2007 Citroen C1 DAG Owner's Manual

II
27
With the ignition on, the
lighting of this warning
lamp indicates a gearbox
malfunction.
Contact a CITROËN dealer.
EASY mode (automatic mode)
Select position
E using the gear lever.
The gear engaged is displayed on the instrument panel screen.
The gearbox continuously selects the most suitable gear.
If you press the accelerator pedal beyond the point of resistan ce,
the SensoDrive gearbox selects the gear below to permit sharper
acceleration.
Manuel mode
Place the gear lever in position M, then change up or down through the
gears by pressing:
- rearwards, "+" to change up,
- forwards, "-" to change down.
The gear engaged is displayed on the instrument panel screen.
In the event of under-revving, to prevent any risk of stalling, the gear below
is selected automatically.
In the event of overheating of the clutch, position N is selected automatically
and the symbol N flashes accompanied by an audible signal.
Stopping the vehicle
Before switching off the engine, you can change to position N to be in
neutral.
In all cases, it is essential that you apply the handbrake to immobilise the
vehicle.
It is compulsory to press the brake pedal while starting the engine.
Never select neutral N while the vehicle is moving.
In all cases, it is essential to apply the handbrake to immobilise the vehicle.
Operating fault
On a slope, use the brake to immobilise the vehicle and place the gear lever in position N, E or R.
Do not keep the vehicle immobilised using the accelera tor.
S E N S O D R I V E G E A R B O X

II
28 When the vehicle is being driven, illumination of this warn
ing lamp
indicates that the handbrake is still on or has not been pro perly
released.
HANDBRAKE
Applying
Pull the handbrake to immobilise your vehicle.
Releasing
Pull on the handle and press the button to release the ha ndbrake.
THE ANTI-LOCK BRAKING SYSTEM (ABS) AND THE BRAKING SYSTEM
The ABS system, associated with the braking system, increases the stabil ity and manoeuvrability of your vehicle
during braking, especially on uneven or slippery road surfaces.
The ABS function intervenes automatically if there is a risk of th e wheels locking.
The normal operation of the ABS system may show itself through slig ht vibrations of the brake pedal.
Note: if you should change any of the wheels on your vehicle (tyres a nd wheel rims), make sure that the replacements
are approved.
The lighting of this warning lamp indicates a malfunctioni ng of the ABS system which could cause a loss of
control of the vehicle on braking.
Consult a CITROËN dealer.
The simultaneous lighting of these warning lamps indicates a malfunctioning of the braking system
which could cause a loss of control of the vehicle on braking.
It is essential to stop the vehicle.
Consult a CITROËN dealer.
If you should need to brake in an emergency, press the brake pedal very hard without relaxing the effort.
When parking on a slope, direct your wheels towards th
e pavement and pull the handbrake.
H A N D B R A K E - A B S S Y S T E M

II
29
E L E C T R O N I C S T A B I L I T Y P R O G R A M M E
ESP (Electronic Stability Programme) and ASR (Traction control)
These systems are associated with and complementary to the ABS. If
there is a discrepancy between the trajectory being taken by the vehicle
and that desired by the driver, the ESP system acts automatically on the
brake of one or more of the vehicle’s wheels as well as on the engine, in
order to bring the vehicle back onto the desired trajectory.
The ASR system optimises traction, so as to prevent the wheels from
skidding, by acting on the brakes of the driving wheels as wel l as on the
engine. It also improves the vehicle’s steering stability under acceleration.
System operational
These warning lamps light up for a few seconds when the
ignition is switched on, to signal that the ESP/ASR system
is operational.
The system will remain operational until the ignition is swi tched off again.
Functioning
When the ASR system is active, this warning lamp flashes.
When the ESP system is active, this warning lamp flashes
accompanied by a sound signal.
Functioning anomaly
If the system starts to malfunction, this warning lamp comes on.
Contact a CITROËN dealer to have the system checked. Safety advice
The ESP system offers you
increased safety in normal driving,
but it is not there to encourage the
driver to take extra risks or to drive
at excessive speeds.
The correct functioning of
this system is dependent on
compliance with the manufacturer’s
recommendations in terms of
wheels (both rims and tyres),
braking components, electronic
components, and CITROËN fitting
and repairing procedures.
After any collision, have this system checked out by a CITROËN dealer.

