2007 CITROEN C4 Owners Manual

32
II
M U L T I F U N C T I O N S C R E E N S Displaying the log of alerts

 Press on A .

 Use B to select the submenu for
options. Confi rm with two presses
on C .
You can cancel the start of the dis-
play by pressing button E to aban-
don and confi rming by pressing C .
Alerts signalled previously but not
resolved, will scroll in the display for
recall.
To clear the displaying of an alert,
press D .
Adjusting the date and time

 Press on A .

 Use B to select the submenu for
display adjustments, then con-
fi rm by pressing C .

 Press B to select what you want
to modify : year, month, day, hour,
minutes, mode of display.

 Make your adjustment by pres-
sing F . You can continue your
adjustments by selecting a dif-
ferent element by presses on B .
When you have fi nished your ad-
justments, press C .
Configuring the vehicle
functions

 Press on A .

 Use B to select the sub-menu for
personalisation confi guration of
your vehicle, then confi rm your
choice with a press on C .

 Select the function to be confi gured
by pressing B .

 The system tells you whether
the function status is active or
inactive. Modify this status with
a press on F .

 Confi rm with a press on C . Choosing the language

 Press on A .

 Use B to select the submenu for
languages. Confi rm your choice
with a press on C .

 With presses on F , select the
language of your choice, then
confi rm with a press on C .
Choosing the units

 Press on A .

 Press B to select the sub-menu
for Units. Confi rm your choice
with a press on C .

 Press B to select the type of unit
you wish to modify (Temperature
or Fuel Consumption).

 With presses on F , select the
unit of your choice, then confi rm
with a press on C .
This choice concerns all the informa-
tion (Consumption - Speed) appear-
ing on the display screens.

33
II
M U L T I F U N C T I O N S C R E E N S
MULTIFUNCTION SCREEN C Main Menu
Presentation
Radio-CD
(see "Audio and
Telematics")
Trip computer
This permits:
Bluetooth
®
hands-free
system
(see "Audio and
Telematics")
Controls

1. Time

2. Ambient temperature

3. Date and display zone
When the ambient temperature is
between +3 °C and -3 °C, the tem-
perature display fl ashes (ice risk).
The ambient temperature displayed
may be greater than the actual tem-
perature, if the vehicle is parked in
bright sunlight.
It is recommended that the driver
should not operate the controls
while the vehicle is in motion.
A. Access to the "Main Menu"

B. Scrolling in the screen menus

C. Selection and confi rmation in the
menus of the function chosen or
the value modifi ed

D. Cancellation of the operation or
return to the previous display

E. Selection of the type of informa-
tion to be displayed permanently
(date, radio-CD, trip computer)
on the right of the screen (See
"Trip computer") Press button
A to view the "Main
Menu" of the multifunction screen.
This menu gives you access to the
following functions:
- entering the distance to your destination,
- access to the log of alerts (recall of alerts signalled previously),
- access to the status of functions, such as the activation/deactivation
of the automatic headlamps, of the
automatic windscreen wipers, of
the ESP...

34
II
M U L T I F U N C T I O N S C R E E N S
Personalisation-
Configuration
This permits activation/deactivation
of the:
- automatic operation of the rear wiper when reverse gear is en-
gaged,
- automatic guide-me-home lighting,
- Xenon dual-function directional headlamps,
and selection of the:
- brightness intensity, time, date and units,
- screen language. Activating/deactivating the
rear screen wipe when you
engage reverse gear

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .

 Then select the sub-menu for ve-
hicle parameters. Confi rm your
choice with a press on C .

 Using B , select "parking assis-
tance". Confi rm your choice with
a press on C .

 Then by pressing C , select/ dese-
lect "triggering of rear screen wipe
in reverse gear" to activate/deacti-
vate this.

 Confi rm with "OK" on the screen.
Activating/deactivating the
automatic guide-me-home
lighting

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .

 Then select the sub-menu for ve-
hicle parameters. Confi rm your
choice with a press on C .
 Using B , select "lighting and
signalling". Confi rm your choice
with a press on C .

 Then by pressing C , select/dese-
lect "guide-me-home lighting" to
activate/deactivate this. After acti-
vation, choose its duration: press
on C , then use B to select the du-
ration and then press on C .

 Confi rm with "OK" on the screen.
Activating/deactivating
the Xenon dual-function
directional headlamps

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .

 Then select the sub-menu for ve-
hicle parameters. Confi rm your
choice with a press on C .

 Using B , select "driving assis-
tance". Confi rm your choice with
a press on C .

