2007 Acura RL key

If you need to use the shif t lock
release, it means your vehicle is
developing a problem. Have the
vehicle checked by a dealer.
Put a cloth on the edge of the shif t
lock release slot cover next to the
shif t lever. Use a small f lat-tipped
screwdriver or a metal f ingernail
f ile to remove the cover. Caref ully
pry on the edge of the cover. Insert a built-in key into the shif t
lock release slot.
Push down on the built-in key, and
move the shift lever out of Park to
neutral.Remove the built-in key from the
shif t lock release slot, then
reinstall the cover. Make sure the
notchonthecoverisonthedriver’s
side. Press the brake pedal, and
restart the engine.
To release the reverse lockout,
move the shift lever from neutral
to reverse, then to Park.
3.
4.
5.6.
Automatic Transmission
Driving
349
COVER
SHIFT LOCK RELEASE SLOT
——
y
y
(yy

The low beam headlight bulbs are a
type of high voltage discharge tube.
High voltage can remain in the
ci rcuit even with the light switch off
and the key removed. Because of
this, you should not attempt to
examine or change a low beam
headlight bulb yourself. If a low
beam headlight bulb fails, take the
vehicle to your dealer to have it
replaced. Your
vehicle has halogen high beam
headlight bulbs which are also used
for the daytime running light.
Handle it by its base and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Your
vehicle is equipped with an
automatic headlight adjusting
system that adjusts the vertical angle
of the headlights automatically.
Refer to page for more
inf ormation.
Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk or pull a trailer (if applicable),
readjustment may be required.
Adjustmentsshouldbedonebyyour
dealer or other qualif ied technician. 144
Lights
Headlight A iming
Replacing a Headlight/Daytime
Running L ight Bulb
404
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
——
y


y
(yy

In this case, the starter motor’s
speed sounds normal, or even faster
than normal, when you turn the
ignition switch to the START (III)
position, but the engine does not run.
Are you using the proper starting
procedure? Refer to
on page . There
may be an electrical
problem, such as no power to the
fuel pump. Check all the fuses
(see page ).
Ifyoufindnothingwrong,youwill
need a qualified technician to find
the problem. See
on page .
Are you using a properly coded
built-in key or remote? An
improperly coded built-in key or
remote will cause the immobilizer
system indicator in the instrument
panel to blink rapidly (see page
).
Do you have f uel? Check the f uel
gauge; the low f uel indicator may
not be working. Although this seems like a simple
procedure, you should take several
precautions.
You cannot start your vehicle by
pushing or pulling it.
64 341
449
455
T he Starter Operates Normally
Starting the
Engine Emergency
Towing Jump Starting
If the Engine Won’t Start, Jump Starting
T aking Care of t he Unexpect ed
437
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.
——
y

y
(yy

.....................................
Built-in-key .164
..............................
Bulbs, Halogen .404
............................
Capacities Chart .460
.............
Carbon Monoxide Hazard .56
....................
Cargo, How to Carry .335
.............
CAUTION, Explanation of .iii
.........................................
CD Care .234
.......................
CD Error Message .235
...................................
CD Changer .223
................................
Ceiling Lights .196
........................
Certif ication Label .458
.................................
Chains, Tires .420
....................
Changing a Flat Tire .432
Changing Oil ........................................
How to .396
......................................
When to .381
..........
Charging System Indicator .443
............
Checklist, Bef ore Driving .340
.....................................
Child Saf ety .38
..............................
Booster Seats .53
...................................
Child Seats .45
.....
Important Saf ety Reminders .38
..........................................
Inf ants .43..........................
Larger Children .52
.........................................
LATCH .47
......................
Risks with Airbags .39
.............................
Small Children .44
.........................................
Tethers .51
.........
Where Should a Child Sit? .39
.......................................
Child Seats .44
.........................................
LATCH .47
..........
Tether Anchorage Points .51
................
Childproof Door Locks .154
Cleaning
...................................
Seat Belts .411
...............
Climate Control System . 198
.........................
Clock, Setting the .273
........................
CO in the Exhaust .468
............
Cold Weather, Starting in . 341
Collision Mitigation Brake System (CMBS) .....................................
Indicator .360
...................................
Operation .355
......................
Compact Spare Tire .431
...........................
Compass System .240
.................
Console Compartment . 191
.................
Consumer Inf ormation . 474
.............
Controls, Instruments and . 59Coolant
........................................
Adding .398
....................................
Checking .331
.........................
Proper Solution .398
...................
Temperature Gauge . 70
Crankcase Emissions Control ........................................
System .468
................
Cruise Control Indicator . 66
............
Cruise Control Operation . 275
...................................
Cup Holders .190
.............
Customer Service Of f ice . 474
.........................
Customize Settings .81
...................................
ACC Setup .89
................
Door/Window Setup . 122
.......
KEYLESS ACCESS Setup . 108
...........................
Lighting Setup .115
.................................
Meter Setup .94
...........................
Position Setup .103
........................
Setting to Default .85
...............................
Wiper Setup .133
...............
DANGER, Explanation of . iii
...................................
Dashboard . 4, 60
Index
D
C
II
——
y
y
(yy

