Instrument Panel Cluster
Your instrument panel cluster and Driver Information Center (DIC) are designed to let you know at a glance
how the vehicle is running. You will know how fast you are going, about how much fuel you have left and
many other things you will need to know to drive safely and economically. The instrument panel cluster
indicator warning lights, gages and DIC messages are explained on the following pages.
United States Manual Transmission shown, Canada, Automatic Transmission and Z06 Model similar
189

Speedometer and Odometer
Your speedometer lets you see your speed in
either miles per hour (mph) or kilometers per
hour (km/h). For more information see “Personal
Options” underDIC Vehicle Personalization
on page 234.
To read the odometer with the ignition off, turn
on the parking lamps.
You may wonder what happens if your vehicle
needs a new odometer installed. The mileage
total of the new odometer will be set to the original
miles (kilometers) of the old odometer. See your
dealer if the odometer must be replaced in
your vehicle.
Tachometer
The tachometer displays the engine speed in
thousands of revolutions per minute (rpm).
Notice:Fuel will shut off at about 6600 rpm
for the base model and 7100 rpm for the
Z06 model. If you continue to drive your vehicle
at the fuel shut off rpm, you could damage
your engine. Be sure to operate your vehicle
below the fuel shut off rpm or reduce your
rpm quickly when the fuel shuts off.
Safety Belt Reminder Light
When the ignition is turned on, a chime will come
on for several seconds to remind people to
fasten their safety belts, unless the driver’s safety
belt is already buckled.
The safety belt light will
also come on and stay
on for several seconds,
then it will ash for
several more.
This chime and light will be repeated if the driver
remains unbuckled and the vehicle is in motion.
If the driver’s belt is already buckled, neither
the chime nor the light will come on.
190

Emissions Inspection and
Maintenance Programs
Some state/provincial and local governments have
or may begin programs to inspect the emission
control equipment on your vehicle. Failure to pass
this inspection could prevent you from getting a
vehicle registration.
Here are some things you need to know to help
your vehicle pass an inspection:
Your vehicle will not pass this inspection if the
check engine light is on or not working properly.
To perform a check engine light bulb check with the
keyless ignition, make sure the transmitter fob is in
the passenger compartment. SeeIgnition Positions
on page 90. Press the bottom of the Acc. button on
the instrument panel and hold the button down for
ve seconds. The instrument panel, including the
check engine light, will light up and the ignition will
be on, but the engine will not start — if you pressthe bottom of the Acc. button only briey, less than
ve seconds, the accessory power mode will be
turned on, but not the ignition. After the bulb check,
be sure to press and release the Acc. button again
to turn the ignition off and avoid draining the
vehicle’s battery.
Your vehicle will not pass this inspection if the
OBD (on-board diagnostic) system determines that
critical emission control systems have not been
completely diagnosed by the system. The vehicle
would be considered not ready for inspection.
This can happen if you have recently replaced
the battery or if the battery has run down.
The diagnostic system is designed to evaluate
critical emission control systems during normal
driving. This may take several days of routine
driving. If you have done this and your vehicle
still does not pass the inspection for lack of
OBD system readiness, your dealer can prepare
the vehicle for inspection.
203

If a problem is detected, a warning message will
appear on the DIC display. Be sure to take any
message that appears on the display seriously and
remember that clearing the message will only make
the message disappear, not correct the problem.
If your vehicle has the Head-Up Display (HUD) and
you use the Manual Paddle Shift feature, the gear
will display in the HUD, except if your vehicle has
the Navigation system and the HUD is displaying
turn-by-turn guidance information. If the HUD is
displaying turn-by-turn guidance information, the
gear instead displays in the DIC. See “Manual
Paddle Shift” underAutomatic Transmission
Operation on page 95and “Head-Up Display
(HUD)” in the index of the Navigation system
manual for more information.DIC Controls and Displays
The Driver Information Center (DIC) has different
modes which can be accessed by pressing
the following buttons located on the instrument
panel, to the right of the instrument panel cluster.
.4(Fuel):Press this button to display fuel
information such as fuel economy and range.
208

2(Gages):Press this button to display gage
information like oil pressure and temperature,
coolant temperature, automatic transmission uid
temperature, if equipped, battery voltage, and
front/rear tire pressures.
TRIP:Press this button to display your total and
trip distance driven, the elapsed time function,
your average speed, and the engine oil life.
OPTION:Press this button to choose personal
options that are available on your vehicle,
depending on the options your vehicle is equipped
with, such as door locks, easy entry seats, and
language.
RESET:Press this button, used along with the
other buttons, to reset system functions, select
personal options, and turn off or acknowledge
messages on the DIC.
FUEL Button
The fuel button displays average fuel economy
and instantaneous fuel economy, calculated
for your specic driving conditions, and range
information.Average Fuel Economy:The average fuel
economy is viewed as a long-term approximation
of your overall driving conditions. You should
reset the average fuel economy display every time
you refuel. If you press the RESET button in
this mode while you are driving, the system will
reset this display and begin guring fuel economy
from that point in time.
Press the fuel button to display average fuel
economy, such as:
AVERAGE FUEL ECONOMY 20.1 MPG or
AVERAGE FUEL ECONOMY 11.7 L/100 km
Instantaneous Fuel Economy:Instantaneous
fuel economy reects only the fuel economy
that the vehicle has right now and will change
frequently as driving conditions change. Unlike
average fuel economy, this menu item cannot
be reset.
Press the fuel button again to display
instantaneous fuel economy, such as:
INSTANT FUEL ECONOMY 20.1 MPG or
INSTANT FUEL ECONOMY 11.7 L/100 km
209