III
30
THE DOORS
Locking/unlocking a door from inside the vehicle
To lock a door, press on button A.
To unlock, pull on button A.
Remarks: it is possible to lock the vehicle’s doors from the inside but an
action on the handle will not unlock the door.
Never leave your vehicle without taking your key or remote control w ith
you.
Driver’s door left open alert
If the driver’s door should be left open, the interior lamp remains on (provided it has not been deactivated).
If you decide to drive with the doors locked,
remember that this will make access by the emergency services more difficult in the event of an emergency.
Central locking/unlocking from the driver’s side
To lock/unlock the vehicle, press/pull button
A on the driver’s door.
A C C E S S

III
31
THE BOOT
Locking/unlocking with the key
To open the boot, action the lock B
by means of the key and lift the
boot lid. Locking/unlocking with the
remote control
The boot can be locked/unlocked
by means of the remote control
.
To open it, press on button C and
lift the boot lid.
Note: the boot can be locked/
unlocked using control A on the
driver’s door.
COURTESY LAMP
In this position, it comes
on when you open the
driver’s door.
The courtesy lamp is de-
activated and is perma-
nently off.
Permanently on.
A C C E S S

III
32
VENTILATION
3. Lateral air vents.
4. Central air vent.
5. Air outlets to passenger footwells.
1.
Vent for deicing or demisting of the windscreen.
2. Vent for deicing or demisting of the door
windows.
V E N T I L A T I O N - H E A T I N G
A I R C O N D I T I O N I N G

III
33
AIR CONDITIONING
A. Air conditioning On/Off
With the engine running, press
the button, the warning lamp lights
up.
If the control C is in position
"0", the air conditioning is off.
The cabin temperature cannot be
lower than the ambient temperature
unless the air conditioning is
operating.
For reassurance that your system
is functioning correctly, you are
recommended to have it checked
on a regular basis.
Water arising from condensation
in the air conditioning system
drains away through an aperture
provided for this purpose. A pool of
water may thus form underneath
the vehicle when stationary.
If after a prolonged stop in strong
sunshine the cabin temperature is
excessive, open the windows to
air the passenger compartment
for a few minutes, the close them
again.
The air conditioning uses power
from the engine to operate. There
is therefore a slight increase in
fuel consumption.
To keep the compressor well
sealed, it is essential to operate
the air conditioning at least once
in every month.
Whatever the time of year, the air
conditioning is useful in removing
humidity and misting.
To be effective, the air conditioning
should only be used with the
windows closed.
V E N T I L A T I O N - H E A T I N G
A I R C O N D I T I O N I N G

III
34 B.
Adjustment of temperature
Rotate the control from blue (cold) to red (hot) to adjust
the temperature to your preference.
C. Adjustment of air flow
When you switch on the ignition, rotate the control to
obtain a flow of air that is comfortable.
Air inlet
Make sure that the exterior air inlet grille and manifold
at the base of the windscreen is clean and free of dead
leaves, snow, etc..
If you wash the vehicle with a high pressure jet, avoid
targeting the air inlet grille.
Air circulation
In order to obtain a perfectly even distribution of air,
you should take care not to obstruct the exterior air
inlet grille, the air vents, the air ducts, or the air outle
ts
to the passenger footwells.
The air vents to the face have grilles for orienting the
flow of air.
Pollen filter
Your installation has a filter for excluding dust.
This filter has to be changed at the prescribed
maintenance intervals (see the Maintenance Guide). D.
Recirculation of air / Outside air
Recirculation of air inside the cabin is useful
for isolating the passenger compartment from
odours or fumes coming from outside.
A combined use of both the air conditioning
and air recirculation for only a short time will optimise
the performance of the air conditioning.
Used in a climate with high humidity, recirculation of
air carries the risk of the windows misting.
As soon as possible, move the manual control D to the
right, to be in the "Exterior air" position, so as to avoid
any risk of poor air quality.
Entry of air from the outside helps to prevent
and eliminate misting of the windscreen and side
windows.
V E N T I L A T I O N - H E A T I N G
A I R C O N D I T I O N I N G