 Then by pressing C , select/dese-
lect "directional headlamps" to
activate/deactivate them.

 Confi rm with "OK" on the screen.

35
II
M U L T I F U N C T I O N S C R E E N S
Adjusting the date and time

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .


Select the display confi guration
using B . Confi rm with a press on C .

 Select the adjustment for the
date and time, using B . Confi rm
with a press on C . Choosing the units

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .

 Select the display confi guration
using B . Confi rm with a press on C .

 Then select the sub-menu for
units. Confi rm your choice with
a press on C .

 Using B , select the unit you
wish to modify (Temperature or
Consumption), then confi rm by
pressing C .

 Confi rm with "OK" on the screen.
This choice concerns all the informa-
tion (Consumption - Speed) appearing
on the screens. Choosing the language

 Press on A .

 Use B to select "Personalisation-
Confi guration", then confi rm your
choice with a press on C .

 Make your choice of language
using B . Confi rm with a press on C .

 Using B , select the language and
confi rm your choice with a press
on C .

 Confi rm with "OK" on the screen.

 Press B to select the values you
wish to modify. Confi rm your
choice with a press on C .

 Make your adjustments by pres-
sing B , confi rming each adjust-
ment choice by pressing C .

 Validate with "OK" on the screen.

36
II
M U L T I F U N C T I O N S C R E E N S
NAVIDRIVE MULTIFUNCTION COLOUR SCREEN
Presentation

1. Ambient temperature

2. Directory

3. Date

4. Telephone

5. Time
When the ambient temperature is be-
tween +3 °C and -3 °C, the tempera-
ture display fl ashes (risk of ice).
The ambient temperature displayed
may be greater than the actual tem-
perature, if the vehicle is parked in
bright sunlight.
It is recommended that the driver
should not operate the controls
while the vehicle is in motion. Controls Main Menu

Traffi c Information

Navigation/Guidance

Map

Audio Functions

Telematics

Confi guration,
for adjusting various parameters
(date, time, units)

Video

Vehicle Diagnostics

A. Access to the "Main Menu"

B. Scrolling in the screen menus

C. Selection and confi rmation in the
menus of the function chosen or
the value modifi ed

D. Cancellation of the operation or
return to the previous display

E. Selection of the type of informa-
tion to be displayed permanently
(date, radio-CD, trip computer)
on the right of the screen Press on the button
A to view the
"Main Menu" of the multifunction
screen.
This menu gives you access to the
following functions (see "NaviDrive
Instructions"):

37
II
M U L T I F U N C T I O N S C R E E N S
TRIP COMPUTER
System which provides current
information concerning the route
travelled (range, consumption...).
Monochrome screen A Data displays

 Press the control for more than
two seconds to reset to zero the
distance travelled, the average
consumption and the average
speed.
Zero reset
The trip computer provides the following
information:
- range,
- current consumption,
- distance travelled,
- average consumption,
- average speed.

 The next press then returns you
to the normal display.

 Press the button, located at the
end of the wiper
stalk , to display
the various items of trip computer
data in succession.

38
II
M U L T I F U N C T I O N S C R E E N S
TRIP COMPUTER
System which provides current infor-
mation concerning the route travelled
(range, consumption, …).
Monochrome screen C
NaviDrive colour screen Display of information
Trip zero reset

 Press the button, located at the
end of the wiper stalk , to display
the various trip computer infor-
mation groups in succession:
- the current information group with:

39
II
M U L T I F U N C T I O N S C R E E N S
"Trip computer" menu
System which provides general infor-
mation concerning the status of certain
equipment with which your vehicle is
equipped, such as the alert log, the
status of the functions...
Alert log
This summarises the active warning
messages, displaying them in suc-
cession on the multifunction screen.
Status of functions
This summarises the active or inac-
tive status of systems present on the
vehicle.
Enter distance to destination
This enables you to enter an ap-
proximate value for the distance to
the fi nal destination. Monochrome screen C
"Vehicle Diagnostics" menu

 Press the "MENU" button to gain
access to the general menu.

 Turn the dial and press it to select
the "Vehicle Diagnostics" menu.

 On the "Vehicle Diagnostics"
menu, select one of the following
applications:
- "Alert log",
- "Status of functions".

 Press the "MENU" button to gain
access to the general menu.

 Press the arrows, then the "OK"
button to select the "Trip com-
puter" menu.

 On the "Trip computer" menu,
select one of the following appli-
cations:
- "Alert log",
- "Status of functions",
- "Enter distance to destination". NaviDrive colour screen
