2007 BUICK RAINIER headlamp

Driving Uphill
Once you decide you can safely drive up the hill,
you need to take some special steps.
Use a low gear and get a rm grip on the
steering wheel.
Get a smooth start up the hill and try to
maintain your speed. Do not use more power
than you need, because you do not want
your wheels to start spinning or sliding.
Try to drive straight up the hill if at all possible.
If the path twists and turns, you might want to
nd another route.
{CAUTION:
Turning or driving across steep hills can
be dangerous. You could lose traction,
slide sideways, and possibly roll over.
You could be seriously injured or killed.
When driving up hills, always try to go
straight up.
Ease up on your speed as you approach the
top of the hill.
Attach a ag to the vehicle to make you more
visible to approaching traffic on trails or hills.
Sound the horn as you approach the top of the
hill to let opposing traffic know you are there.
Use your headlamps, even during the day.
They make you more visible to oncoming traffic.
{CAUTION:
Driving to the top (crest) of a hill at full
speed can cause an accident. There could
be a drop-off, embankment, cliff, or even
another vehicle. You could be seriously
injured or killed. As you near the top of a
hill, slow down and stay alert.
306

After Off-Road Driving
Remove any brush or debris that has collected
on the underbody, chassis, or under the hood.
These accumulations can be a re hazard.
After operation in mud or sand, have the brake
linings cleaned and checked. These substances
can cause glazing and uneven braking. Check the
body structure, steering, suspension, wheels,
tires, and exhaust system for damage. Also, check
the fuel lines and cooling system for any leakage.
Your vehicle will require more frequent service
due to off-road use. Refer to the Maintenance
Schedule for additional information.
Driving at Night
Night driving is more dangerous than day driving.
One reason is that some drivers are likely to
be impaired — by alcohol or drugs, with night
vision problems, or by fatigue.
Here are some tips on night driving.
Drive defensively.
Do not drink and drive.
Adjust the inside rearview mirror to reduce the
glare from headlamps behind you.
Since you cannot see as well, you may need
to slow down and keep more space between
you and other vehicles.
Slow down, especially on higher speed roads.
Your vehicle’s headlamps can light up only so
much road ahead.
In remote areas, watch for animals.
If you are tired, pull off the road in a safe
place and rest.
314

No one can see as well at night as in the daytime.
But as we get older these differences increase.
A 50-year-old driver may require at least twice as
much light to see the same thing at night as a
20-year-old.
What you do in the daytime can also affect your
night vision. For example, if you spend the
day in bright sunshine you are wise to wear
sunglasses. Your eyes will have less trouble
adjusting to night. But if you are driving, do not
wear sunglasses at night. They may cut down on
glare from headlamps, but they also make a
lot of things invisible.
You can be temporarily blinded by approaching
headlamps. It can take a second or two, or
even several seconds, for your eyes to re-adjust
to the dark. When you are faced with severe glare,
as from a driver who does not lower the high
beams, or a vehicle with misaimed headlamps,
slow down a little. Avoid staring directly into
the approaching headlamps.Keep the windshield and all the glass on your
vehicle clean — inside and out. Glare at night is
made much worse by dirt on the glass. Even the
inside of the glass can build up a lm caused
by dust. Dirty glass makes lights dazzle and ash
more than clean glass would, making the pupils
of your eyes contract repeatedly.
Remember that the headlamps light up far less of a
roadway when you are in a turn or curve. Keep your
eyes moving; that way, it is easier to pick out dimly
lighted objects. Just as the headlamps should be
checked regularly for proper aim, so should your
eyes be examined regularly. Some drivers suffer
from night blindness — the inability to see in dim
light — and are not even aware of it.
315

You will need a well-charged battery to restart the
vehicle, and possibly for signaling later on with
your headlamps. Let the heater run for a while.
Then, shut the engine off and close the window
almost all the way to preserve the heat. Start
the engine again and repeat this only when you
feel really uncomfortable from the cold. But do it as
little as possible. Preserve the fuel as long as
you can. To help keep warm, you can get out of
the vehicle and do some fairly vigorous exercises
every half hour or so until help comes.
If Your Vehicle is Stuck in Sand,
Mud, Ice, or Snow
In order to free your vehicle when it is stuck,
you will need to spin the wheels, but you do not
want to spin your wheels too fast. The method
known as rocking can help you get out when you
are stuck, but you must use caution.
{CAUTION:
If you let your vehicle’s tires spin at high
speed, they can explode, and you or others
could be injured. And, the transmission or
other parts of the vehicle can overheat.
That could cause an engine compartment
re or other damage. When you are stuck,
spin the wheels as little as possible. Do not
spin the wheels above 35 mph (55 km/h) as
shown on the speedometer.
Notice:Spinning the wheels can destroy parts
of your vehicle as well as the tires. If you
spin the wheels too fast while shifting
the transmission back and forth, you can
destroy the transmission.
For information about using tire chains on your
vehicle, seeTire Chains on page 433.
329

