The
multi -information display in the
instrument panel displays various
inform ation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comfortably.
Others help to keep you aware of the
periodic maintenance your vehicle
needs for continued trouble-free
driving.
When you open the driver’s door, a
‘‘Welcome’’ message is shown on the
multi-info rmation display. To
change the display, press the
INFO( / )buttononthesteering
wheel repeatedly until the main
menu appears (see page ). With
the ignition switch in the ON
(II) position, the multi -information
display changes as shown on page
each time you press the INFO
( / ) button or SEL/RESET
button.
Wh en you turn the ignition switch to
the ON (II) position, what you last
selected is displayed.
In the multi-information display, the
system message is also displayed
(see page ) and you can
cu stomize your vehicle control
settings (see page ).
69 69
6877
Multi-Inf ormation Display
66
SEL/RESET
BUTTON
INFO BUTTONS
——
yy
(%y
y

ÛÝÛÝ
If there is a problem with your
vehicle, f or example, the parking
brake is not f ully released or a door
is not f ully closed, the multi-
inf ormation display will show you the
problem. It does this by interrupting
the current display with one or more
messages. The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.
You will also hear a beep when the
system message indicator comes on
for the first time.
Most of the messages are displayed
f or about 5 seconds, and then the
normal display returns. If there are
several system messages to be
shown, the display switches these
messages every 5 seconds.
To cancel the message(s) bef ore 5
seconds elapsed, press the INFO
( / ) button on the steering wheel.
Even if you press the INFO ( / )
button, some messages stay on or
come on again at regular intervals
until the problem is corrected.
Here is a list of all messages:
CONT INUED
Multi-Inf ormation Display
System Messages
Inst rument s and Cont rols
67
SYSTEM MESSAGE INDICATOR
——
yy
(%yy

See page
11
See p ages
18, 58
See pages
18, 58
See page
59
See page
59 See
page
268
See page
269
See page
236
See page
63
See page
287 See
page
249
See page
274
Multi-Inf ormation Display
68
U.S.
Canada Canada onlyAT model only
——
y
y
(%yy

Multi-Inf ormation Display
Inst rument s and Cont rols
69
Main Menu
——
y



y
(%yy

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.
Switch between Trip A and Trip B by
pressing the SEL/RESET button.
To reset a trip meter, display it, then
press and hold the SEL/RESET
button until the number resets to
‘‘0.0’’.
Multi-Inf ormation Display
Odometer
T rip Meter
70
SEL/RESET BUTTON
——
y
y
(%yy

µµµµ
µµ µ
µ
¶¶
This shows the outside Fahrenheit
temperature in U.S. models, and
Centigrade temperature in Canadian
models. The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
Select the outside temperature
display, then press the SEL/RESET
button f or 10 seconds. The f ollowing
sequence will appear f or 1 second
each:0,1,2,3,4,5, 5, 4, 3, 2,
1,0(U.S.)or0,1,2,3, 3, 2,
1, 0 (Canada).
When it reaches the desired value,
release the SEL/RESET button. You
should see the new outside
temperature displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
If the outside temperature is
incorrectly displayed, you can adjust
it up to 5°F ( 3°C) warmer or
cooler.
NOTE: The temperature must be
stabilized bef ore doing this
procedure.
Outside Temperature
Multi-Inf ormation Display
Inst rument s and Cont rols
71
U.S.
Canada
——
yy
(%yy

Ý
This
shows the remaining life of the
engine oil. It shows 100% after the
engine oil is replaced and the display
is reset. The engine oil life is
calculated based on engine operating
conditions and accumulated engine
revolutions. For more information,
see page . T
he language of the multi-
inf ormation display is selectable. The
selectable languages are English,
French, and Spanish. To select a language, display
‘‘LANGUAGE SELECTION.’’ Press
the SEL/RESET button. The display
will change as shown above.
Select the desired language by
pressing the INFO ( ) button, then
enter your selection by pressing the
SEL/RESET button.
273
Multi-Inf ormation Display
Engine Oil Lif e
Language Selection
72
——
yy
(%yy

You can receive or make phone calls
from your cell phone through your
vehicle’s HandsFreeLink (HFL)
system without touching your cell
phone. To
use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page for instructions on how to link
your cell phone to the HFL and how
to receive or make phone calls, or
visit the handsf reelink.com website.
When the multi-information display
is in the trip computer mode,
pressing the SEL/RESET button
changes the display as shown in the
next column.
190
CONT INUED
Multi-Inf ormation Display
HandsFreeL ink
T rip Computer
Inst rument s and Cont rols
73
