range.
5. If the fluid is low, add fluid in small amounts, continuously checking
the level until it reaches the range between the MIN/MAX or upper and
lower lines. Be sure to put the cap back on the reservoir.
BRAKE/CLUTCH FLUID
Brake and clutch systems are supplied from the same reservoir.
The fluid level will drop slowly as
the brakes wear, and will rise when
the brake components are replaced.
Fluid levels between the “MIN” and
“MAX” lines are within the normal
operating range; there is no need to
add fluid. If the fluid levels are
outside of the normal operating
range the performance of the
system could be compromised; seek
service from your authorized dealer
immediately.
TRANSAXLE FLUID
Checking 5–speed automatic transaxle fluid (If equipped)
Refer to yourscheduled maintenance informationfor scheduled
intervals for fluid checks and changes. Your transaxle does not consume
fluid. However, the fluid level should be checked if the transaxle is not
working properly, i.e., if the transaxle slips or shifts slowly or if you
notice some sign of fluid leakage.
Automatic transmission fluid expands when warmed. To obtain an
accurate fluid check, drive the vehicle until it is warmed up
(approximately 20 miles [30 km]). If your vehicle has been
MAX
MIN
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
257

High fluid level
Fluid levels above the safe range
may result in transaxle failure. An
overfill condition of transmission
fluid may cause shift and/or
engagement concerns and/or
possible damage.
High fluid levels can be caused by an overheating condition.
Adjusting automatic transmission fluid levels
Before adding any fluid, make sure the correct type is used. The type of
fluid used is normally indicated on the dipstick and also in the
Maintenance product specifications and capacitiessection in this
chapter.
Use of a non-approved automatic transmission fluid may cause
internal transaxle component damage.
If necessary, add fluid in 1/2 pint
(250 mL) increments through the
filler tube until the level is correct.
If an overfill occurs, excess fluid
should be removed by an authorized
dealer.
An overfill condition of
transmission fluid may cause shift and/or engagement concerns
and/or possible damage.
Do not use supplemental transmission fluid additives, treatments or
cleaning agents. The use of these materials may affect transmission
operation and result in damage to internal transaxle components.
Checking 6–speed automatic transmission fluid (if equipped)
Refer to yourscheduled maintenance informationfor scheduled
intervals for fluid checks and changes. Your transaxle does not consume
fluid. However, the fluid level should be checked if the transaxle is not
working properly, i.e., if the transaxle slips or shifts slowly or if you
notice some sign of fluid leakage.
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
259

Checking automatic transmission fluid at normal operating
temperature (140°F-158°F [60°C-70°C])
Automatic transmission fluid expands when warmed. To obtain an
accurate fluid check, drive the vehicle until it is warmed up
(approximately 20 miles [30 km]) until the engine coolant gauge
indicates normal operating temperature. If your vehicle has been
operated for an extended period at high speeds, in city traffic
during hot weather or pulling a trailer, the vehicle should be
turned off for about 30 minutes to allow fluid to cool before
checking.
1. Drive the vehicle 20 miles (30 km) or until the coolant guage indicates
normal operating temperature.
2. Park the vehicle on a level surface and engage the parking brake.
3. With the parking brake engaged and your foot on the brake pedal,
start the engine and move the gearshift lever through all of the gear
ranges. Allow sufficient time for each gear to engage (approximately
10–15 seconds in each position).
4. Move the gearshift lever to P (Park) and leave the engine running.
5. Remove the dipstick, wiping it clean with a clean, dry, lint-free rag. If
necessary, refer toIdentifying components in the engine compartment
in this chapter for the location of the dipstick.
6. Install the dipstick making sure it is fully seated in the filler tube.
7. Remove the dipstick and inspect
the fluid level. The fluid should read
within the hot range on the dipstick
if at normal operating temperature
(140°F-158°F [60°C-70°C]).
Checking automatic transmission fluid at cool temperature
(59°F-77°F [15°C-25°C])
If a fluid check is necessary at a low
fluid temperature (59°F-77°F
[15°C-25°C]), perform the check
using the cold range on the dipstick.
However, the fluid must be
re-checked at the proper fluid temperature.
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
260

Low fluid level
Do not drive the vehicle if the fluid
level does not show at all on the
dipstick.
Driving the vehicle with less than
the recommended fluid level may result in transaxle failure. An under fill
condition of transmission fluid may cause shift and/or engagement
concerns and /or possible damage to the transaxle.
High fluid level
Fluid levels above the normal
operating range may result in
transaxle failure. An overfill
condition of transmission fluid may
cause shift and/or engagement
concerns and/or possible damage to
the transaxle.
High fluid levels can be caused by an overheating condition.
Adjusting automatic transmission fluid levels
Before adding any fluid, make sure the correct type is used. The type of
fluid used is normally indicated on the dipstick and also in the
Maintenance product specifications and capacitiessection in this
chapter.
Note:Only one ATF fluid specification has been tested and approved for
use with the automatic 6-speed: Premium Automatic Transmission fluid.
Mercon fluids cannot be used with the automatic 6-speed without
damage or voiding warranty.
Use of a non-approved automatic transmission fluid may cause
internal transaxle component damage.
If necessary, add fluid in 1/2 pint (250 mL) increments through the filler
tube until the level is correct.
If an overfill occurs, excess fluid should be removed by an authorized
dealer.
An overfill condition of transmission fluid may cause shift and/or
engagement concerns and/or possible damage.
Do not use supplemental transmission fluid additives, treatments or
cleaning agents. The use of these materials may affect transmission
operation and result in damage to internal transaxle components.
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
261

