2007 DODGE CARAVAN Owners Manual

radio, power vent windows, power outlets, and remov-
able center console, when the ignition switch is turned off
or until the key is removed and either front door is
opened.
GARAGE DOOR OPENER — IF EQUIPPED
The HomeLink Universal Transceiver replaces up to
three remote controls (hand held transmitters) that oper-
ate devices such as garage door openers, motorized
gates, or home lighting. It triggers these devices at the
push of a button. The Universal Transceiver operates off
your vehicle’s battery and charging system; no batteries
are needed.
NOTE: The HomeLink Universal Transceiver is dis-
abled when the Vehicle Theft Alarm is active.
For additional information on HomeLink , call 1–800–
355–3515, or on the internet at www.homelink.com.
WARNING!
A moving garage door can cause injury to people and
pets in the path of the door. People or pets could be
seriously or fatally injured. Only use this transceiver
with a garage door opener that has a “stop and
reverse” feature as required by federal safety stan-
dards. This includes most garage door opener mod-
els manufactured after 1982. Do not use a garage
door opener without these safety features it could
cause injury or death. Call toll-free 1–800–355–3515
or, on the Internet at www.homelink.com for safety
information or assistance.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

WARNING!
Vehicle exhaust contains carbon monoxide, a danger-
ous gas. Do not run the vehicle’s exhaust while
training the transceiver. Exhaust gas can cause seri-
ous injury or death.
WARNING!
Your motorized door or gate will open and close
while you are training the Universal Transceiver. Do
not train the transceiver if people or pets are in the
path of the door or gate. A moving door or gate can
cause serious injury or death to people and pets or
damage to objects.
Programming HomeLink
NOTE: When programming a garage door opener, it is
advised to park outside the garage. Some vehicles may
require the ignition switch to be turned to the second
(Accessory) position for programming and/or operation
of HomeLink. It is also recommended that a new battery
be placed in the hand-held transmitter of the device
being programmed to HomeLink for more efficient train-
ing and accurate transmission of the radio-frequency
signal.
1. Press and hold the two outer HomeLink buttons, and
release only when the indicator light begins to flash or
the EVIC display shows “Channels Cleared” (after 20
seconds). Do nothold the buttons for longer than 30
seconds and do notrepeat Step One to program a second
and/or third hand-held transmitter to the remaining two
HomeLink buttons.
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Position the end of your hand-held transmitter 1-3
inches (3-8 cm) away from the HomeLink buttons while
keeping the indicator light in view. 3. Simultaneously press and hold both the HomeLink
button that you want to train and the hand-held trans-
mitter buttons.
Do not release the buttons until Step
Four has been completed.
NOTE: Some gate operators and garage door openers
may require you to replace this Programming Step 3 with
procedures noted in the Gate Operator/Canadian Pro-
gramming section.
4. The HomeLink indicator light will flash slowly and
then rapidly after HomeLink successfully receives the
frequency signal from the hand-held transmitter. Release
both buttons after the indicator light changes from the
slow to the rapid flash.
5. Press and hold the just trained HomeLink button and
observe the indicator light or the EVIC display. If the
indicator light stays on constantly, programming is
complete and your device should activate when the
HomeLink button is pressed and released.
HomeLink Buttons
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

