2007 FIAT LINEA Owners Manual

Fiat Group Automobiles S.p.A. - Servizi al Cliente - Assistenza Tecnica - Ingegneria Assistenziale - Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print N. 603.81.255 - 07/2007 - 1stEdition
ENGINE OIL CHANGE
1.4 - 1.4 T-JET - 1.3 Multijet
Tank capacity 45
Reserve5 ÷ 7
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
COLD TYRE INFLATION PRESSURE (bar)
Tyre Medium load Full load
Front Rear Front Rear
185/65 R15 84T 2.3 2.1 2.3 2.3
195/60 R15 88H 2.3 2.1 2.3 2.3
195/55 R16 87H 2.3 2.1 2.4 2.4
205/45 R17 88V 2.4 2.2 2.5 2.4
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
1.4 1.4 T-JET 1.3 Multijet
litres kg litres kg litres kg
Engine sump and filter 2.6 – 2.4 2.6 3.2 –
