2007 BMW MOTORRAD K 1200 R height

moved up or down for this
purpose.Adapting caseOpen the case.
Remove screws1.
Adjust the height of the holder.
Tighten screws 1.
795zAccessories

Use locating pins3to set the
front-wheel stand to the de-
sired height.
Centre the front-wheel stand
relative to the front wheel and
push it against the front axle.
Push both mounting pins 2
through the triangles of the
brake caliper anchorages just
far enough to allow the front
wheel to be rolled between
them.
There is a risk of damaging
the ABS sensor ring of the
BMW ABS.
Push the pin in just far enough to ensure that it clears the sensor
ring of the BMW ABS.
Tighten adjusting screws 1.
If the motorcycle is on the
centre stand and is raised
too far, the centre stand will lift
clear of the ground and the mo-
torcycle could topple to one side.
When raising the motorcycle,
make sure that the centre stand
remains on the ground.
Apply uniform pressure to push
the front-wheel stand down
and raise the motorcycle.
Rear-wheel standUseBMW Motorrad offers a rear-
wheel stand for holding motor-
cycles (including those without
centre stands) securely upright
for maintenance work. The BMW
special tool number is 36 3 980
and the rear-wheel stand is avail-
able from your authorised BMW
Motorrad dealer.
8116zMaintenance

Installing rear-wheel
standUse screws1to set the rear-
wheel stand to the desired
height.
Remove retaining disc 2.To
do so, press release button 3. Push the rear wheel stand from
the left into the rear axle.
Install the retaining disc from
the right; to do so, press the
unlock button.
Place your left hand on the
left grab handle of the motor-
cycle
4, and your right hand
on the lever of the rear wheel
stand 5. Lift the motorcycle upright,
simultaneously pressing the
lever down until the stand sup-
ports the motorcycle in the up-
right position.
8117zMaintenance

DimensionsLength of motorcycle2288 mm
Height of motorcycle 1230 mm, At DIN unladen weight
Width of motorcycle 856 mm, Across mirrors
Front-seat height 820 mm, Without rider
with OE Double seat, low: 790 mm, Without riderWeightsUnladen weight 237 kg, DIN unladen weight, ready for road, 90 %
load of fuel, without optional extras
Permissible gross weight 450 kg
Maximum payload max 213 kg
10148zTechnical data
