When the tire pressure monitoring
system (TPMS) is functioning
normally and the tires are properly
inflated, you will see the above
display on the multi-info rmation
display as it cycles through its main
menu. To
see the inflation pressures of all
four tires, press the SEL/RESET
button. The display changes as
shown above.
Each tire pressure is shown in PSI
(U.S. model s) or in kPa (Canadian
models). If
one or more of your vehicle tires
are low on pressu re, you will see a
‘‘CHECK TIRE PRESSURE’’
message in the display.
If there is a problem with the TPMS,
you will see a ‘‘CHECK TPMS
SYSTEM’’ message.
Multi-Inf ormation Display
Tire Pressure Monitor
Inst rument s and Cont rols
75
U.S.
Canada
— —
y y
(% y y
See page 266 through 270for more
inf ormation.
To see the inf lation pressures of all
f our tires, press the SEL/RESET
buttononthesteeringwheel.The
display changes as shown above.Each tire pressure is shown in PSI
(U.S. models) or in kPa (Canadian
models).
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator in the instrument
panel to come on. If this happens,
you will see which tire is losing
pressure on the multi-inf ormation
display along with a ‘‘CHECK TIRE
PRESSURE’’ message.
Tire Pressure Monitoring System (TPMS)
268
Canadian model
U.S. model
— —
y
y
(% y y
