2007 DODGE RAM 2500 DIESEL Owners Manual

WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with Mopar Glass Cleaner or any commercial household-
type glass cleaner. Never use an abrasive type cleaner.
Use caution when cleaning the inside rear window
equipped with electric defrosters or the right rear quarter
window equipped with the radio antenna. Do not use
scrapers or other sharp instruments which may scratch
the elements. When cleaning the rear view mirror, spray
cleaner on the towel or rag that you are using. Do not
spray cleaner directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage can also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the car to
wash them.
MAINTAINING YOUR VEHICLE 425
7

Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
Dry with a soft tissue.
FUSES (INTEGRATED POWER MODULE)
An integrated Power Module is located in the engine
compartment near the battery. This center contains car-
tridge fuses and mini fuses. A description of each fuse
and component may be stamped on the inside cover
otherwise the cavity number of each fuse is stamped on
the inside cover that corresponds to the following chart.
Integrated Power Module Location
426 MAINTAINING YOUR VEHICLE

Cavity Cartridge Fuse Mini
Fuse Description
1 20 Amp Yellow Power Outlet Console
2 20 Amp Yellow Cabin Compartment
Node (CCN) Door
Locks/Brake Trans-
mission Shift Inter-
lock (BTSI)
3 20 Amp Yellow Spare
4 20 Amp Yellow Spare
5 20 Amp Yellow Power Sunroof
6 10 Amp Red Occupant Classifica-
tion Module (OCM)/
VIST Fan/WastegateCavity Cartridge
Fuse Mini
Fuse Description
7 15 Amp Blue Reverse Lockout Sole-
noid Battery (SRT-10
Only)
8 10 Amp Red Heated Mirrors
9 30 Amp Pink Off Road Module
Power
10 5 Amp Orange Trx-Off Rd Pkg Sen
(Gas Engine Only)
MAINTAINING YOUR VEHICLE 427
7

Cavity Cartridge Fuse Mini
Fuse Description
11 20 Amp Yellow Ignition Off Draw
(IOD)-Cabin Com-
partment Node
(CCN)/Radio/Under
Hood Lamp/Wireless
Control Module
(WCM)/Satellite Digi-
tal Audio Receiver
(SDARS)/Hands Free
Module (HFM)
12 30 Amp Pink Electric Brake
13 25 Amp Natural Power-Battery
RWAL/ABS Module
Feed
14 15 Amp Blue Park Lamps LeftCavity Cartridge
Fuse Mini
Fuse Description
15 20 Amp Yellow Trailer Park Lamps
16 15 Amp Blue Park Lamps Right
17 15 Amp Blue Spare
18 40 Amp Green ABS Pump
19 30 Amp Pink Trailer Tow
20 10 Amp Red Occupant Restraints
Controller (ORC) 2
21 10 Amp Red Occupant Restraints
Controller (ORC) Pre-
set Carrier
22 2 Amp Gray IGN Switch Feed
428 MAINTAINING YOUR VEHICLE

Cavity Cartridge Fuse Mini
Fuse Description
23 10 Amp Red Engine Control Mod-
ule (ECM)/Wireless
Control Module
(WCM)/HVC
24 20 Amp Blue Subwoofer Amplifier
(SRT-10 Only)
25 10 Amp Red Power Mirror
26 20 Amp Yellow Brake Switch/Center
High Mount Stop
Lamp (CHMSL)
27 40 Amp Green Power Seats
28 10 Amp Red Power Run/Start-
NCC/Wireless Con-
trol Module (WCM)/
ABS/RWALCavity Cartridge
Fuse Mini
Fuse Description
29 10 Amp Red Switches/EC Mirror/
Smart Bar
30 15 Amp Blue Spare
31 10 Amp Red PCM/Transfer Case
Brake
32 10 Amp Red HVAC/Ajustable
Pedals/Heated Seats
Switch LED/Exhaust
Brake
33 10 Amp Red Power-IGN Run Misc
34 10 Amp Red Spare
35 15 Amp Blue Cabin Compartment
Node (CCN) Illumi-
nation
MAINTAINING YOUR VEHICLE 429
7

Cavity Cartridge Fuse Mini
Fuse Description
36 25 Amp Natural Audio_Amplifier
37 15 Amp Blue Spare
38 20 Amp Yellow Power Outlet IP
39 10 Amp Red Sunroof/Seatbelt Ten-
sioner
40 20 Amp Yellow Cigar Lighter
41 25 Amp Natural Spare
42 30 Amp Pink Diesel PCM (Diesel
Only)CAUTION!
•When installing the Integrated Power Module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Integrated Power
Module, and possibly result in a electrical system
failure.
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
430 MAINTAINING YOUR VEHICLE

VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
•Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Integrated Power Module, located in the
engine compartment. The I.O.D. cavity includes a
snap-in retainer that allows the fuse to be discon-
nected, without removing it from the fuse block.
•The electronic shift transfer case should be placed in
the 4HI mode and kept in this position to minimize the
battery drain.
•As an alternative to the above steps you may, discon-
nect the negative cables from both batteries.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
NOTE: When reinstalling the IOD fuse push firmly until
fully seated, the gages in the Instrument Cluster will do
a full sweep, when the ignition key is cycled to RUN. This
is a normal condition.
MAINTAINING YOUR VEHICLE 431
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS — Inside Bulb No.
Overhead Console Lights ............... TS212-2
Dome Light ............................ 7679
All of the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved.
LIGHT BULBS — Outside Bulb No.
Back-Up .............................. 3057
Center High Mounted Stop Lamp ............. 912
Fog Lamp ........................... 9006LL
Headlamp (Halogen) ..................... H13
Side Marker Bulb ....................... W5W Park & Turn Signal
................... 3157NAK
Rear License Plate Lamp ................... 168
Rear Cargo Light ......................... 912
Tail & Stop ............................ 3057
Cab Clearance Lights ...................... 168
Dual Rear Wheel Sidemarker Light ............ 168
Dual Rear Wheel Tailgate ID Lights (3) ......... 168
432 MAINTAINING YOUR VEHICLE