CONT INUED
................................................
Keys .149
................
Keyless Access System .163
...............
Keyless Access Remote .164
...........
Keyless Memory Settings .170 .................
Jacking up the Vehicle .433
.......................................
Jack, Tire .432
................................
Jump Starting .437
HomeLink Universal
................................
Transceiver .293
.......................
Hood, Opening the .329
...........................................
Horn .5,136
...
Identif ication Number, Vehicle . 458
Ignition ............................................
Keys .149
.........................................
Switch .151
............
Timing Control System . 469
......................
Immobilizer System .150
.........
Important Safety Precautions . 8
.........................................
Indicators .62
ABS (Anti-lock Brake ............................
System) . 64, 353
Aduptive Front lighting ..................
System (AFS) . 69, 143
Brake (Parking and Brake ............................
System) . 63, 445
................
Charging System . 62, 443
Collision Mitigation Brake ..............
System (CMBS) . 69, 360
.............................
Cruise Control .66 Electronically Controlled Power
........
Steering System (ECPS) . 68
.....................................
Fog Light .66
...................................
High Beam .66
........
Key (Immobilizer System) . 64
.....
Keyless Access System . 68, 176
.....................................
Lights On .64
......................................
Low Fuel .66
................
Low Oil Pressure . 62, 443
Low Tire Pressure ...........................
Indicator . 67, 365
.............
Malfunc tion (MIL) . 62, 444
.......................................
Message .68
..............
Seat Belt Reminder . 21, 62
..................
Security System . 69, 274
......................................
SH-AWD .67
...........................
Side Airbag Of f .63
...............................................
SRS .63
Turn Signal and Hazard ...................................
Warning .65
..
VSA (Vehicle Stability Assist) . 65
VSA (Vehicle Stability Assist) .........................
Ac tivation . 65, 371
.........
Indicators, Instrument Panel . 61
...............................
Inf ant Restraint .43 ......................................
Inf ant Seats .43
..........
Tether Anchorage Points . 51
...................
Inf lation, Proper Tire . 415
.................................
Inside Mirror .158
.............................
Inspection, Tire .417
............................
Instrument Panel .61
......
Instrument Panel Brightness . 145
................
Interface Dial . 199, 207, 297
...............................
Interior Lights .196
........................................
Introduction .i
Index
J
K
I
INDEX
V
——
y

y
(yy

.......................
Label, Certif ication .458
...............
Lane Change, Signaling .140
........................
Lap/Shoulder Belts .22
........................
Lights On Indicator .64
Lights ....................
Bulb Replacement .404
.......................................
Indicator .61
......................................
Position .140
................................
Turn Signal .140
.....................................
Load Limit .373
....
LOCK (Ignition Key Position) .151
Locks
.....
Anti-thef t Steering Column .151
........................
Childproof Door .154
............................
Fuel Fill Door .327
..................................
Glove Box .189
...............................
Power Door .152
.........................................
Trunk .153
......
Trunk Pass-through Cover . 157
........................
Low Coolant Level .331
.........................
Low Fuel Indicator .66
...
Low Oil Pressure Indicator . 62, 443
...
Lubricant Specif ications Chart . 460
..........................
Luggage, Storing .335 ...................
Neutral Gear Position . 344..................
New Vehicle Break-in . 326
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 458
..................................
Maintenance .379
................................
Main Items .389
........................................
Minder .381
Owner’s Maintenance ...................................
Checks .388
.................................
Record . 391-392
..........................................
Saf ety .380
...................................
Sub Items .390
.
Malfunction Indicator Lamp . 62, 444
...........
Memory, Driving Position . 160
.............................
Message Display .78
..........................
Message Indicator .68
...............................
Meters, Gauges .70
...................
Methanol in Gasoline . 326
........................
Mirrors, Adjusting .158
.................................
Modif ications .333
...............
Modif ying Your Vehicle . 334
................................
Moonroof . 183-186
................................................
MP3 .230
.............
Multi-Inf ormation Display . 71 ...
Octane Requirement, Gasoline . 326
.........................................
Odometer .72
...............................
Odometer, Trip .72
Oil ........................
Change, How to .396
......................
Change, When to .381
......................
Checking Engine .331
...............................
Lif e, Engine .381
..............
Pressure Indicator . 62, 443
Selecting Proper Viscosity ......................................
Chart .395
.....
ON (Ignition Switch Position) . 151
Onboard Ref ueling Vapor ....................................
Recovery .468
............................
Outside Mirrors .158
....
Outside Temperature Indicator . 73
....................
Overheating, Engine .440
....
Owner’s Maintenance Checks . 388
.........................
Oxygenated Fuels .326
Index
O
M
N
L
VI
——
y
y
(yy
