Light bulbsBulbNo.WTy p e
Headlights—60/55A
Front fog lights900651B
Parking lights1685C
Front side marker
and front turn
signal lights3157 A27/8D
Rear turn signal
lights744021D
Stop/tail and rear
side marker lights744321/5C
Back −up lights92118C
Tail lights1943.8C
License plate lights1685C
High mounted
stoplight1758C
Interior lights—8E
Personal lights—3.8C
Glove box light—1.2C
Luggage
compartment light—8E
Vanity lights—3C
Door courtesy
lights1943.8C
A: HB2 halogen bulbs
B: HB4 halogen bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
1. Open the hood. Unplug the connec-
tor. Remove the rubber cover.
If the connector is tight, wiggle it.
—Headlights

’06_SEQUOIA_U (L/O 0508)
448
2. Release the bulb retaining springand remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutouts of the mounting
hole.3. Install the rubber cover and fit it securely on the boss. Then, plug in
the connector.
Make sure the rubber cover fits securely
on the bulb base and the mounting body.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer. If either the left or right front fog lights
burns out, contact your Toyota dealer.
NOTICE
Do not try to replace the front fog
light bulbs by yourself. You may dam-
age the vehicle.
—Front fog lights

’06_SEQUOIA_U (L/O 0508)
449
1. LEFTHAND PARKING LIGHT: Foreasy access to the parking light, re-
move the engine coolant reservoir.Use a Phillipshead screwdriver. Remove
and install the clip as shown in the fol-
lowing illustrations.
—Parking lights —Front side marker and front
turn signal lights

’06_SEQUOIA_U (L/O 0508)
450
Removing clip
Installing clip
—Rear turn signal and
stop/tail, rear side marker
lights

’06_SEQUOIA_U (L/O 0508)
451
a: Stop/tail and rear side marker light
b: Rear turn signal lightUse a flathead screwdriver. To protect the
paint, place several sheets of paper over
the paintwork.
—Tail and backup lights

’06_SEQUOIA_U (L/O 0508)
452
Unplug the connector while depressing
the lock release.
a: Tail light
b: Backup light
Use a Phillipshead screwdriver.
—License plate lights

’06_SEQUOIA_U (L/O 0508)
453
Use a Phillipshead and a flathead screw-
drivers. To protect the paint, place several
sheets of paper over the paintwork.
—High mounted stoplight

’06_SEQUOIA_U (L/O 0508)