Item Capacity Ford part nameFord part number /
Ford specification
Engine oil 2.3L engine4.5 quarts
(4.25L)Motorcraft SAE 5W-20
Premium Synthetic
Blend Motor Oil (US)
Motorcraft SAE 5W-20
Super Premium Motor
Oil (Canada)
2
XO-5W20-QSP (US)
CXO-5W20-LSP12
(Canada) /
WSS-M2C930-A with API
Certification Mark Engine oil 3.0L engine 6.0 quarts (5.7L)
Lock cylinders —Motorcraft Penetrating
and Lock LubricantXL-1/
None
Power steering fluidBetween MIN
and MAX on
reservoirMotorcraft MERCON
AT FXT-2-QDX /
MERCON
Manual transmission
fluid3.0 quarts
(2.87L)
3
Motorcraft 75W-90 gear
oil (non-synthetic)XY-75W90-QGL /
WSS-M2C203-A1 and
GL-4
Automatic transmission
fluid 5-Speed7.0 quarts
(6.7L)
4
Motorcraft FNR5
Automatic Transmission
FluidXT-9-QMM5 /
MAZDA V (S)
Automatic transmission
fluid 6-Speed7.4 quarts
(7.0L)
4
Motorcraft Premium
Automatic Transmission
FluidXT-8-QAW /
WSS-M2C924-A
Rear Differential (AWD)
fluid2.4 pints (1.15 L)Motorcraft SAE 80W-90
Premium Rear Axle
LubricantXY-80W90-QL /
WSP-M2C197-A
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
267

A
Accessory delay ..........................68
Air cleaner filter ...............262–264
Air conditioning ....................43, 45
Airbag supplemental
restraint system ........121, 130, 133
and child safety seats ............123
description ..............121, 130, 133
disposal ....................................136
driver airbag ............123, 130, 134
indicator light .........129, 132, 135
operation .................123, 130, 134
passenger airbag .....123, 130, 134
side airbag ...............................130
All Wheel Drive (AWD),
driving off road .........................183
Antifreeze
(see Engine coolant) ................239
Anti-lock brake system
(see Brakes) ..............................174
Anti-theft system ..................96, 99
arming the system ....................99
disarming a triggered
system .....................................100
triggering .................................100
Audio system (see Radio) ...21, 27
Automatic transaxle
fluid, adding ............................257
fluid, checking ........................257
Automatic transmission
driving an automatic
overdrive .........................179–180
fluid, adding ....................259, 262
fluid, checking ................259, 262
fluid, refill capacities ..............266
fluid, specification ..................266Auxiliary Input Jack ...................34
Axle
lubricant specifications ..........266
B
Battery .......................................237
acid, treating emergencies .....237
jumping a disabled battery ....205
maintenance-free ....................237
replacement, specifications ...264
servicing ..................................237
Belt-Minder.............................116
Brakes ........................................173
anti-lock ...................................174
anti-lock brake system (ABS)
warning light ...........................174
fluid, checking and adding ....257
fluid, refill capacities ..............266
fluid, specifications .................266
lubricant specifications ..........266
parking ....................................175
shift interlock ..........................177
Break-in period .............................5
Bulbs ............................................53
C
Capacities for refilling fluids ....266
Cassette tape player ...................21
Cell phone use ..............................7
Changing a tire .........................199
Child safety restraints ..............136
child safety belts ....................136
Child safety seats ......................140
attaching with tether straps ..144
in front seat ............................141
in rear seat ..............................141
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Index
274

Cleaning your vehicle
engine compartment ..............221
instrument panel ....................223
interior .....................................224
interior trim ............................224
plastic parts ............................222
washing ....................................219
waxing .....................................220
wheels ......................................220
wiper blades ............................222
Climate control (see Air
conditioning or Heating) ......43, 45
Clock ............................................66
Clock adjust
6-CD in dash .............................28
AM/FM/CD .................................22
Clutch
fluid ..........................................257
operation while driving ..........182
recommended shift speeds ....182
Compass, electronic
set zone adjustment .................77
Console ........................................65
overhead ....................................65
Controls
power seat ...............................104
steering column ........................72
Coolant
checking and adding ..............239
refill capacities ................243, 266
specifications ..........................266
Cruise control
(see Speed control) ....................69
Cupholder(s) .............................107
Customer Assistance ................190
Ford Extended Service
Plan ..........................................215Getting assistance outside
the U.S. and Canada ..............216
Getting roadside assistance ...190
Getting the service
you need .................................211
Ordering additional
owner’s literature ...................217
Utilizing the Mediation/
Arbitration Program ...............215
D
Daytime running lamps
(see Lamps) ................................50
Dipstick
automatic transmission
fluid ..................................257, 259
engine oil .................................232
Driving under special
conditions ..................181, 185, 187
sand .........................................186
snow and ice ...........................188
through water .................186, 189
E
Electronic message center .........75
Emergencies, roadside
jump-starting ..........................205
Emission control system ..........253
Engine ........................................269
cleaning ...................................221
coolant .....................................239
fail-safe cooling .......................244
idle speed control ...................237
lubrication specifications .......266
refill capacities ........................266
service points ..................229–230
starting after a collision .........192
Engine block heater .................173
2007 Fusion(fsn)
Owners Guide (post-2002-fmt)
USA(fus)
Index
275