SHIFT TO PARK
If your vehicle has an automatic transmission,
this message displays if the vehicle is not in
PARK (P) when the engine is being turned off.
The vehicle will be in Acc. Once the shift lever is
moved to PARK (P), the vehicle will turn off.
The vehicle will remain in Acc., without the
20 minute time-out period, until the shift lever is
moved to PARK (P) or until the driver presses the
pushbutton to restart the vehicle. SeeIgnition
Positions on page 90for more information.
SHIFT TO PARK OR SET PARK BRAKE
FOR TOP
If your vehicle has an automatic transmission, this
message displays and a chime sounds if you
try to operate the power convertible top without
rst shifting into PARK (P) or setting the parking
brake. Either shift the vehicle into PARK (P) or
set the parking brake before trying to operate the
power convertible top. SeeConvertible Top
(Manual) on page 139orConvertible Top (Power)
on page 146for more information.
SHOCKS INOPERATIVE
This message displays when a malfunction is
present in the Selective Ride Control system which
is causing the shocks to be in their full soft
mode. This is a warning to the driver that the
vehicle handling may be affected. Have your
vehicle serviced by your dealer as soon as
possible.
To acknowledge the message, press the RESET
button. The message reappears every 10 minutes
until this condition changes.
228

If this message is displayed during normal vehicle
operation on at roads, your vehicle may need
service. See your dealer for an inspection.
If driving in a performance or competitive manner,
the use of (S) Sport Automatic Mode or (S) Sport
Manual Paddle Shift gear selection is
recommended. SeeAutomatic Transmission
Operation on page 95for more information.
To acknowledge the message, press the RESET
button. The message reappears every 10 minutes
until this condition changes. If you do not press
the RESET button, the message remains on
the display until the condition changes.
TURN SIGNAL ON
This message displays and a chime sounds
if a turn signal is left on for three-quarters of
a mile (1.2 km). Move the turn signal/multifunction
lever to the off position.
To acknowledge this message, press the RESET
button.
UNLATCH HEADER TO MOVE TOP
This message displays and a chime sounds if you
try to lower the convertible top without rst unlocking
the top. Move the latch handle to unlock the
convertible top. SeeConvertible Top (Manual) on
page 139orConvertible Top (Power) on page 146.
Other Messages
Here are more messages that you can receive
on your Driver Information Center (DIC). To
acknowledge a message and read another
message that may have come on at the same
time, press the RESET button.
ACCESSORY MODE ON
BATTERY VOLTAGE HIGH
SeeVoltmeter Gage on page 194.
BATTERY VOLTAGE LOW
SeeVoltmeter Gage on page 194.
CHECK WASHER FLUID
SeeWindshield Washer Fluid on page 360.
CRUISE SET TO XXX MPH (XXX km/h)
SeeCruise Control on page 164.
232

Entering the Personal Options Menu
To enter the personal options menu, use the
following steps:
1. If you have an automatic transmission vehicle,
turn the vehicle on with the shift lever in
PARK (P).
If you have a manual transmission vehicle,
turn the vehicle on with the parking brake set.
To avoid excessive drain on the battery, it
is recommended that the headlamps are
turned off.
2. Press the OPTION button and you will enter
the PERSONAL OPTIONS menu.
The DIC will display the current driver
number (1 or 2) for a few seconds and then
will display instructions on which buttons
to use for setting the personalizations. The
RESET button is used to select a setting for a
particular feature. The OPTION button is
used to move to the next feature.
3. Press the OPTION button while the instruction
screen is displayed to enter the rst
personalization menu item.4. Once you have cycled through all of the
personal options, pressing the OPTION
button a nal time exits the personal options
menu. In addition, if no button is pressed
within 45 seconds, the DIC will exit the
personal options menu.
Personal Options
The following options are available for
programming:
Display Units:This option allows you to choose
the measurement units.
Press the OPTION button until DISPLAY UNITS
appears on the display, then press the RESET
button to scroll through the following modes:
ENGLISH (default)
METRIC
If you choose ENGLISH, all information will be
displayed in English units.
If you choose METRIC, all information will be
displayed in metric units.
When the mode you want is selected, press the
OPTION button to set your choice and advance to
the next personal option.
235
