LIGHT BULBS — Exterior Bulb Number
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Light...................3457A
Front Fog Light—If Equipped. . . 9145/H10 (Serviced at
Dealer)
Front Sidemarker........194NA (Serviced at Dealer)
Tail/Stop/Turn Light...............3157KP27/7W
Rear Sidemarker.................3757APY27/7W
Backup Light......................921/W16W
Center High Mount Stop Light (CHMSL)....... LED
License.............................. W5W
BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.2. Twist the appropriate bulb and socket assembly
counter-clockwise and then pull it out of the headlight
assembly.
3. Pull the bulb out of the socket assembly.
4. Push the replacement bulb into the socket assembly.
5. Reinstall the bulb and socket assembly into the head-
light assembly, and then turn it clockwise.
1 — Low Beam Headlight Bulb
2 — High Beam Headlight BulbMAINTAINING YOUR VEHICLE 345
7
Hood............................... 95
Lead Free Gasoline...................... 261
LifeofTires ........................... 250
Liftgate ............................... 31
Liftgate Window Wiper/Washer............ 201
Lights .............................. 61,96
Airbag....................... 46,49,61,142
Anti-Lock........................147,228
Automatic Headlights................... 96
Brake Assist Warning.................. 235
Brake Warning....................144,226
Bulb Replacement..................... 344
Courtesy/Reading.................100,109
Cruise ............................. 140
Daytime Running...................... 98
Dimmer Switch, Headlight............... 99
Electronic Stability Program (ESP)
Indicator ..........................233,235
Electronic Throttle Control Warning....... 141
Engine Temperature Warning............ 142
Fog ............................. 98,144
Hazard Warning Flasher................ 284
Headlight Switch...................... 96Headlights........................... 96
Headlights On With Wipers........... 97,103
High Beam........................ 99,143
High Beam Indicator................... 143
IlluminatedEntry ...................... 17
Instrument Cluster.................. 96,140
Interior ..........................100,109
License............................. 349
Lights On Reminder.................... 98
Low Fuel........................... 147
LowTire ............................ 145
Malfunction Indicator (Check Engine)...... 147
Oil Pressure......................... 143
Passing............................. 99
Reading............................ 109
Seat Belt Reminder.................... 143
Service..........................344,345
Service Engine Soon (Malfunction Indicator) . 147
Tire Pressure Monitoring (TPMS).......145,254
Traction Control...................... 235
Turn Signal........................ 99,142
Voltage ............................. 140
Warning (Instrument Cluster Description) . . . 140
INDEX 389
10