NOTE:To program the remaining two HomeLink but-
tons, begin with ProgrammingStep Two. Do not repeat
Step One.
NOTE: If your hand-held transmitter appears to pro-
gram the universal transceiver, but your garage door
does not operate using the transmitter and your garage
door opener was manufactured after 1995, your garage
door opener may have a multiple security code system
(rolling code system). If your garage door is the “rolling
code” type, please proceed to the heading “Program-
ming A Rolling Code System.”
Programming A Rolling Code System
1. At the garage door opener receiver (motor-head unit)
in the garage, locate the learnorsmart button. This
can usually be found where the hanging antenna wire is
attached to the motor-head unit. 2. Firmly press and release the
learnorsmart button.
(The name and color of the button may vary by manu-
facturer.)
NOTE: There are 30 seconds in which to initiate Step
Three.
3. Return to the vehicle and firmly press, hold for two
seconds and release the programmed HomeLink button.
Repeat the press/hold/release sequence a second time,
and, depending on the brand of the garage door opener
(or other rolling code equipped device), repeat this
sequence a third time to complete the programming.
HomeLink should now activate your rolling code
equipped device.
NOTE: To program the remaining two HomeLink but-
tons, begin with ProgrammingStep Two. Do not repeat
Step One . For questions or comments, please contact
HomeLink at www.homelink.com or 1-800-355-3515 .
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Canadian Programming/Gate Programming
Canadian radio-frequency laws require transmitter sig-
nals to time-out (or quit) after several seconds of
transmission which may not be long enough for
HomeLink to pick up the signal during programming.
Similar to this Canadian law, some U.S. gate operators are
designed to time-outin the same manner.
If you live in Canada or you are having difficulties
programming a gate operator by using the Program-
ming  procedures (regardless of where you live), replace
 Programming HomeLink Step Three with the follow-
ing:
NOTE: If programming a garage door opener or gate
operator, it is advised to unplug the device during the
 cycling process to prevent possible overheating.
3. Continue to press and hold the HomeLink button
while you press and release every two seconds cycle
your hand-held transmitter until the frequency signal has successfully been accepted by HomeLink. (The indicator
light will flash slowly and then rapidly.) Proceed with
 Programming
Step Four to complete.
Using HomeLink
To operate, simply press and release the programmed
HomeLink button. Activation will now occur for the
trained device (i.e. garage door opener, gate operator,
security system, entry door lock, home/office lighting,
etc.). For convenience, the hand-held transmitter of the
device may also be used at any time. In the event that
there are still programming difficulties or questions,
contact HomeLink at: www.homelink.com or 1-800-355-
3515 .
Erasing HomeLink Buttons
To erase programming from the three buttons (individual
buttons cannot be erased but can be reprogrammed-
note below), follow the step noted:
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181
3

•Press and hold the two outer HomeLink buttons until
the indicator light begins to flash-after 20 seconds.
Release both buttons. Do not hold for longer that 30
seconds. HomeLink is now in the train (or learning)
mode and can be programmed at any time beginning
with Programming - Step Two.
Reprogramming a Single HomeLink Button
To program a device to HomeLink using a HomeLink
button previously trained, follow these steps:
1. Press and hold the desired HomeLink button. Do
NOT release the button.
2. The indicator light will begin to flash after 20 seconds.
Without releasing the HomeLink button, proceed with
 Programming Step Two.
For questions or comments, contact HomeLink at:
www.homelink.com or 1-800-355-3515 .
Security
If you sell your vehicle, be sure to erase the frequencies
by following the “Erasing HomeLink Buttons” instruc-
tions in this section.
This device complies with part 15 of FCC rules and with
RSS-210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference that may be
received including interference that may cause undes-
ired operation.
NOTE: Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLink is a trademark owned by Johnson Controls,
Inc.
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

In the event that you are still having programming
difficulties, questions, or comments, contact HomeLink
at: www.homelink.com or 1-800-355-3515 .
POWER SUNROOF — IF EQUIPPED
The power sunroof control is located between the sun
visors on the overhead console. Press and hold the switch rearward to fully open the
sunroof. The sunroof can be stopped at any position
between closed and full open. Momentarily pressing the
switch rearward will activate the Express Open Feature,
causing the sunroof to open automatically.
Press and hold the button located to the right of the
sunroof switch, to open the vent. The sunroof can be
stopped at any position between closed and full vent. To
close the sunroof from the vent position, press and hold
the switch forward. Releasing the switch will stop the
movement of the sunroof and the sunroof will remain in
the partial vent position until the switch is pushed
forward again.
Express Open Feature
During the Express Open operation, any movement of
the switch will stop the sunroof and it will remain in a
partial open position. Again, momentarily pressing the
switch rearward will activate the Express Open Feature.
Power Sunroof Controls
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183
3

To close the sunroof, hold the switch in the forward
position. Again, any release of the switch will stop the
movement and the sunroof will remain in a partial open
condition until the switch is pushed forward again.
The sunshade can be opened manually. It will also open
as the sunroof opens. The sunshade cannot be closed if
the sunroof is open.
WARNING!
NEVER leave children alone in a vehicle. Occupants,
particularly unattended children, can become en-
trapped by the power sunroof while operating the
power sunroof switch. Such entrapment may result
in serious injury or death. Don’t leave the keys in the
ignition. A child could operate power windows,
other controls, or move the vehicle
WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could also
be seriously injured or killed. Always fasten your
seat belt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sunroof.
Never allow fingers or other body parts, or any
object to project through the sunroof opening. Injury
may result.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
