2007 BUICK TERRAZA engine

Checking Things Under
the Hood
{CAUTION:
An electric fan under the hood can start up
and injure you even when the engine is not
running. Keep hands, clothing, and tools
away from any underhood electric fan.
{CAUTION:
Things that burn can get on hot engine
parts and start a re. These include
liquids like fuel, oil, coolant, brake uid,
windshield washer and other uids, and
plastic or rubber. You or others could be
burned. Be careful not to drop or spill
things that will burn onto a hot engine.
408

Hood Release
To open the hood, do the following:
1. Pull the hood
release handle with
this symbol on it.
It is located
under the instrument
panel on the
driver’s side.
2. Go to the front of the vehicle and push the
underhood release to the right. It is located
near the center of the hood, above the grille.
3. Lift the hood.4. Pull up on the hood prop to release it from its
storage clip.
The hood prop may be hot due to increased
engine temperatures under the hood, so
be careful when handling it. Use your hood
prop sleeve when handling the hood prop.
5. Put the end of the hood prop into the slot in
the underside of the hood, on the driver’s
side of the vehicle. It is marked by an arrow.
Before closing the hood, be sure all the ller caps
are on properly. Lift the hood to relieve pressure on
the hood prop. Remove the hood prop from the slot
in the hood and return the prop to its retainer. Then
let the hood down and close it rmly.
409

Engine Compartment Overview
When you open the hood on the 3.9L V6 engine, here is what you will see:
410

A. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 500.
B. Remote Positive (+) Terminal. SeeJump
Starting on page 438.
C. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 433.
D. Radiator Pressure Cap. SeeRadiator Pressure
Cap on page 423.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 432.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 411.
G. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 411.
H. Automatic Transaxle Fluid Dipstick. See
“Checking the Fluid Level” underAutomatic
Transaxle Fluid on page 417.
I. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 434.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 416.
K. Engine Coolant Recovery Tank. SeeCooling
System on page 426.Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time
you get fuel. In order to get an accurate reading,
the oil must be warm and the vehicle must be
on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 410
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil
several minutes to drain back into the oil pan.
If you do not do this, the oil dipstick might
not show the actual level.
2. Pull out the dipstick and clean it with a paper
towel or cloth, then push it back in all the
way. Remove it again, keeping the tip down,
and check the level.
411

When to Add Engine Oil
If the oil is below the cross-hatched area at the
tip of the dipstick, you will need to add at least
one quart/liter of oil. But you must use the
right kind. This section explains what kind of oil to
use. For engine oil crankcase capacity, see
Capacities and Specications on page 503.
Notice:Do not add too much oil. If the engine
has so much oil that the oil level gets above
the cross-hatched area that shows the
proper operating range, the engine could be
damaged.SeeEngine
Compartment Overview
on page 410for the
location of the engine oil
ll cap.
Be sure to add enough oil to put the level
somewhere in the proper operating range in the
cross-hatched area. Push the dipstick all the
way back in when you are through.
412

What Kind of Engine Oil to Use
Look for two things:
GM6094M
Your vehicle’s engine requires oil meeting GM
Standard GM6094M. You should look for
and use only an oil that meets GM Standard
GM6094M.
SAE 5W-30
As shown in the viscosity chart, SAE 5W-30 is
best for your vehicle.
These numbers on an oil container show its
viscosity, or thickness. Do not use other
viscosity oils such as SAE 20W-50.
Oils meeting these
requirements should
also have the starburst
symbol on the
container. This symbol
indicates that the oil
has been certied by the
American Petroleum
Institute (API).
You should look for this information on the oil
container, and use only those oils that are
identied as meeting GM Standard GM6094M and
have the starburst symbol on the front of the oil
container.
413

Notice:Use only engine oil identied as
meeting GM Standard GM6094M and showing
the American Petroleum Institute Certied
For Gasoline Engines starburst symbol. Failure
to use the recommended oil can result in
engine damage not covered by your warranty.
GM Goodwrench
®oil meets all the requirements
for your vehicle.
If you are in an area of extreme cold, where the
temperature falls below−20°F (−29°C), it is
recommended that you use either an SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will
provide easier cold starting and better protection
for the engine at extremely low temperatures.
Engine Oil Additives
Do not add anything to the oil. The recommended
oils with the starburst symbol meet GM Standard
GM6094M are all you will need for good
performance and engine protection.
Engine Oil Life System
When to Change Engine Oil
Your vehicle has a computer system that lets you
know when to change the engine oil and lter. This
is based on engine revolutions and engine
temperature, and not on mileage. Based on driving
conditions, the mileage at which an oil change will
be indicated can vary considerably. For the oil life
system to work properly, you must reset the system
every time the oil is changed.
When the system has calculated that oil life has
been diminished, it will indicate that an oil change is
necessary. A CHANGE OIL SOON message will
come on. SeeDIC Warnings and Messages on
page 230. Change your oil as soon as possible
within the next 600 miles (1 000 km). It is possible
that, if you are driving under the best conditions, the
oil life system may not indicate that an oil change is
necessary for over a year. However, your engine oil
and lter must be changed at least once a year and
at this time the system must be reset. Your dealer
has GM-trained people who will perform this work
using genuine GM parts and reset the system. It is
also important to check your oil regularly and keep
it at the proper level.
414

If the system is ever reset accidentally, you must
change your oil at 3,000 miles (5 000 km)
since your last oil change. Remember to reset the
oil life system whenever the oil is changed.
How to Reset the Engine Oil Life
System
The Engine Oil Life System calculates when to
change your engine oil and lter based on vehicle
use. Anytime your oil is changed, reset the
system so it can calculate when the next oil
change is required. If a situation occurs where you
change your oil prior to a CHANGE OIL SOON
message being turned on, reset the system.
1. With the ignition key in RUN but the engine
off, repeatedly push the set/reset button until
OIL is displayed on the Driver Information
Center (DIC).
2. Once OIL is displayed, push and hold the
set/reset button for ve seconds. The
number will disappear and be replaced by 100
(indicating 100% oil life remaining).
3. Turn the key to LOCK.If the CHANGE OIL SOON message comes back
on when you start your vehicle, the engine oil
life system has not reset. Repeat the procedure.
What to Do with Used Oil
Used engine oil contains certain elements that
may be unhealthy for your skin and could
even cause cancer. Do not let used oil stay on
your skin for very long. Clean your skin and nails
with soap and water, or a good hand cleaner.
Wash or properly dispose of clothing or rags
containing used engine oil. See the manufacturer’s
warnings about the use and disposal of oil
products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil
from the lter before disposal. Never dispose of oil
by putting it in the trash, pouring it on the
ground, into sewers, or into streams or bodies of
water. Instead, recycle it by taking it to a place
that collects used oil. If you have a problem
properly disposing of your used oil, ask your
dealer, a service station, or a local recycling center
for help.