Trailer Wiring Harness
Your vehicle is equipped with a seven-wire trailer
towing harness. This harness has a seven-pin
universal heavy-duty trailer connector (if equipped
with the trailering package) that is attached to a
bracket on the hitch platform. If your vehicle is not
equipped with the heavy-duty trailer connector,
you may purchase one from your dealer.The seven-wire harness contains the following
trailer circuits:
Yellow: Left Stop/Turn Signal
Dark Green: Right Stop/Turn Signal
Brown: Running Lamps
White: Ground
Light Green: Back-up Lamps
Dark Blue: Electric Brakes
Red: Battery Feed (The chassis wiring ring
terminal must be fastened to a stud on the
underhood electrical center before the
trailer feed will become active.)
If you need to tow a light-duty trailer with a standard
four-way round pin connector, an adapter connector
is available from your dealer.
If you are charging a remote (non-vehicle) battery,
turn on the headlamps to boost the vehicle
system voltage and properly charge the battery.
Your vehicle is also equipped with wiring for an
electric trailer brake controller. These wires are
located inside the vehicle on the driver’s side under
the instrument panel. These wires should be
connected to an electric trailer brake controller by
your dealer or a qualied service center.
352

Service........................................................ 356
Accessories and Modications................... 356
California Proposition 65 Warning.............. 357
Doing Your Own Service Work.................. 357
Adding Equipment to the Outside
of Your Vehicle...................................... 358
Fuel............................................................. 358
Gasoline Octane........................................ 358
Gasoline Specications.............................. 358
California Fuel........................................... 359
Additives................................................... 359
Fuels in Foreign Countries........................ 360
Filling the Tank......................................... 361
Filling a Portable Fuel Container............... 363
Checking Things Under the Hood.............. 364
Hood Release........................................... 364
Engine Compartment Overview.................. 366
Engine Oil................................................. 369
Engine Oil Life System.............................. 372
Engine Air Cleaner/Filter............................ 374
Automatic Transmission Fluid.................... 375
Engine Coolant.......................................... 379Radiator Pressure Cap.............................. 382
Engine Overheating................................... 382
Cooling System......................................... 384
Engine Fan Noise..................................... 390
Power Steering Fluid ................................. 390
Windshield Washer Fluid........................... 391
Brakes...................................................... 392
Battery...................................................... 396
Jump Starting............................................ 397
All-Wheel Drive........................................... 402
Rear Axle.................................................... 402
Front Axle................................................... 403
Bulb Replacement....................................... 404
Halogen Bulbs........................................... 404
Headlamps, Front Turn Signal, and
Parking Lamps....................................... 405
Taillamps and Turn Signal Lamps............. 405
License Plate Lamp................................... 407
Replacement Bulbs................................... 407
Windshield Replacement............................ 408
Windshield Wiper Blade Replacement....... 408
Section 5 Service and Appearance Care
353

Electrical System........................................ 464
Add-On Electrical Equipment..................... 464
Headlamps................................................ 464
Windshield Wiper Fuses............................ 464
Power Windows and Other
Power Options....................................... 464Fuses and Circuit Breakers....................... 465
Engine Compartment Fuse Block............... 465
Rear Underseat Fuse Block....................... 471
Capacities and Specications.................... 474
Section 5 Service and Appearance Care
355

Headlamps, Front Turn Signal, and
Parking Lamps
To replace a bulb, do the following:
1. Open the hood. SeeHood Release on
page 364for more information.
2. Remove the grille by grasping and pulling it
forward.
3. Lift the two headlamp retaining clips.
4. Pull the headlamp assembly away from the
vehicle to access the electrical connectors.
5. Remove the cover from the headlamp bulb.
6. Disconnect the wiring harness.
7. Remove the bulb socket by turning it
counterclockwise. Pull the bulb from the
socket.
8. Install the new bulb and turn clockwise to
secure it.
9. Reinstall by reversing Steps 1 through 6.
10. Press down on the headlamp retaining clips to
secure the headlamp assembly.
Taillamps and Turn Signal Lamps
To replace a taillamp or turn signal bulb, do
the following:
1. Open the liftgate. SeeLiftgate/Liftglass on
page 102for more information.
2. Remove the two
screws from the
taillamp assembly.
3. Pull the taillamp assembly away from the
vehicle.
405
