By opening and closing the doors
To turn on: Open any of the doors.
To turn off: Close all the doors:
When the ignition switch is in the “ON”
position, the cargo lamp will go off im-
mediately.
When the ignition switch is in the
“ACC” or “LOCK” position or the key is
removed, the cargo lamp will automati-
cally go off after 20 seconds.
CARGO LAMP AUTOMATIC POWER OFF
FUNCTION
To prevent the battery being discharged,
the cargo lamp will automatically go off
when the lamp remains on for 30 minutes
or more.
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The “INT” band lets you adjust the wiping
time interval when the wiper lever is in
the intermittent position (position 1). Twist
the band upward to increase the time be-
tween sweeps, and downward to decrease
it. To squirt washer fluid, pull the lever
toward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7
−3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Windshield wipers and washer
(intermittent type)
’06 TUNDRA_U (L/O 0508)
170
2006 TUNDRA from Oct. ’06 Prod. (OM 34458U)
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield,
push the lever up and release it.
To squirt washer fluid, pull the lever
toward you and release it.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7 −3. In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
To defog or defrost the outside rear
view mirrors, push the switch.
The key must be in the “ON” position.
The heater panels in the outside rear view
mirrors will quickly clear the mirror sur-
faces. An indicator light will illuminate to
indicate the mirror heaters are operating.
Push the switch once again to turn the
mirror heaters off.
The system will automatically shut off af-
ter the mirror heaters have operated about
15 minutes.
Windshield wipers and washer
( mist typ e)
Outside rear view mirror
heaters
’06 TUNDRA_U (L/O 0508)
494
2006 TUNDRA from Oct. ’06 Prod. (OM 34458U)
22. ALT S 7.5 A: Charging system
23. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
24. HAZ 15 A: Emergency flashers, turn
signal lights, towing converter
25. EFI NO.1 20 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, fuel pump, “EFI NO.2”
fuse
26. AM2 30 A: Ignition system, starting
system, “IGN” and “STA” fuses
27. TOWING 30 A: Towing converter
28. WIP 20 A: Windshield wipers and
washer
29. TURN 5 A: Turn signal lights
30. ECU IG 5 A: Anti−lock brake system,
vehicle stability control system, multi-
plex communication system, tire pres-
sure warning system
31. 4WD 20 A: Four−wheel drive control
system, A.D.D. control system
32. ACC 15 A: Cigarette lighter, audio sys-
tem, power rear view mirrors, “PWR
OUTLET 1” and “PWR OUTLET 2”
fuses 33. GAUGE 10 A:
Gauges and meters,
back −up lights, starting system, air
conditioning system, auto anti −glare in-
side rear view mirror, outside rear view
mirror heaters
34. IGN 5 A (without daytime running light system) or 7.5 A (with daytime
running light system): SRS airbag
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem, discharge warning light, ignition
system, vehicle stability control system,
front passenger occupant classification
system, engine immobilizer system
35. CARGO LP 5 A: Cargo lamp
36. TAIL 15 A: Tail lights, turn signal
lights, license plate lights, instrument
panel lights, parking lights, glove box
light
37. OBD 7.5 A: On−board diagnosis sys-
tem
38. HORN 10 A: Horns
39. STA 5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, g auges and meters
40. STOP 15 A: Stoplights, high mounted
stoplight, anti −lock brake system, ve-
hicle stability control system, towing
converter Fuses (type B)
41. AM1 40 A: Starting system, “ACC”,
“WIP”, “4WD”, “ECU −IG”, “GAUGE” and
“TURN” fuses
42. HTR 50 A: Air conditioning system,
“A/C” fuse
43. J/B 50 A: “POWER”, “CARGO LP”,
“TAIL”, “OBD”, “HORN” and “STOP”
fuses
44. ABS 2 50 A: Anti−lo
ck brake system,
vehicle stability control system
45. ABS 3 30 A: Anti−lock brake system,
vehicle stability control system
46. ST3 30 A: Starting system, “STA” fuse
47. POWER 30 A: Power door lock sys-
tem, power windows, power back win-
dow, power seat
Fuse (type C)
48. FL ALT 120 A (without towing pack- age) or 140 A (with towing package):
“AM1”, “HTR”, “J/B”, “MIR HTR”,
“FOG”, “TOW BRK”, “SUB BATT”,
“TOW TAIL”, “PWR OUTLET 1” and
“PWR OUTLET 2” fuses
49. A/PUMP 60 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
