2007 Acura TSX navigation system

ÛÝ
On vehicles with navigation system
On vehicles without navigation system
On vehicles with navigation system
In AU TO mode, the vehicle’s interior
temperature is independently
regulated for the driver and
passenger. If the driver’s side of the
vehicle is getting too much sun, the
system will adjust to a lower
temperature.
Press the AUTO button. The
indicator in the button comes on. When
you push the passenger’s side
temperature control bar, the
indicator in the DUAL button comes
on and the driver’s side and
passenger’s side temperature can be
controlled independently (see page ).
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set the temperature to its
lowest limit ( ) or its highest
limit ( ), the system runs at
f ull cooling or heating only. It does
not regulate the interior temperature.
In cold weather, the fan will not
come on automatically until the
heater starts to develop warm air. You can manually select various
f unctions of the climate control
system when it is in the AUTO mode.
All other f eatures remain
automatically controlled.
Making any manual selection causes
thewordAUTOinthedisplaytogo
out.
Press the A/C button to view the
A/C manual control display.
Making any manual selection causes
the indicator in the AUTO button to
turn off.
Set the desired temperature by
pushing or on the driver’s
side temperature control bar. The
selected temperature will show in
the upper display.
2. 1.
167Semi-automatic Operation
Climate Control System
Features
163

ÝÛ
Ý
Û
On vehicles without navigation system
On vehicles with navigation system On
vehicles without navigation system
On vehicles with navigation system
Select the fan speed by pressing the
fan control bar ( or ).
The fan speed is represented by
vertical bars in the display.
Press the A/C button to view the
A/C manual control display. Touch
the fan control icons to the desired
speed. To
adjust the desired temperature,
push or on the
temperature control bar.
Press the DUAL button to select
dual temperature control mode (see
page ). The indicator in the
DUAL button comes on.
When you press the DUAL button
again (indicator turns of f ), both side
temperature is adjusted by turning
the driver’s side temperature dial. PresstheA/Cbuttontoturntheair
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display.
Press the A/C button to view the
A/C manual control display.
Touching ON or OFF icon in the
display turns the air conditioning on
and off.
When you turn the A/C of f , the
system cannot regulate the inside
temperature if you set the
temperature control below the
outside temperature.
167
Fan Control
T emperature Control
Dual Button Air Conditioning (A/C) Button/
Icons
Climate Control System
164

Use the mode control buttons or
icons to select the vents the air f lows
f rom. Some air f lows f rom the
dashboard corner vents in all modes.If you press the OFF button, the
climate control system shuts of f
completely.
Air flows from the center
and corner vents in the dashboard.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Press the A/C button to view the
A/C manual control display, then
touch any of the mode icons on the
display.
When the climate control system is
turned off, the temperature in the
upper display will also turn of f .To keep stale air and mustiness
f rom collecting, you should have
the f an running at all times. Keep the system of f f or short
periods only.
On vehicles with navigation system
On vehicles with navigation system
Mode ControlTo Turn Everything Of f
Climate Control System
166

ÛÝ
ÛÝ
CONT INUED
Your vehicle has two temperature
control bars, one f or the driver, and
one f or the passenger.
Thedriver’ssideandthepassenger’s
side can be controlled independently
by adjusting these bars when the
green indicator in the DUAL button
is lit.
To set the driver’s side temperature
to a different value than the
passenger’s, press the DUAL button,
then press the temperature control
bars ( or side) on the driver’s
side. To set the passenger’s side to a
different value than the driver’s,
press the temperature control bars
( or side) on the passenger’s
side. You can adjust the passenger’s
side without pressing the DUAL
button first.
Dual Temperature Control
T emperature Control Bars
Features
167
Without navigation system
With navigation system DRIVER’S SIDE
TEMPERATURE
CONTROL BAR
DRIVER’S SIDE
TEMPERATURE
CONTROL BAR
DUAL BUTTON DUAL BUTTON
PASSENGER’S SIDE
TEMPERATURE
CONTROL BAR
PASSENGER’S SIDE
TEMPERATURE
CONTROL BAR
DRIVER’S SIDE
TEMPERATURE DISPLAY
PASSENGER’S SIDE
TEMPERATURE DISPLAY

ÛÝ
When you set the temperature to its
lower or upper limit, it is displayed as
or .
Push AUTO or . The selected
temperatures appear in the upper
display. For vehicles with navigation
system when the indicator in the
DUALbuttonisoff,youcanadjust
both sides to the same temperature
by adjusting the driver’s side
temperature control bar ( or
side).
Dual Temperature Control
168
DRIVER’S SIDE PASSENGER’S SIDE

Playing the AM/FM Radio
170
AM/FM BUTTONSTEREO INDICATOR
A. SEL BUTTON
SCAN BUTTON
PRESET BUTTONS
Without navigation system
TUNE/SOUND KNOB
U.S. model is shown. VOL/PWR KNOB SEEK/SKIP BAR

Playing the AM/FM Radio
Features
171
PRESET ICONSTUNE/SOUND KNOB
SEEK/SKIP BAR UPPER DISPLAY
SCAN ICON SOUND ICON
AUDIO DISPLAY BUTTON
AM/FM BUTTON
SCAN BUTTON
A.SEL ICON
With navigation system
U.S. model is shown. VOL/PWR KNOB

µ
µ
You
can use any of five methods to
find radio stations on the selected
band: TUNE, SEEK, SCAN, the
preset buttons or icons, and AUTO
SELECT.
Pushing the AUDIO DISPLAY
button will also turn on the system.
The band and frequency that the
radio was last tuned to is displayed.
To change bands, press the FM/AM
button. On the FM band, ST will be
displayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available.
XM satellite radio inf ormation is
available on page .
The audio system f or your vehicle
can also be operated using the voice
control system. See the Navi section
in your Quick Start Guide f or an
overview of this system, and the
Navigation System manual f or
complete details.
Use the TUNE/SOUND
knob to tune the radio to a desired
f requency. Turn the knob right to
tune to a higher f requency, and turn
theknoblefttotunetoalower
f requency.
The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Turn the system on by
pushingtheVOL/PWRknoborthe
AM/FM button. Adjust the volume
by turning the same knob.
The SEEK f unction
searches up and down from the
current f requency to f ind a station
with a strong signal. To activate it,
press the or side of the
SEEK/SKIP bar, then release it.
179
On vehicles with navigation system
On vehicles with navigation system
On U.S. models
Playing the AM/FM Radio
To Select a Station
To Play the AM/FM Radio
Voice Control System
TUNE
SEEK
172
